Keyless Entry System - Remote: Diagnosis Eagle Vision I

TROUBLE SHOOTING

Remote Keyless Entry (RKE) module may be accessed by carefully prying each end of dashboard top cover, then lifting rear edge of top cover and sliding cover forward to disengage front clips. RKE module is located under right side of dash cover. (Scheme 25)

Scheme 25

TESTING

Note. The Remote Keyless Entry (RKE) system is connected to the Body Control Computer system. Testing of the RKE System requires use of the Chrysler Diagnostic Readout Box (DRB) tester to check circuits connected to the Body Control Computer. Only those specific tests for the RKE system are included here. See TESTS W/CODES - BODY CONTROL COMPUTER article in the ENGINE PERFORMANCE Section for complete Body Control Computer testing.

TEST 36A - IDENTIFYING REMOTE KEYLESS ENTRY (RKE) PROBLEM

Note. Perform TEST VER-1 after each repair.

1. Lower both front windows. Remove key from ignition switch. Close all doors. Lock and unlock doors from both front door switches. If doors fail to lock or unlock properly, perform appropriate test listed in the TEST 36A DIAGNOSTIC DIRECTORY . If doors lock and unlock properly, go to next step. TEST 36A DIAGNOSTIC DIRECTORY Problem Perform Test No. Left Front Door Fails To Lock & Unlock From Any Switch TEST 36B Left Front Door Fails To Lock From Any Switch TEST 36C Left Front Door Fails To Unlock From Any Switch TEST 36D All Doors (1) Fail To Lock & Unlock TEST 36E All Doors (1) Fail To Lock TEST 36F All Doors (1) Fail To Unlock TEST 36G (1) Except left front door.
2. Using Remote Keyless Entry (RKE) transmitter, operate door locks and trunk lock. If door locks and trunk lock do not operate properly, replace transmitter batteries or substitute a known-good transmitter. If RKE transmitter still does not operate properly, go to TEST 36H . If RKE transmitter operates properly, go to next step.
3. Insert key in ignition switch. Open left front door. Lock doors from either switch. If doors lock with key in ignition switch, go to TEST 35J in TESTS W/CODES - BODY CONTROL COMPUTER article in the ENGINE PERFORMANCE Section. If doors do not lock with key in ignition switch, go to next step.
4. If vehicle is equipped with speed sensitive locks, drive vehicle with all doors closed. Reach a vehicle speed more than 15 MPH. If doors do not lock at more than 15 MPH, go to TEST 35K in the appropriate TESTS W/CODES - BODY CONTROL COMPUTER article in the ENGINE PERFORMANCE Section. If doors lock, system is operating properly at this time.

TEST 36B - REPAIRING LEFT FRONT DOOR FAILS TO LOCK & UNLOCK FROM ANY SWITCH

Note. For wiring diagram, refer to WIRING DIAGRAM . Perform TEST VER-1 after each repair.

1. Remove key from ignition switch. Gain access to Remote Keyless Entry (RKE) module. (Scheme 25) Disconnect RKE module Black connector. Go to next step.
2. Using DRB, in ohmmeter mode, check resistance of RKE module Black connector terminal No. 4 (Black wire). see scheme 4 If resistance is more than 5 ohms, repair open Black wire. If resistance is less than 5 ohms, go to next step.
3. Connect jumper wire between RKE module Black connector terminals No. 3 (Pink/Black wire) and No. 4 (Black wire). Depress left front door lock switch. If left front door lock operates, replace RKE module. If left front door lock does not operate, go to next step.
4. Remove jumper cable. Using DRB in voltmeter mode, check voltage on RKE module Black connector terminal No. 8 (Pink wire). If voltage is less than 10 volts, repair open Pink wire. If voltage is more than 10 volts, go to next step.
5. Check voltage on RKE module Black connector terminal No. 6 (Orange/White wire). Depress door lock switch to LOCK position. If voltage is less than 10 volts, repair open Orange/White wire. If voltage is more than 10 volts, go to next step.
6. Check voltage on RKE module Black connector terminal No. 1 (Pink/Violet wire). Depress door lock switch to UNLOCK position. If voltage is less than 10 volts, repair open Pink/Violet wire). If voltage is more than 10 volts, go to next step.
7. Reconnect RKE module Black connector. Check voltage on RKE module Black connector terminal No. 3 (Pink/Black wire). Depress door lock switch to UNLOCK position. If voltage is less than 10 volts, replace RKE module. If voltage is more than 10 volts, go to next step.
8. Remove left front door trim panel. Disconnect left front door lock motor connector. Using DRB in voltmeter mode, check voltage on left front door lock motor connector terminal No. 1 (Orange/Black wire). Depress door lock switch to LOCK position. If voltage is less than 10 volts, repair open Orange/Black wire. If voltage is more than 10 volts, go to next step.
9. Check voltage on door lock motor connector terminal No. 2 (Pink/Violet wire). Depress door lock switch to UNLOCK position. If voltage is less than 10 volts, repair open Pink/Violet wire. If voltage is more than 10 volts, replace door lock motor.

TEST 36C - REPAIRING LEFT FRONT DOOR LOCK PROBLEM

Note. For wiring diagram, refer to WIRING DIAGRAM . Perform TEST VER-1 after each repair.

1. Gain access to the Remote Keyless Entry (RKE) module. (Scheme 25) Disconnect RKE module Black connector. Go to next step.
2. Connect jumper wire between RKE module Black connector terminals No. 3 (Pink/Black wire) and No. 4 (Black wire). see scheme 4 Remove key from ignition switch. Depress left front door lock switch to LOCK position. If left front door lock operates, replace RKE module. If left front door lock does not operate, repair open Black wire.

TEST 36D - LEFT FRONT DOOR UNLOCK PROBLEM WITH REMOTE KEYLESS ENTRY (RKE)

Note. For wiring diagram, refer to WIRING DIAGRAM . Perform TEST VER-1 after each repair.

1. Gain access to the Remote Keyless Entry (RKE) module. (Scheme 25) Disconnect RKE module Black connector. Go to next step.
2. Using DRB in voltmeter mode, check voltage on RKE module Black connector terminal No. 8 (Pink wire). see scheme 4 If voltage is less than 10 volts, repair open Pink wire. If voltage is more than 10 volts, go to next step.
3. Check voltage on RKE module Black connector terminal No. 1 (Pink/Violet wire). Depress left front door lock switch to UNLOCK position. If voltage is less than 10 volts, repair open Pink/Violet wire. If voltage is more than 10 volts, replace RKE module.

TEST 36E - ALL DOORS (EXCEPT LEFT FRONT) FAIL TO LOCK & UNLOCK

Note. For wiring diagram, refer to WIRING DIAGRAM . Perform TEST VER-1 after each repair.

1. Remove door unlock relay from junction block. see scheme 5 Junction block is located behind end cover, on left side of instrument panel. Go to next step.
2. Using DRB in ohmmeter mode, check resistance of door unlock relay connector terminal "A" (Pink/Black wire). If resistance is more than 10 ohms, repair open Pink/Black wire. If resistance is less than 10 ohms, go to next step.
3. Check resistance of door unlock relay connector terminals "D" (Black wire) and "E" (Black wire). If resistance is more than 5 ohms in either wire, repair appropriate open Black wire. If resistance is less than 5 ohms, replace unlock relay.

TEST 36F - ALL DOORS (EXCEPT LEFT FRONT) FAIL TO LOCK

Note. For wiring diagram, refer to WIRING DIAGRAM . Perform TEST VER-1 after each repair.

1. Remove key from ignition switch. Remove door lock relay from junction block. see scheme 5 Junction block is located behind end cover, on left side of instrument panel. Go to next step.
2. Using DRB in ohmmeter mode, check resistance of door lock relay connector terminal "E" (Black wire). If resistance is more than 5 ohms, repair open Black wire. If resistance is less than 5 ohms, go to next step.
3. Using DRB in voltmeter mode, check voltage on door lock relay connector terminal "C" (Orange/White wire). Depress door lock switch to LOCK position. If voltage is less than 10 volts, repair open Orange/White wire. If voltage is more than 10 volts, replace door lock relay.

TEST 36G - ALL DOORS (EXCEPT LEFT FRONT) FAIL TO UNLOCK

Note. For wiring diagram, refer to WIRING DIAGRAM . Perform TEST VER-1 after each repair.

1. Remove door unlock relay from junction block. see scheme 5 Junction block is located behind end cover, on left side of instrument panel. Go to next step.
2. Using DRB in ohmmeter mode, check resistance of door unlock relay connector terminal "E" (Black wire). If resistance is more than 5 ohms, repair open Black wire. If resistance is less than 5 ohms, go to next step.
3. Using DRB in voltmeter mode, check voltage on door unlock relay connector terminal "C" (Pink/Violet wire). Depress door lock switch to UNLOCK position. If voltage is less than 10 volts, repair open Pink/Violet wire. If voltage is more than 10 volts, replace door unlock relay.

TEST 36H - REMOTE KEYLESS ENTRY PROBLEM

Note. For wiring diagram, refer to WIRING DIAGRAM . Perform TEST VER-1 after each repair.

1. Gain access to the Remote Keyless Entry (RKE) module. (Scheme 25) Disconnect RKE module Black connector. Go to next step.
2. Using DRB in voltmeter mode, check voltage on RKE module Black connector terminal No. 8 (Pink wire). see scheme 4 If voltage is less than 10 volts, repair open Pink wire. If voltage is more than 10 volts, go to next step.
3. Using DRB in ohmmeter mode, check resistance of RKE module Black connector terminal No. 5 (Dark Green wire). If resistance is less than 5 ohms, repair short to ground in Dark Green wire. If resistance is more than 5 ohms, go to next step.
4. Using DRB in voltmeter mode, check voltage on RKE module Black connector terminal No. 3 (Pink/Black wire). Using DRB, actuate door lock relay. If voltage is less than 10 volts, repair open Pink/Black wire. If voltage is more than 10 volts, go to next step.
5. Check voltage on RKE module Black connector terminal No. 1 (Pink/Violet wire). Using DRB, actuate door unlock relay. If voltage is less than 10 volts, repair open Pink/Violet wire. If voltage is more than 10 volts, go to next step.
6. Check voltage on RKE module Black connector terminal No. 6 (Orange/White wire). Actuate door lock relay. If voltage is less than 10 volts, repair open Orange/White wire. If voltage is more than 10 volts, replace RKE module.

TEST VER-1 - VERIFICATION PROCEDURE

Note. For wiring diagram, see WIRING DIAGRAM .

1. Reconnect all previously disconnected components and connectors. Using DRB, calibrate Automatic Temperature Control (ATC) doors, if any work has been done on ATC system. Ensure all repairs have been made.
2. Turn ignition switch to OFF position, then back to ON position. Using DRB, erase trouble codes. Fully operate system that was malfunctioning by turning switch on, opening door, etc. If system operates properly, repair is complete. If system does not operate properly, return to test 36A.

Remote Keyless Entry (RKE) System Wiring Diagram. Scheme 26
