DOOR WINDOW GLASS
Normally, the door window glass does not need to be adjusted. If there is anything wrong, adjust by the following procedure.
- Remove the window regulator assembly mounting bolts and elongate the mounting hole.
- Temporarily mount the bolts, move the upper installation back and forth and adjust the tilted angle of the glass.
Check for faulty sub fusible link No. 7, faulty power window relay or faulty power window switches. See COMPONENT LOCATIONS .
POWER WINDOW SWITCH(4-DOOR)
Remove suspect power window switch. Check power window switch for continuity. Continuity should be as specified. (Scheme 27) If continuity is not as specified, replace switch.
Scheme 27
SUB SWITCH(4-DOOR)
Remove suspect sub switch. Check sub switch for continuity. Continuity should be as specified. (Scheme 28) If continuity is not as specified, replace sub switch.
Scheme 28
POWER WINDOW MOTOR
- Remove the power window motor and regulator. See «FRONT DOOR GLASS & REGULATOR»(ref-150554-S33939774212002111800000) under REMOVAL & INSTALLATION.
- Connect the motor terminals directly to the battery and check that the motor operates smoothly. (Scheme 29)
- Reverse the polarity and check that the motor operates smoothly in the reverse direction. If not, replace motor.
Scheme 29
CIRCUIT BREAKER
Note. Circuit breaker is incorporated in the power window motor.
- Press UP switch to fully close the window glass, and continue to press the switch for 10 seconds.
- At the moment that the UP switch is released, press the DOWN switch. The circuit breaker can be considered good if the door window glass begins to open within 60 seconds.
POWER WINDOW RELAY
Note. Apply battery voltage to terminal No. 2, and check for continuity when terminal No. 4 is grounded. (Scheme 30)
