Exterior Lighting System Ford Crown Victoria II

HEADLAMP BULB SPECIFICATIONS

HEADLAMP BULB SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

The exterior lighting system consists of the following components

1. headlamp assemblies
2. rear lamp assemblies
3. fog lamps (if equipped)
4. reversing lamps
5. license lamps
6. front turn signal/cornering lamps
7. side marker lamps
8. high mounted stoplamp
9. photocell and amplifier (if equipped) (located under the LH side of the defroster grille panel)
10. multifunction switch
11. headlamp switch
12. brake pedal position (BPP) switch
13. lighting control module (LCM) (located behind the LH instrument panel lower insulator rearward of the accelerator pedal)

Police Option

In addition to the above listed components, a police option vehicle may include the following

1. front police auxiliary junction box (AJB) (non-fleet vehicle)
2. police glove compartment relay/fuse center (fleet vehicle)
3. police luggage compartment relay/fuse center (fleet vehicle)
4. rear deck flashing lights (fleet vehicle)
5. strobe lamp control module (fleet vehicle)
6. light bar relay/fuse center (fleet vehicle)
7. wig-wag module (alternates the flashing of the high beam headlamps) (located on the RH side of the engine compartment) (fleet vehicle)
8. strobe/light bar control switch (fleet vehicle)

Lighting Control Module (LCM)

The LCM eliminates the electronic interference and heat associated with the thermoelectric devices used previously. The LCM is a microprocessor- based module that controls several vehicle subsystems. It responds to electrical input signals from various switches, sensors, and external modules.

LCM exterior lighting subsystem functions include

1. headlamps with autolamps (if equipped)
2. turn signal lamps/hazard flasher lamps
3. cornering lamps
4. parking lamps
5. battery saver

Security Lighting

Refer to INTERIOR LIGHTING .

Daytime Running Lamps (DRL)

Refer to DAYTIME RUNNING LAMPS .

Headlamps

Refer to HEADLIGHTS for schematic and connector information.

Scheme 1

Principles of Operation

Note. Due to varying wattage ratings and resulting current draw, certain aftermarket headlamp bulbs may cause the lighting control module (LCM) to shut down the short circuit protection, resulting in the low beams becoming inoperative. Verify that the headlamp bulbs meet Ford specifications.

The lighting control module (LCM) receives inputs from the following

1. headlamp switch
2. multifunction switch
3. photocell and amplifier

Depending on the inputs received, the LCM will command the headlamps on or off.

Scheme 2

1. Verify the customer concern by operating the headlamps.
2. Visually inspect for obvious signs of mechanical and electrical damage; (Scheme 2)
3. If the inspection reveals obvious concern(s) that can be readily identified, repair as necessary.
4. If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
5. If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual. NOTE: Make sure the headlamp switch is in the OFF position and the multifunction switch is in the low beam position before carrying out diagnostic tests.
6. Carry out the diagnostic tool data link test. If the diagnostic tool responds with: SCP or ISO circuit fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#module-communications-network-system). No response/not equipped for lighting control module (LCM), refer to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#multifunction-electronic-modules-system). System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out the self-test diagnostics for the LCM.
7. If the DTCs retrieved are related to the concern, go to the «LCM DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) to continue diagnostics.
8. If no DTCs related to the concern are retrieved, proceed to the Symptom Chart to continue diagnostics.

LCM DIAGNOSTIC TROUBLE CODE (DTC) INDEX

For a complete list of LCM DTCs, refer to MULTIFUNCTION ELECTRONIC MODULES .

Scheme 3

PINPOINT TEST A: THE LOW BEAMS ARE INOPERATIVE

Note. Due to varying wattage ratings and resulting current draw, certain aftermarket headlamp bulbs may cause the lighting control module (LCM) to shut down the short circuit protection, resulting in the low beams becoming inoperative. Verify that the bulbs meet Ford specifications.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Autolamps

Refer to HEADLIGHTS for schematic and connector information.

Scheme 10

Headlamp Delay System - Autolamp

The autolamp system

1. provides light sensitive on-off control of the lamps normally controlled by the headlamp switch.
2. provides increased visibility for occupants when leaving the vehicle by keeping the lamps on for approximately 20 seconds after the ignition switch is turned off.

The system consists of

1. a light sensor amplifier
2. a lighting control module (LCM)
3. the headlamp switch

For the autolamp system to be operational, the headlamp switch must be rotated to the AUTO position.

In normal operation

1. The system will turn the exterior lamps on when the light available to the light sensor amplifier decreases below a predetermined level, such as at sunset.
2. The lamps will automatically turn off when the level of outside light exceeds a predetermined level, such as during daylight hours.

The light sensor amplifier must always be exposed to outside light to function correctly. Do not place any items on the defroster grille panel which may block light to the light sensor amplifier and cause erratic operation of the system.

Turning the headlamp switch to any other position will override the autolamps operation. Automatic operation will not be possible until the headlamp switch is turned to the AUTO position.

Scheme 11

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
5. If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
6. Carry out the diagnostic tool data link test. If the diagnostic tool responds with: SCP or ISO circuit fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#module-communications-network-system) . No response/not equipped for LCM, refer to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#multifunction-electronic-modules-system) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out the self-test diagnostics for the LCM.
7. If the DTCs retrieved are related to the concern, go to the «LCM DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) .
8. If no DTCs related to the concern are retrieved, proceed to the Symptom Chart.

LCM DIAGNOSTIC TROUBLE CODE (DTC) INDEX

Note. For a complete master list of all LCM DTCs, refer to MULTIFUNCTION ELECTRONIC MODULES .

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Stoplamps

Refer to EXTERIOR LIGHTS for schematic and connector information.

Scheme 19

Note. The stoplamps are powered directly from the brake pedal position (BPP) switch, not from the lighting control module (LCM).

Stoplamps are mounted in the same housings as the rear lamp.

Stoplamp functions are carried out by double filament bulbs. The low power filaments are dedicated to the parking lamp operation. Stoplamps utilize the high power filaments when the driver applies the brake pedal, closing the BPP switch.

On Crown Victoria equipped with the police street appearance package or Grand Marquis, power is routed from the BPP switch through the multifunction switch to the stoplamps.

On Crown Victoria, power is routed from the BPP switch directly to the stoplamps.

High Mounted Stoplamp

The high mounted stoplamp is mounted in the rear window area. It operates in conjunction with the stoplamps.

Scheme 20

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
5. If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
6. Carry out the diagnostic tool data link test. If the diagnostic tool responds with: SCP or ISO circuit fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#module-communications-network-system) . No response/not equipped for DDM, refer to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#multifunction-electronic-modules-system) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out the self-test diagnostics for the DDM.
7. If the DTCs retrieved are related to the concern, go to the «DDM DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) .
8. If no DTCs related to the concern are retrieved, proceed to the Symptom Chart.

DDM DIAGNOSTIC TROUBLE CODE (DTC) INDEX

Note. For a complete master list of all DDM DTCs, refer to MULTIFUNCTION ELECTRONIC MODULES .

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Turn Signal, Cornering and Hazard Lamps

Refer to EXTERIOR LIGHTS for schematic and connector information.

Scheme 26

Cornering Lamps

The cornering lamps are powered from the headlamp circuit. When the multifunction switch is activated and the headlamps are on, the cornering lamp on the turn side will illuminate and remain illuminated until the turn signal cancels.

Turn Signal and Hazard Lamps

The turn signal and hazard lamp system consists of the following

1. bulbs
2. lighting control module (LCM)
3. turn signal indicators in the instrument cluster
4. multifunction switch

The turn signal system operates as follows

1. The turn signal functions are carried out by double filament bulbs in lamp assemblies located next to the headlamps in front and in the rear lamp assemblies.
2. The turn/hazard function utilizes the second filament of the appropriate bulb(s).
3. With the multifunction switch in the right turn position, power is supplied to the RH front and rear turn signal miniature bulbs and the RH turn indicator in the instrument cluster.
4. With the multifunction switch in the left turn position, power is supplied to the LH front and rear turn signal miniature bulbs and the LH turn indicator in the instrument cluster.

Hazard Lamps Switch

The hazard lamps switch (part of the multifunction switch) is located on the top of the steering column, forward of the steering wheel.

1. The hazard lamps switch should cycle smoothly from OFF to ON by pressing and releasing the switch top.
2. The switch should produce an audible click when it toggles from one state to another.
3. The switch should extend markedly further above the column when the switch is ON than it does when it is OFF.

When the hazard lamps switch is in the ON position, the four turn signal lamps will flash. Also, the two turn indicators in the instrument cluster will flash simultaneously.

Scheme 27

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
5. If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
6. Carry out the diagnostic tool data link test. If the diagnostic tool responds with: SCP or ISO circuit fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#module-communications-network-system) . No response/not equipped for LCM, refer to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#multifunction-electronic-modules-system) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out the self-test diagnostics for the LCM.
7. If the DTCs retrieved are related to the concern, go to the «LCM DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) .
8. If no DTCs related to the concern are retrieved, proceed to the Symptom Chart.

LCM DIAGNOSTIC TROUBLE CODE (DTC) INDEX

Note. For a complete master list of all LCM DTCs, refer to MULTIFUNCTION ELECTRONIC MODULES .

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Parking, Rear and License Lamps

Refer to EXTERIOR LIGHTS for schematic and connector information.

Scheme 34

Lamps - Parking, Rear and License

Based on the input from the headlamp switch (and photocell and amplifier when in the AUTO position), the lighting control module (LCM) provides power to the exterior lamps.

Scheme 35

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If the inspection reveals obvious concern(s) that can be readily identified, repair as necessary.
4. If the concern remains after the inspection, connect the diagnostic tool to the data link connector (DLC) located beneath the instrument panel and select the vehicle to be tested from the diagnostic tool menu. If the diagnostic tool does not communicate with the vehicle: check that the program card is correctly installed. check the connections to the vehicle. check the ignition switch position.
5. If the diagnostic tool still does not communicate with the vehicle, refer to the diagnostic tool manual.
6. Carry out the diagnostic tool data link test. If the diagnostic tool responds with: SCP or ISO circuit fault; all electronic control units no response/not equipped, refer to «MODULE COMMUNICATIONS NETWORK»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#module-communications-network-system) . No response/not equipped for LCM, refer to «MULTIFUNCTION ELECTRONIC MODULES»(/ford/crown-victoria/ii-1997-2011/remont/communication-devices/#multifunction-electronic-modules-system) . System passed, retrieve and record the continuous diagnostic trouble codes (DTCs), erase the continuous DTCs and carry out self-test diagnostics for the LCM.
7. If the DTCs retrieved are related to the concern, go to the «LCM DIAGNOSTIC TROUBLE CODE (DTC) INDEX»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) .
8. If no DTCs related to the concern are retrieved, proceed to the Symptom Chart.

LCM DIAGNOSTIC TROUBLE CODE (DTC) INDEX

Note. For a complete master list of all LCM DTCs, refer to MULTIFUNCTION ELECTRONIC MODULES .

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Fog Lamps

Refer to HEADLIGHTS for schematic and connector information.

Scheme 40

The fog lamp system consists of the following

1. fog lamps
2. fog lamp relay
3. flash-to-pass relay
4. headlamp switch

When the fog lamp switch is engaged, the high beams are not illuminated, and the lighting control module (LCM) has commanded the exterior lamps on if the headlamp switch in the AUTO position, then the fog lamp relay is energized and power is supplied to the fog lamps. When the high beams are illuminated the flash-to-pass relay is energized, which opens the controlled power circuit to the fog lamp relay.

Scheme 41

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern is not visually evident, verify the symptom and refer to the «SYMPTOM CHART»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) .

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Reversing Lamps

Refer to EXTERIOR LIGHTS for schematic and connector information.

Scheme 47

Note. The reversing lamps are not powered by the lighting control module (LCM).

The reversing lamp system consists of the following

1. reversing lamps
2. digital transmission range (TR) sensor

With the transmission in REVERSE, the digital transmission range (TR) sensor contacts close and power is provided to the reversing lamp bulbs.

Scheme 48

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern is not visually evident, verify the symptom and refer to the «SYMPTOM CHART»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) .

Scheme 49

Scheme 50

Scheme 51

Public Safety - Police Package

Refer to EXTERIOR LIGHTS for schematic and connector information.

Scheme 52

Scheme 53

1. Verify the concern.
2. Visually inspect for obvious signs of mechanical and electrical damage.
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. Verify the stoplamps, turn signals, and hazard warning flasher lamps are operating correctly. Refer to the appropriate diagnostic procedures in this article, if necessary.
5. If the concern is not visually evident, verify the symptom and GO to «SYMPTOM CHART»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) .

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Headlamp Aiming

1. The headlamp aiming procedure depends on what type of beam pattern the headlamp is equipped with. Vehicles may come equipped with visual optical left (VOL), visual optical right (VOR) or SAE only (includes sealed beam type) headlamps. To identify the headlamp beam pattern, look on the headlamp lens. Molded in small letters on the headlamp lens is one of the following: SAE VOL and SAE VOR and SAE
2. Once the headlamp beam pattern is identified, aim the headlamps using one of the following methods as applicable. Photometric aimers can aim VOL, VOR and SAE-type headlamps only. This is the preferred method of headlamp aiming. Visual or screen method aiming can be used to aim VOL, VOR and SAE-type headlamps only. Mechanical aimers cannot be used with VOR or VOL-type headlamps. Aerodynamic lamps that can be aimed mechanically have three nibs molded into the lens of the lamp.

Photometric Aiming

1. For the photometric aiming procedure, refer to the appropriate photometric headlamp aimer instruction manual.

Screen Method Aiming

Note. Horizontal aim is not necessary for VOL or VOR headlamps.

Note. Consult your state vehicle inspection manual for recommended tolerance ranges for visual aiming.

Note. The sight shield may need to be positioned or removed for access to the adjusters.

1. Before starting headlamp adjustment: check the tire inflation. check that no other load is in the vehicle other than a half tank of fuel. check that the headlamps are clean. check for correct headlamp operation. check that the vehicle is on level ground. if the vehicle is equipped with air suspension, make sure that the switch is on.
2. Park the vehicle on a level surface approximately 7.6 meters (25 feet) from the vertical wall or screen directly in front of it.
3. Mark a horizontal reference line on the vertical wall or screen.

Scheme 76

Scheme 77

1. Measure the center of the headlamp height to ground and record the measurement.
2. Make a 2.4 meter (8 foot) horizontal mark (using masking tape) on the vertical wall or screen at the same distance from the ground as previously recorded.
3. Turn on the low beam headlamps to illuminate the wall or screen and open the hood.
4. On the wall or screen, locate the high intensity area of the beam pattern. Place the top edge of the high intensity zone even with the horizontal reference line.
5. In addition to the horizontal line marked in Step 3, a pair of vertical lines must be marked at the center line of the headlamps on the wall or screen. Mark the center line of the vehicle on the wall or screen. Measure from the center of the headlamp to the center line of the vehicle. Make two 1.5 meter (5 foot) vertical marks (using masking tape) on the wall or screen at the same distance from the vehicle center line as previously recorded.
6. On the wall or screen, locate the high intensity area of the beam pattern. Place the left edge of the high intensity zone even with the vertical line corresponding to the headlamp being adjusted.
7. Identify at the top edge of this high intensity area a distinct horizontal cutoff in the beam pattern. If the top edge of this cutoff is not even with the horizontal reference line, the headlamp beam needs to be adjusted.
8. For VOL-type headlamps, there is a distinct cutoff in the left portion of the beam pattern. The edge of this cutoff should be positioned 50.2 mm (2 in) below the horizontal reference line. Horizontal reference line. Top edge of the beam pattern. High intensity zone.

Scheme 78

Mechanical Aiming

1. For the mechanical aiming procedure, refer to the appropriate mechanical headlamp aimer instruction manual.

Front Fog Lamp Adjustment

1. Before starting the fog lamp assembly adjustment: check the tire inflation. make sure there are no other loads in the vehicle other than a half tank of fuel. make sure the vehicle is on level ground. make sure the fog lamps and headlamps are clean. make sure the headlamps are operating and are correctly aimed.
2. Park the vehicle on a level surface approximately 7.6 meters (25 ft) from the vertical wall or screen directly in front of it.
3. The correct visual aim for the fog lamps is with the top edge of the high-intensity zone 10 cm (4 in) below the horizontal center of the fog lamps.

Scheme 79

Removal and Installation

All vehicles

Note. The headlamp bulb should not be removed from the headlamp until just before a new bulb is installed. Removing the bulb for an extended period of time may affect headlamp bulb performance. Contaminants may enter the headlamp where they can settle on the lens and reflector. Never turn the headlamps on with the bulb removed.

Note. Make sure the headlamp switch and the ignition switch are turned to the OFF position.

Note. Bulbs 9004 and 9007 look similar, but are not interchangeable.

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. Remove the three pin-type retainers and the radiator sight shield.
2. Remove the headlamp retainers and the headlamp assembly. Disconnect the electrical connectors.
3. Grasp the headlamp bulb by its base and remove the bulb.
4. Remove the nuts and the side turn signal assembly. Disconnect the electrical connector.
5. Remove bolts and the headlamp assembly. Disconnect the electrical connector.
6. Remove the headlamp bulb protective cover
7. Disconnect the electrical connector, grasp the headlamp bulb by its base and remove the bulb.
8. To install, reverse the removal procedure. If necessary, adjust the headlamps. For additional information, refer to «HEADLAMP ADJUSTMENT»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) .

Note. The fog lamp bulb should not be removed from the fog lamp assembly until just before a new bulb is installed. Removing the bulb for an extended period of time may affect fog lamp bulb performance. Contaminants may enter the fog lamp where they may settle on the lens and reflector. Never turn on the fog lamps with the bulb removed.

Note. Make sure the headlamp switch and the ignition switch are turned to the OFF position.

Note. When installing a new fog lamp bulb, use H1 long-life bulbs.

Scheme 87

1. Raise and support the vehicle. For additional information, refer to «JACKING & LIFTING»(/ford/crown-victoria/ii-1997-2011/remont/hoistjack/#jacking-lifting) .
2. Disconnect the electrical connector and remove the fog lamp.
3. To install, reverse the removal procedure.

Scheme 88

Scheme 89

Scheme 90

Scheme 91

1. Remove the two bolts. Disconnect the electrical connector.
2. Disconnect the high mounted stoplamp connector.
3. Remove the flashing rear deck light assembly.
4. Remove the screws and the flashing rear deck light. Disconnect the electrical connector.
5. To install, reverse the removal procedure.

All vehicles

Note. The headlamp bulb should not be removed from the headlamp until just before a new bulb is installed. Removing the bulb for an extended period of time may affect headlamp bulb performance. Contaminants may enter the headlamp where they can settle on the lens and reflector. Never turn the headlamps on with the bulb removed.

Note. Make sure the headlamp switch and the ignition switch are turned to the OFF position.

Scheme 92

Scheme 93

Scheme 94

Scheme 95

1. Remove the three pin-type retainers and the radiator sight shield.
2. Remove the headlamp retainers and the headlamp assembly. Disconnect the electrical connectors.
3. Remove the nuts and the side turn signal assembly. Disconnect the electrical connector.
4. Remove bolts and the headlamp assembly. Disconnect the electrical connector.
5. To install, reverse the removal procedure. If necessary, adjust the headlamps. For additional information, refer to «HEADLAMP ADJUSTMENT»(/ford/crown-victoria/ii-1997-2011/remont/exterior-lights/#exterior-lighting-system) .

Scheme 96

Scheme 97

Scheme 98

Scheme 99

1. Remove the screw.
2. Remove the three pin-type retainers and the radiator sight shield.
3. Remove the nut and the side turn signal assembly. Disconnect the electrical connectors.
4. Remove the nuts and the side turn signal assembly. Disconnect the electrical connectors.
5. To install, reverse the removal procedure.

Scheme 100

Scheme 101

1. Remove the pin-type retainer and position the luggage compartment trim aside.
2. Remove the nuts and the rear lamp assembly. Disconnect the electrical connectors.
3. To install, reverse the removal procedure.

Scheme 102

Scheme 103

Scheme 104

1. Remove the two screws and the high mounted stoplamp assembly. Disconnect the electrical connector.
2. Remove the screws and the high mounted stoplamp assembly. Disconnect the electrical connector.
3. Press the clips and remove the high mounted stoplamp bulb holder.
4. To install, reverse the removal procedure.

Note. The fog lamp bulb should not be removed from the fog lamp assembly until just before a new bulb is installed. Removing the bulb for an extended period of time may affect fog lamp bulb performance. Contaminants may enter the fog lamp where they may settle on the lens and reflector. Never turn on the fog lamps with the bulb removed.

Note. Make sure the headlamp switch and the ignition switch are turned to the OFF position.

Scheme 105

1. Raise and support the vehicle. For additional information, refer to «JACKING & LIFTING»(/ford/crown-victoria/ii-1997-2011/remont/hoistjack/#jacking-lifting) .
2. Disconnect the electrical connector, remove the four screws and the fog lamp assembly.
3. To install, reverse the removal procedure.

Note. Unity stoplamp shown; all others similar.

Scheme 106

Scheme 107

Scheme 108

1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/crown-victoria/ii-1997-2011/remont/charging-system/#battery-mounting-and-cables) .
2. Remove the handle assembly. Remove the set screw. Remove the wedge. Disconnect the electrical connector.
3. Remove the windshield side garnish molding.
4. Remove the inside tube bracket. Remove the set screw. Remove the screws.
5. Remove the stoplamp assembly. Remove the screws and slide the assembly out.
6. Remove the stoplamp. Loosen the set screws. Remove the stoplamp housing from the exterior tube. Remove the O-ring. Remove the nylon bushing.
7. To install, reverse the removal procedure.

Scheme 109

1. Remove the headlamp switch and bezel assembly.
2. Disconnect the electrical connectors.
3. To install, reverse the removal procedure.

Scheme 110

Scheme 111

Scheme 112

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/crown-victoria/ii-1997-2011/remont/charging-system/#battery-mounting-and-cables) .
2. Remove the pin-type retainers and the LH instrument panel insulator. Disconnect the courtesy lamp.
3. Disconnect the brake pedal position (BPP) switch electrical connector.
4. Remove the BPP switch. Remove the self locking pin. Remove the brake master cylinder push rod spacer. Remove the BPP switch from the brake master cylinder push rod. Remove the brake master cylinder push rod bushing.
5. To install, reverse the removal procedure.

Scheme 113

Scheme 114

Scheme 115

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(/ford/crown-victoria/ii-1997-2011/remont/charging-system/#battery-mounting-and-cables) .
2. Remove the defroster grille panel. Disconnect the electrical connector.
3. Unclip the light sensor amplifier.
4. Remove the defroster grille panel. Disconnect the electrical connector.
5. Remove the screws and the light sensor amplifier.
6. To install, reverse the removal procedure.

See also:
• INTERIOR LIGHTING
• DAYTIME RUNNING LAMPS
• MODULE COMMUNICATIONS NETWORK
• MULTIFUNCTION ELECTRONIC MODULES
• JACKING & LIFTING
• BATTERY, MOUNTING AND CABLES
• LCM DIAGNOSTIC TROUBLE CODE (DTC) INDEX
