Front
Check front toe-in. See ALIGNMENT SPECIFICATIONS table. If front toe-in is not within specification, remove clips. Turn tie rods or turnbuckles same amount, but in opposite directions. Recheck front toe-in.
Rear (Stealth 2WD & 3000GT 2WD)
Check rear toe-in. See ALIGNMENT SPECIFICATIONS table. If rear toe-in is not within specification, loosen both assist link eccentric cam nuts. Turn assist link eccentric cam bolts equal amount to obtain correct rear toe-in. (Scheme 2)
Rear (Stealth 4WD & 3000GT 4WD)
Check rear toe-in. See ALIGNMENT SPECIFICATIONS table. If rear toe-in is not within specification, loosen both trailing arm eccentric cam nuts. Turn trailing arm eccentric cam bolts equal amount to obtain correct rear toe-in. (Scheme 3)
Scheme 2
Scheme 3
| Application | Preferred | Range | |
|---|---|---|---|
| Camber (1) | |||
| Front | 0 | 0.5 To 0.5 | |
| Rear (2WD) | 0 | 0.5 To 0.5 | |
| Rear (4WD) | 0.17 | 0.67 To 0.33 | |
| Caster (1) | 3.92 | 3.42 To 4.42 | |
| Toe-In (1) | |||
| Front | 0 | 0.24 To 0.24 | |
| Rear | 0.02 | 0.16 To 0.2 | |
| Toe-In (2) | |||
| Front | 0 (0) | 0.12 To 0.12 (-3 To 3) | |
| Rear | 0.01 (0.5) | 0.08 To 0.1 (-2 To 3) | |
| Toe-Out On Turns (1) | |||
| Inner | 33.75 | N/A | |
| Outer | 28.35 | N/A | |
| (1) Measurement in degrees. (2) Measurement in inches (mm). | |||
| (1) | Measurement in degrees. |
| (2) | Measurement in inches (mm). |
WHEEL ALIGNMENT SPECIFICATIONS
