Overhaul - CD4E Automatic Transmission: Specifications Ford Contour I рестайлинг

Automatic Trans 1 illustration

No Torque Converter Clutch Engagement

Check valve body and torque converter.

Torque Converter Clutch Always Engaged

Check valve body, oil pump assembly, torque converter and transaxle case.

VEHICLE SHIFT SPEED SPECIFICATIONS

Operating ConditionShift Speed MPH
Minimum Throttle (1)
1-29-19
2-320-30
3-435-45
Partial Throttle (2)
1-212-22
2-330-45
3-455-70
WOT
1-230-40
2-362-72
3-497-107
Coast (3)
4-317-27
3-2N/A
3-15-15
2-15-15
Manual 2-127-37
(1) Minimum throttle opening (13%). (2) Partial throttle opening (30%). (3) Closed throttle, coasting condition. Downshift may be imperceptible.
(1)Minimum throttle opening (13%).
(2)Partial throttle opening (30%).
(3)Closed throttle, coasting condition. Downshift may be imperceptible.

VEHICLE SHIFT SPEEDS (PROBE)

Operating ConditionShift Speed MPH
2.0L
Minimum Throttle (1)
1-29-14
2-318-28
3-433-53
Partial Throttle (2)
1-219-30
2-333-53
3-451-82
WOT
1-230-48
2-361-98
3-493-149
Coast (3)
4-327-43
3-2N/A
3-15-8
2-15-8
Manual 2-130-48
2.5L
Minimum Throttle (1)
1-29-14
2-317-27
3-433-53
Partial Throttle (2)
1-216-25
2-330-48
3-451-82
WOT
1-230-48
2-361-98
3-493-149
Coast (3)
4-327-43
3-2N/A
3-16-9
2-16-9
Manual 2-133-53
(1) Minimum throttle opening (13%). (2) Partial throttle opening (30%). (3) Closed throttle, coasting condition. Downshift may be imperceptible.
(1)Minimum throttle opening (13%).
(2)Partial throttle opening (30%).
(3)Closed throttle, coasting condition. Downshift may be imperceptible.

VEHICLE SHIFT SPEEDS (CONTOUR & MYSTIQUE)

TURBINE TORQUE CHECK

Install End Play Checking Tool (T81P-7902-D) with sleeve into turbine splines in converter. Using torque wrench, measure turbine turning torque. Replace converter if torque exceeds 71 INCH lbs. (8 N.m).

Scheme 23

Scheme 23: TURBINE TORQUE CHECK
Scheme 23: TURBINE TORQUE CHECK

TORQUE SPECIFICATIONS

ApplicationFt Lbs. (N.m)
Axle Nut
Contour & Mystique246 (340)
Probe174-235 (235-319)
Ball Joint Clamp Bolt
Contour & Mystique54-67 (74-92)
Probe25-42 (34-57)
Bearing Bracket Bolt
Contour & Mystique15-23 (21-32)
Probe31-46 (42-62)
Cooler Line Fitting27-32 (36-44)
Drain Plug19-21 (25-29)
Manual Control Lever Bolt19-22 (25-30)
Stabilizer Link Nut
Contour & Mystique15-23 (20-32)
Probe27-40 (36-54)
Steering Knuckle Clamp Bolt25-42 (34-57)
Tie Rod End Nut20 (28)
Torque Converter Bolt27 (36)
Transaxle Case Bolt15-18 (20-24)
Transaxle-To-Engine Bolt30 (40)
Transmission Speed Sensor Bolt11 (15)
Valve Body Cover Bolt10-13 (14-18)
Wheel Lug Nut
Contour & Mystique94 (127)
Probe65-87 (88-118)
INCH Lbs. (N.m)
Accumulator-To-Transfer Plate Bolt89 (10)
Manual Valve Lever Ball Stud Nut96-117 (11-13)
Oil Level Control Valve Bolt96-117 (11-13)
Oil Pump Bolt117 (13)
Pressure Tap Plate Bolt71 (8)
Solenoid Valve Body Bolt80-97 (9-11)
Transmission Range Sensor Bolt97 (11)
Transmission Speed Sensor106-124 (12-14)
Valve Body-To-Transfer Plate Bolt96-117 (11-13)
Valve Body-To-Transaxle Case Bolt80-97 (9-11)
Vehicle Speed Sensor Bolt44-53 (5-6)

TORQUE SPECIFICATIONS

TRANSAXLE SPECIFICATIONS

ApplicationIn. (mm)
Direct Clutch Pack Clearance.020-.044 (.50-1.12)
Forward/Coast Clutch Pack Clearance.020-.043 (.50-1.09)
Reverse Clutch Pack Clearance.012-.035 (.33-.89)
Low/Reverse Clutch Pack Clearance.021-.046 (.54-1.17)
Low/Inter. Planetary Thrust Clearance.006-.028 (.15-.72)
Oil Pump Drive Gear Clearance.0015-.0030 (.040-.080)
Oil Pump Driven Gear Clearance.0015-.0030 (.040-.080)
Reverse/OD Planetary Thrust Clearance.006-.028 (.15-.72)
Torque Converter End Play.050 (1.27)
INCH lbs. (N.m)
Oil Pump Rotating Torque2 (.3)

TRANSAXLE SPECIFICATIONS
