VIN - Identification Codes Ford Cutaway E350 Super Duty

Scheme 1

The Vehicle Identification Number (VIN) is a 17-digit combination of letters and numbers. The VIN is stamped on a metal tab riveted to the top upper left of the instrument panel. The VIN is also found on the Vehicle Certification (VC) label.

If the VIN plate requires replacement, authorized dealers must contact their respective regional office.

Scheme 2

VEHICLE IDENTIFICATION NUMBER (VIN) LABELS CODE DESCRIPTION CHART

Scheme 3

The first 3 VIN positions are the WMI .

1. 1FB - Ford Motor Company, USA, bus
2. 1FC - Ford Motor Company, USA, basic (stripped) chassis
3. 1FD - Ford Motor Company, USA, incomplete vehicle
4. 1FM - Ford Motor Company, USA, multi-purpose passenger vehicle
5. 1FT - Ford Motor Company, USA, truck, completed vehicle

Scheme 4

The fourth VIN position is the vehicle brake type and GVWR code. All vehicles use hydraulic brakes.

1. N - 8,501-9,000 lb GVWR with driver and front passenger air bags
2. S - 9,001-10,000 lb GVWR with driver and front passenger air bags
3. W - 10,001-14,000 lb GVWR with driver and front passenger air bags
4. X - 14,001-16,000 lb GVWR with driver and front passenger air bags
5. A - 16,001-19,500 lb GVWR with driver and front passenger air bags
6. H - 8,501-9,000 lb GVWR with active safety belts (all positions)
7. J - 9,001-10,000 lb GVWR with active safety belts (all positions)
8. K - 10,001-14,000 lb GVWR with active safety belts (all positions)
9. L - 14,001-16,000 lb GVWR with active safety belts (all positions)

Scheme 5

Positions 5 through 7 indicate vehicle line, series and body type.

1. E1B - E-150 wagon
2. E1E - E-150 van
3. E2E - E-250 van
4. E2F - E-250 cutaway
5. E3B - E-350 wagon
6. E3E - E-350 van
7. E3F - E-350 cutaway
8. E3K - E-350 stripped chassis
9. E4F - E-450 cutaway
10. E4K - E-450 stripped chassis
11. S1E - E-150 van (extended body)
12. S2E - E-250 van (extended body)
13. S3B - E-350 wagon (extended body)
14. S3E - E-350 van (extended body)
15. S3H - E-350 cutaway

Scheme 6

The eighth VIN position is the engine displacement and number of cylinders.

1. L - 5.4L, SOHC, electronic fuel injection, V8, Gas
2. P - 6.0L, Overhead Camshaft (OHC), V8, Diesel
3. S - 6.8L, SOHC, electronic fuel injection, V10, Gas
4. W - 4.6L, SOHC, electronic fuel injection, V8, Gas

Additional engine information can be obtained from the engine tag. Refer to ENGINE - 4.6L (2V) , ENGINE - 5.4L (2V) , ENGINE - 6.8L or ENGINE - 6.0L DIESEL .

Scheme 7

The ninth VIN position is a government-assigned, computer-generated check digit.

Scheme 8

The tenth VIN position is the model year code.

1. A - 2010

Scheme 9

The eleventh VIN position is the assembly plant code.

1. D - Ohio Assembly

Scheme 10

The last 6 VIN positions are an alphanumeric code for the vehicle build sequence. This is also the vehicle serial and warranty number. The serial number can also be found on the engine block, transmission and frame.

1. A00001-F99999 - Ford Division

Scheme 11

The VC label contains the manufacturer name, the month and year of manufacture, the certification statement and the VIN . It also includes the vehicle GVWR .

If a vehicle requires replacement of the VC label and is 4 years old or less, an authorized dealer must submit the VIN to their respective regional office. The regional office will submit a web form to the assembly plant for the replacement label. Once the label has been printed, a representative from the regional office will deliver the label to the dealer and witness installation on the vehicle. If a vehicle is more than 4 years old and requires a replacement label, the dealer must submit a request to the Department of Motor Vehicles.

Scheme 12

VEHICLE CERTIFICATION (VC) LABEL CODES DESCRIPTION CHART

Scheme 13

Exterior paint codes may be listed as a 2-part code. The first set of letters/numbers listed indicate the primary body color. The second set of letters/numbers listed (if applicable) indicate a 2-tone or accent color. All colors are basecoat/clearcoat.

Primary Body Color

1. Blank - No paint
2. BY - School Bus Yellow
3. DX - Dark Blue Pearl
4. E4 - Vermilion Red
5. G3 - Pueblo Gold
6. GG - Forest Green
7. P - PTO paint (special order)
8. UA - Ebony
9. UJ - Sterling Gray Metallic
10. UK - Royal Red
11. UX - Ingot Silver Metallic
12. YZ - Oxford White 2-Tone/Accent Color
13. UX - Ingot Silver Metallic
14. YZ - Oxford White

Scheme 14

1. 138 - 3,505 mm (138 in) wheelbase
2. 158 - 4,013 mm (158 in) wheelbase
3. 176 - 4,470 mm (176 in) wheelbase

Scheme 15

Interior trim is listed as a 2-part code. The first character indicates the trim type. The second character indicates the interior trim color.

Trim Type

1. A - Simulated vinyl (perforated), bucket seats
2. A - Standard vinyl bucket seats (Canada)
3. C - Mortar cloth, bucket seats
4. L - Milled Pebble leather, captain's chairs
5. L - Premium cloth, captain's chairs (Canada and Mexico)
6. M - Calvin cloth, captain's chairs
7. X - No trim available, seats not included Interior Trim Color
8. E - Medium Flint
9. W - Medium Pebble
10. X - No trim/no color

Scheme 16

Tape and paint stripe codes do not apply.

Scheme 17

1. 5 - Premium electronic AM/FM stereo with CD player
2. 7 - Electronic AM/FM stereo with clock
3. D - Radio prep package (no radio chassis), 6 speakers installed
4. F - Radio pre-equipment pack 4
5. H - AM/FM stereo with CD player
6. N - AM/FM stereo with CD player, clock and navigation system
7. P - Radio pre-equipment pack 6
8. S - Electronic AM/FM stereo with 6-disc CD changer
9. W - Radio pre-equipment pack 5
10. Y - Radio delete

Scheme 18

1. 22 - 4.10 ratio, non-limited slip, single rear wheels
2. 24 - 3.73 ratio, non-limited slip, single rear wheels
3. 32 - 4.10 ratio, non-limited slip, single rear wheels
4. 34 - 3.73 ratio, non-limited slip, single rear wheels
5. 39 - 3.55 ratio, non-limited slip, single rear wheels
6. 52 - 4.10 ratio, non-limited slip, dual rear wheels
7. 56 - 4.10 ratio, non-limited slip, single rear wheels
8. 82 - 4.10 ratio, non-limited slip, dual rear wheels
9. 83 - 4.56 ratio, non-limited slip, dual rear wheels
10. A2 - 3.73 ratio, non-limited slip, dual rear wheels
11. A4 - 3.73 ratio, non-limited slip, single rear wheels
12. B2 - 4.10 ratio, limited slip, single rear wheels
13. B4 - 3.73 ratio, limited slip, single rear wheels
14. C2 - 4.10 ratio, limited slip, single rear wheels
15. C4 - 3.73 ratio, limited slip, single rear wheels
16. C9 - 3.55 ratio, limited slip, single rear wheels
17. D2 - 3.73 ratio, non-limited slip, dual rear wheels
18. D4 - 3.73 ratio, non-limited slip, single rear wheels
19. E2 - 4.10 ratio, limited slip, dual rear wheels
20. E6 - 4.10 ratio, limited slip, single rear wheels
21. F2 - 4.10 ratio, limited slip, dual rear wheels
22. F3 - 4.56 ratio, limited slip, dual rear wheels

Additional axle information can be obtained from the axle tag. Refer to DRIVELINE SYSTEM - GENERAL INFORMATION .

Scheme 19

1. B - 5-speed automatic overdrive (5R110W), diesel
2. Q - 4-speed automatic overdrive (4R75E), gas
3. T - 5-speed automatic overdrive (5R110W), gas

Additional transmission information can be obtained from the transmission tag. Refer to AUTOMATIC TRANSAXLE/TRANSMISSION - 4R70E/4R75E or AUTOMATIC TRANSAXLE/TRANSMISSION - TORQSHIFT .

Scheme 20

Spring codes are identified as a 4-part code. The first 2 characters listed identify the front spring codes. The second 2 characters listed identify the rear spring codes.

Front Springs

1. JJ - 9C24-5310-JA (coil spring)
2. KK - 9C24-5310-KA (coil spring)
3. LL - 9C24-5310-LA (coil spring)
4. MM - 9C24-5310-MA (coil spring)
5. NN - 9C24-5310-NA (coil spring)
6. PP - 9C24-5310-PA (coil spring)
7. RR - 9C24-5310-RA (coil spring)
8. SS - 9C24-5310-SA (coil spring)
9. TT - 9C24-5310-TA (coil spring)
10. UU - 9C24-5310-UA (coil spring)
11. VV - 9C24-5310-VA (coil spring)
12. XX - 9C24-5310-XA (coil spring) Rear Springs
13. 22 - 8C24-5560-RR (leaf spring)
14. 33 - 8C24-5560-SB (leaf spring)
15. 44 - 8C24-5560-CB (leaf spring)
16. AA - 8C24-5560-AB (leaf spring)
17. BB - 8C24-5560-BE (leaf spring)
18. VV - 8C24-5560-VE (leaf spring)

Scheme 21

Note. Powertrain calibration information is limited to a maximum of 5 characters per line on the VC label. Because of this, calibration identification consisting of more than 5 characters will wrap to the second line on the VC label.

Powertrain calibration information is printed in the lower right corner of the VC label. Only the base calibration information is printed. Revision levels will not appear, however, they can be obtained through a scan tool using the most current software revision.

Scheme 22

POWERTRAIN CALIBRATION INFORMATION CODE DESCRIPTION CHART

Model Year

1. 0 - 2000
2. 1 - 2001
3. 2 - 2002
4. 3 - 2003
5. 4 - 2004
6. 5 - 2005
7. 6 - 2006
8. 7 - 2007
9. 8 - 2008
10. 9 - 2009
11. A - 2010 Vehicle Line
12. E4 - E-Series Transmission
13. 1 - Automatic transmission

Unique Calibration

The Emission/Corporate Average Fuel Economy/CO2 Compliance Department is responsible for assigning calibration numbers. Unique calibration identifications are assigned to cover similar vehicles to differentiate tires, drive configurations, final drive ratios and other significant certification factors.

These 2 characters are chosen by the analyst to provide identifiable information unique to each calibration. For example, using the number 2 to denote a 2-valve engine and 4 to denote a 4-valve engine, provides an easily identifiable difference.

Fleet Code

1. 0 - Certification (US 4K, final sale in export markets)
2. 1 - Heavy duty gas engine/Dyno
3. 2 - Fast-Automobile Manufacturer's Association, US
4. 3 - Alternative durability protocol, US
5. 4 - Not assigned
6. 5 - Not assigned
7. 6 - Evaporative Emission (EVAP)
8. 7 - Mileage accumulation aging endurance durability
9. 8 - On-Board Diagnostic (OBD)
10. 9 - Not assigned Certification Region
11. Certification region - Lead code where multiple regions are included in one calibration
12. 5 - US 50 states
13. A - US Federal (including altitude, may include Canada or Mexico)
14. B - US California standard (includes US green states)
15. C - Canada
16. D - China
17. E - European Community (Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Luxembourg, Netherlands, Portugal, Spain, Sweden and United Kingdom)
18. F - Extended European Community (E plus Croatia, Czech Republic, Estonia, Hungary, Norway, Poland, Romania, Russian Federation, Slovakia, Slovenia, Switzerland and Yugoslavia)
19. G - Gulf Cooperative Council
20. H - Hong Kong
21. J - Japan
22. K - Korea
23. L - Malaysia
24. M - Mexico
25. N - New Zealand
26. P - Australia
27. Q - South America (Brazil)
28. S - Singapore
29. T - Taiwan
30. U - South America (unleaded fuel)
31. V - Vietnam
32. X - Rest Of World (ROW)
33. Y - Military
34. Z - Israel Revision Level (not printed on label)
35. 91-99 - Hardware and certification level
36. 01-04 - Preliminary levels
37. 00 - Job 1 production (initial calibration)
38. 05-09 - Pre-job 1 revisions to calibrations
39. 10-89 - Post-job 1 revisions to calibrations
40. 0B - Durability test level
41. BD - OBD intermediate level (pre-05)
