Power Windows: Removal & Installation Eagle Vision I

Removal

1. Remove door trim panel. Raise window to up position. Place a window block in door to prevent window from going down. Window must stay in up position when motor is separated from spring load regulator. Disconnect motor electrical connector.
2. Remove tie down bracket holding motor against inner door panel (if equipped). Remove 3 motor gearbox-to-regulator mounting screws. Separate motor from regulator.

Installation

1. Tap threads in NEW motor screw holes before installation. Install motor on regulator. Ensure motor gearbox engages with regulator sector teeth. Position motor so gearbox center post fits into pilot hole in plate. (Scheme 6) Rotate or rock motor to align 3 motor gearbox screws.
2. Install 3 gearbox screws and one tie down bracket screw. Tighten to 50-60 INCH lbs. (6-7 N.m). Reconnect motor electrical connector. Carefully remove window block. Using control switch, check operation of motor.

Scheme 6

1. Remove door trim panel. Raise or lower window to proper access hole position. Remove flex rack-to-drive arm screw. Drill out regulator attaching rivets. Remove retaining screws (if equipped). Move flex drive regulator motor end outside of large inside panel access hole and rotate regulator out of door.
2. On vehicles that motor does not operate, use following removal procedure: Drill out regulator attaching rivets. Remove retaining screws (if equipped). With flex drive regulator attached, lift window upward until drive arm screw can be removed. If more access is required, remove 2 "T" track-to-motor gearbox screws, allowing removal of motor from "T" track.
3. On all vehicles, remove 2 "T" track-to-motor gearbox screws. Remove motor.

1. Install motor on "T" track. Tighten 2 "T" track-to-motor gearbox screws to 40 INCH lbs. (5 N.m). Insert top of "T" track into access hole. "T" track must point toward hinge pillar.
2. Move "T" track until regulator motor is approximately horizontal. Rotate regulator in opposite direction approximately 1/4 turn and align bracket tab to inner panel slot.
3. Fasten regulator with proper rivet sequence. see scheme 3 Operate motor until flex rack is visible within access slot. Attach window and drive arm assembly to flex rack with screw. Tighten screw to 40 INCH lbs. (5 N.m).

Power Window System Wiring Diagram. Scheme 7
