INTERIOR FUSE PANEL IDENTIFICATION
The fuse panels for the Bronco are located on the instrument panel behind access door, left of the steering column.
Scheme 1
Interior Fuse & Circuit Breaker Identification
- 1 - 30 Amp - Heater A/C Blower
- 2 - 8.25 Amp (Circuit Breaker) - Wiper/Washer
- 3 - Not Used
- 4 - 15 Amp - Warning Buzzer/Chime Module, Exterior, Lights, Instrument Illumination, Trailer Exterior Light Relay
- 5 - 10 Amp - Air Bag System
- 6 - 15 Amp - A/C Clutch, Auxiliary Fuel Selector
- 7 - 15 Amp - Turn Signal Lights, Rear Window Defroster
- 8 - 15 Amp - Courtesy, Dome & Cargo Lights, Electric Outside Mirrors, Radio/Clock Memory, Speedometer Memory, Warning Buzzer/Chime Module
- 9 - 15 Amp - Power Point
- 10 - 4 Amp - Instrument Panel Illumination
- 11 - 15 Amp - Radio, Radio Display Dimmer
- 12 - 20 Amp - Power Lumbar, Power Door Locks, Electronic Shift Motor 4WD, Key Switch & Tailgate Power, Window (Bronco)
- 13 - 15 Amp - Stoplights, Hazard Lights, Keep Alive Memory Power (F-Series Only), Electronic Engine Control, Speed Control, Anti-Lock Brakes, Stop Sense For: Anti-Lock Brakes & Electronic Engine Control
- 14 - 20 Amp - Power Windows, Tailgate Power Window, Instrument Panel Switch
- 15 - 20 Amp - Anti-Lock Brakes (F-Series Only)
- 16 - 15 Amp - Cigarette Lighter
- 17 - 10 Amp - Warning Buzzer/Chime Module, Warning Indicators, Gauges, Tachometer, Transmission, Control Switch & Indicator Light
- 18 - 10 Amp - Speed Control (F-Series), Electronic Shift Module (4WD), Speedometer
UNDERHOOD FUSE PANEL IDENTIFICATION (BRONCO)
The underhood fuse panel (power distribution box) is located in the engine compartment on the left-hand fender apron.
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
Fuse & Relay Identification (Gas Engine Only)
- 1 - 20 Amp - Audio Power
- 2 - 30 Amp - Anti-Lock Brakes
- 3 - 30 Amp - Horn, Speed Control, Headlight Flash-to-Pass, Daytime Running Lights (Canada)
- 4 - 25 Amp - Trailer, Backup & Running Lights
- 5 - 15 Amp - Heated Oxygen Sensor, Backup Lights, Daytime Running Lights Module (Canada), Trailer Battery Charge Relay, Speed Control
- 6 - 10 Amp - Trailer Stop/Turn Light R/H
- 7 - 10 Amp - Trailer Stop/Turn Light L/H
- 8 - 30 Amp - Anti-Lock Brakes
- 9 - 20 Amp - Electronic Engine Control System, Fuel Pump Relay Coil
- 10 - 20 Amp - Starter Relay Coil, Instrument Panel Fuses: 5, 18
- 11 - Not Used
- 12 - Diode - Electronic Engine Control Relay
- 13 - 50 Amp - Instrument Panel Fuses: 5, 9, 13
- 14 - 30 Amp - Rear Window Defrost
- 15 - 50 Amp - Instrument Panel Fuses: 1, 7, Power Network Box Fuse: 5
- 16 - 20 Amp - Fuel Pump Feed
- 17 - 50 Amp - Instrument Panel Fuses: 2, 6, 11, Power Network Box Fuse: 22, Alternator Charge Light
- 18 - 30 Amp - Trailer Battery Charge
- 19 - 40 Amp - Headlights
- 20 - 50 Amp - Instrument Panel Fuses: 4, 8, 12, 16
- 21 - 30 Amp - Trailer Brake Feed
- 22 - 20 Amp - TFI Module, Ignition Coil, Distributor Pickup, EEC Relay Coil
- Relay 1 - Electronic Engine Control
- Relay 2 - Fuel Pump
- Relay 3 - Horn
- Relay 4 - Trailer Tow or Dual Rear Wheel Running Lights
- Relay 5 - ABS Pump Motor
Fuse & Relay Identification (Diesel Engine Only)
- 1 - 20 Amp - Audio Power
- 2 - Not Used
- 3 - 30 Amp - Horn, Speed Control, Headlight Flash-to-Pass, Daytime Running Lights (Canada)
- 4 - 25 Amp - Trailer, Backup & Running Lights
- 5 - 15 Amp - Backup Lights, Daytime Running Lights Module (Canada), Trailer Battery Charge Relay, Speed Control
- 6 - 10 Amp - Trailer Stop/Turn Light R/H
- 7 - 10 Amp - Trailer Stop/Turn Light L/H
- 8 - 30 Amp - EDV Power
- 9 - 20 Amp - Powertrain Control System
- 10 - 20 Amp - Starter Relay Coil, Instrument Panel Fuses: 5, 18
- 11 - Not Used
- 12 - Diode - Powertrain Control System Relay
- 13 - 50 Amp - Instrument Panel Fuses: 5, 9, 13
- 14 - Not Used
- 15 - 50 Amp - Instrument Panel Fuses: 1, 7, Power Network Box Fuse: 5
- 16 - Not Used
- 17 - 50 Amp - Instrument Panel Fuses: 2, 6, 11, Power Network Box Fuse: 22, Alternator Charge Light
- 18 - 30 Amp - Trailer Battery Charge
- 19 - 40 Amp - Headlights
- 20 - 50 Amp - Instrument Panel Fuses: 4, 8, 12, 16
- 21 - 30 Amp - Trailer Brake Feed
- 22 - 20 Amp - Powertrain Control System Relay
- Relay 1 - Electronic Transmission Control System
- Relay 2 - Trailer Backup Lamps
- Relay 3 - Horn
- Relay 4 - Trailer Tow Lights
- Relay 5 - Not Used
