ADJUSTMENTS

Note. Prior to performing wheel alignment, perform preliminary visual and mechanical inspection of wheels, tires and suspension components. See PRE-ALIGNMENT INSTRUCTIONS in WHEEL ALIGNMENT THEORY/OPERATION article in the GENERAL INFORMATION section.

CAMBER ADJUSTMENT

Check camber. See ALIGNMENT SPECIFICATIONS table. If camber is not within specification, loosen eccentric cam nut. Rotate eccentric cam bolt to obtain correct camber. (Scheme 1) Each marking represents a change of.12-.25 degree of camber.

Scheme 1

Scheme 1: CAMBER ADJUSTMENT

Scheme 1: CAMBER ADJUSTMENT

CASTER ADJUSTMENT

Check caster. See ALIGNMENT SPECIFICATIONS table. If caster is not within specification, replace damaged or bent parts.
