Checking Automatic Stop
- Operate wiper motor at low speed. see scheme 1 Disconnect battery voltage during operation to stop motor.
- Using jumper wire, connect terminals as shown. see scheme 1 Connect 12 volts to indicated terminal, and ground wiper motor bracket. Ensure wiper arm is correctly parked.
Continuity & Voltage Check
- Disconnect column switch connector. Ensure continuity is present between terminals No. 5 and 11, and between terminals No. 6 and 10. Ensure there is no continuity between terminals No. 6 and 11.
- Connect battery voltage to terminal No. 5 and ground terminal No. 11. Battery voltage should be present on terminal No. 6. Replace relay if continuity and voltage are not present. (Scheme 6)
Scheme 6
Automatic Stop Check
Operate wiper motor, and then disconnect wiring connector from wiper motor to stop motor operation at a point other than park position. Connect battery voltage and jumper wire to wiper motor connector as shown, and ensure motor housing is well grounded. (Scheme 7) Motor should return to park position.
Scheme 7
