Accessory Drive System Ford Cutaway E350

GENERAL SPECIFICATIONS

GENERAL SPECIFICATIONS

Note. All belts new and used must meet the same specifications for the specific application.

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

Ford vehicles are equipped with a Poly-V drive belt. To make sure of maximum belt life, newly installed drive belts must be of the same type and specification as originally installed.

The drive belt is tensioned by a spring-loaded tensioner that maintains correct belt tension at all times.

A loose drive belt will result in slippage, which can cause a noise complaint or incorrect accessory operation. An overly tight drive belt will place severe loads on accessory bearings and result in premature drive belt or accessory failure. Refer to for the belt routing.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Drive Belt Tensioner - Automatic

The drive belt tensioner will maintain correct belt tension if the correct length drive belt is on the engine. To verify that the drive belt tensioner is working correctly, check to see that the belt length indicator mark on the drive belt tensioner is between the minimum and maximum marks. Remove the drive belt and rotate the tensioner to verify that the tensioner does not stick, grab or bind. If the tensioner exhibits any of these conditions, install a new tensioner.

Scheme 5

Inspection and Verification

Scheme 6

Scheme 7

Scheme 8

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical damage. VISUAL INSPECTION CHART Mechanical Drive belt cracking/chunking/wear Belt/pulley contamination Incorrectly routed belt Pulley misalignment or excessive pulley runout Loose or mislocated hardware Incorrectly routed power steering tubes (rubbing)
3. Eliminate all other non-belt related noises that could cause belt misdiagnosis, such as A/C compressor engagement chirp, power steering cavitations at low temperatures, variable camshaft timing (VCT) tick or generator whine.
4. If a concern is found, correct the condition before proceeding to the next step.
5. Check the belt for cracks. Up to 15 cracks in a rib over a distance of 100 mm (4.0 in) can be considered acceptable. If cracks exceed this standard, install a new belt.
6. The condition of the V-ribbed drive belt should be compared against the illustration and appropriate action taken. Small scattered deposits of rubber material. This is not a concern, therefore, installation of a new belt is not required. Longer deposit areas building up to 50% of the rib height. This is not considered a concern but it can result in excessive noise. If noise is apparent, install a new belt. Heavy deposits building up along the grooves resulting in a possible noise and belt stability concern. If heavy deposits are apparent, install a new belt. NOTE: Piling is an excessive buildup in the V-grooves of the belt.
7. There should be no chunks missing from the belt ribs. If the belt shows any evidence of this, install a new accessory drive belt.
8. If the concern is not visually evident, verify the symptom and GO to «SYMPTOM CHART»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system__symptom-chart) .

Symptom Chart

ACCESSORY DRIVE SYMPTOM CHART

Drive Belt - Noise/Flutter

Drive belt chirp occurs due to pulley misalignment or excessive pulley runout. It can be the result of a damaged or an incorrectly aligned grooved pulley.

To correct, determine the area where the noise comes from. Check each of the pulleys in that area with a straightedge to the crankshaft pulley. Look for accessory pulleys out of position in the fore/aft direction or at an angle to the straightedge.

Drive belt squeal may be an intermittent or constant noise that occurs when the drive belt slips on an accessory pulley under certain conditions.

A short intermittent squeal may occur during engine start-up and shut down or during very rapid engine acceleration and decelerations, such as

1. wide open throttle 1 - 2 and 2 - 3 shifts or 2 - 3 and 3 - 4 back out shifts on automatic transmissions.
2. wide open throttle 1 - 2 and 2 - 3 shifts and any combination of rapid downshifting on manual transmissions.

These special short-term transient events are expected, and are due to the higher system inertias required to meet the electrical and cooling demands on today's vehicle systems. Constant or reoccurring drive belt squeal can occur

1. if the A/C discharge pressure goes above specifications: the A/C system is overcharged. the A/C condenser core airflow is blocked.
2. if the A/C OFF equalized pressure (the common discharged and suction pressure that occurs after several minutes) exceeds specifications.
3. if any of the accessories are damaged or have a worn or damaged bearing. All accessories should be rotatable by hand in the unloaded condition. If not, inspect the accessory.
4. if there is evidence of fluid contamination on the accessory drive belt. When the drive belt has been exposed to fluid contamination during vehicle operation, such as leaks from the power steering system, A/C system or cooling system, clean all pulleys with soap and water, rinse with clean water and install a new accessory drive belt. If the drive belt has been exposed to fluids in a localized area during routine vehicle service, such as replacement of hoses or fluids, the drive belt and pulleys should be washed with soap and water immediately (prior to starting the engine), and rinsed with clean water.
5. if the accessory drive belt is too long. A drive belt that is too long will allow the accessory drive belt tensioner arm to go all the way to the arm travel stop under certain load conditions, which will release tension to the drive belt. If the accessory drive belt tensioner indicator is outside the normal installation wear range window, install a new accessory drive belt.
6. Install a new accessory drive belt tensioner if the drive belt tensioner is worn or damaged.

Drive Belt - Incorrect Installation

Non-standard accessory drive belts can track differently or incorrectly. If an accessory drive belt tracks incorrectly, install a new accessory drive belt to avoid performance failure or loss of the drive belt.

Scheme 9

Scheme 10

With the engine running, check accessory drive belt tracking on all pulleys. If the edge of the accessory drive belt rides beyond the edge of the pulleys, noise and premature wear will occur. Make sure the accessory drive belt rides correctly on the pulley. If an accessory drive belt tracking condition exists, proceed with the following

1. Visually check the accessory drive belt tensioner for damage, especially the mounting pad surface. If the accessory drive belt tensioner is not installed correctly, the mounting surface pad will be out of position. This will result in chirp and squeal noises.
2. With the engine running, visually observe the grooves in the pulleys (not the pulley flanges or the pulley forward faces) for excessive wobble. Install new components as necessary.
3. Check all accessories, mounting brackets and the accessory drive belt tensioner for any interference that would prevent the component from mounting correctly. Correct any interference condition and recheck the accessory drive belt tracking.
4. Tighten all accessories, mounting brackets and accessory drive belt tensioner retaining hardware to specification. Recheck the accessory drive belt tracking.

Belt Tensioner - Mechanical

The only mechanical check that needs to be made is a check for tensioner stick, grab or bind.

1. With the engine OFF, check routing of the accessory drive belt. Refer to the illustrations under «DESCRIPTION AND OPERATION»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .
2. Using a suitable, commercially available serpentine belt tensioner release tool, release the tension on the belt and detach the accessory drive belt in the area of the tensioner.
3. Using a suitable, commercially available serpentine belt tensioner release tool, move the tensioner from its relaxed position, through its full stroke and back to the relaxed position to make sure there is no stick, grab or bind, and to make sure that there is tension on the tensioner spring.
4. Rotate the tensioner pulley by hand and check for a binding, contaminated or seized condition. Install a new accessory drive belt tensioner if necessary.
5. Inspect the area surrounding the accessory drive belt tensioner for oil leaks or contamination and repair any leaks. Install a new accessory drive belt tensioner as necessary.
6. If the accessory drive belt tensioner meets the above criteria, proceed to testing the tensioner dynamically. If the accessory drive belt tensioner does not meet the above criteria, install a new tensioner.

Belt Tensioner - Dynamics

The accessory drive belt tensioner can be checked dynamically as follows

1. With the engine running, observe the accessory drive belt tensioner movement. The accessory drive tensioner should move (respond) when the air conditioning clutch cycles (if equipped), or when the engine is accelerated rapidly. If the accessory drive belt tensioner movement is excessive without air conditioning clutch cycling or engine acceleration, check belt rideout. Excessive belt rideout (uneven depth of grooves in the belt) can cause excessive accessory drive belt tensioner movement. Check rideout condition by installing a new belt. If excessive accessory drive belt tensioner movement still exists, install a new accessory drive belt tensioner.

Scheme 11

1. Remove the air cleaner assembly. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering) .
2. Rotate the tensioner clockwise and remove the drive belt.
3. To install, reverse the removal procedure. For additional information, refer to «ACCESSORY DRIVE (DRIVE BELT ROUTING - 4.6L, 5.4L, 6.8L WITH A/C ILLUSTRATION)»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .

Scheme 12

1. Remove the air cleaner assembly. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(/ford/cutaway-e350/2004-2007/remont/removal-installation/#intake-air-distribution-filtering) .
2. Rotate the tensioner counterclockwise and remove the drive belt.
3. To install, reverse the removal procedure. For additional information, refer to «ACCESSORY DRIVE (DRIVE BELT ROUTING - 4.6L, 5.4L, 6.8L WITHOUT A/C ILLUSTRATION)»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .

Removal and Installation

1. Remove the cooling fan stator. For additional information, refer to «ENGINE COOLING»(/ford/cutaway-e350/2004-2007/remont/cooling-system-mechanical/#engine-cooling) .
2. Rotate the tensioner clockwise and remove the accessory drive belt.
3. To install, reverse the removal procedure.

1. Remove the drive belt. For additional information, refer to «ACCESSORY DRIVE BELT - 4.6L, 5.4L AND 6.8L WITH A/C»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) or «ACCESSORY DRIVE BELT - 4.6L, 5.4L AND 6.8L WITHOUT A/C»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .
2. Remove the bolts and the drive belt tensioner.
3. To install, reverse the removal procedure.

Scheme 13

1. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE BELT - 6.0L DIESEL»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .
2. Remove the bolts and the accessory drive belt tensioner.
3. To install, reverse the removal procedure.

Scheme 14

1. Remove the drive belt. For additional information, refer to «ACCESSORY DRIVE BELT - 4.6L, 5.4L AND 6.8L WITH A/C»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) or «ACCESSORY DRIVE BELT - 4.6L, 5.4L AND 6.8L WITHOUT A/C»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .
2. Remove the belt idler pulley. Remove the bolt. Remove the pulley.

Installation

1. To install, reverse the removal procedure.

Scheme 15

1. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE BELT - 6.0L DIESEL»(/ford/cutaway-e350/2004-2007/remont/accessory-drive-belts/#accessory-drive-system) .
2. Remove the bolt and the accessory drive belt idler pulley.
3. To install, reverse the removal procedure.
