Removal (Left): Removal & Installation Ford Bronco V

Installation

Ensure gasket mating surfaces are clean and flat. Install exhaust manifold and bolts. Tighten bolts, starting from center and moving outward, to specification. See TORQUE SPECIFICATIONS . To complete installation, reverse removal procedure.

1. Remove lower intake manifold. See «LOWER INTAKE MANIFOLD»(ref-48793-S39531579502001011500000). Remove valve cover(s). Remove drive belt. Disconnect exhaust pipe(s) from manifold(s).
2. To remove left cylinder head, remove A/C compressor (if equipped) and power steering bracket. Remove oil dipstick tube and speed control bracket (if equipped).
3. To remove right cylinder head, remove alternator and air pump mounting bracket complete with accessories. Swing alternator down and position aside.
4. To remove either cylinder head, loosen rocker arm bolts. Mark push rods for installation reference and remove. Disconnect air injection supply hoses at check valves, and plug check valve.
5. Remove cylinder head bolts in reverse order of tightening sequence. (Scheme 4) Remove cylinder head and gasket.

Scheme 4

1. Ensure gasket mating surfaces are clean and flat. Properly install NEW cylinder head gasket as marked on gasket. DO NOT use sealer on head gasket. Install cylinder head and bolts. Tighten bolts in sequence to specification. (Scheme 4) See «TORQUE SPECIFICATIONS»(ref-48793-S07645334572001011500000).
2. Lubricate push rod ends, valve stem tips, rocker arms and fulcrum seats with Multipurpose Grease (DOAZ-19584-AA). To complete installation, reverse removal procedure. Fill and bleed air from cooling system. See «COOLING SYSTEM BLEEDING»(ref-48793-S00546574172001011500000).
