DISASSEMBLY Dodge Pickup R1500

Front Axle - 9 1/4 Aa 4 illustrations ~161 words

DISASSEMBLY

Single cardan U-joint components are not serviceable. If defective they must be replaced as a unit.

CAUTIONClamp only the narrow forged portion of the yoke in the vise. To avoid distorting the yoke, do not over tighten the vise jaws.

Scheme 129

Scheme 129
Scheme 129

Scheme 130

Scheme 130
Scheme 130

Scheme 131

Scheme 131
Scheme 131

Scheme 132

Scheme 132
Scheme 132
  1. Remove the bearing cap retaining snap rings (Scheme 131) NOTE: Saturate the bearing caps with penetrating oil prior to removal.
  2. Locate a socket with an inside diameter that is larger than the bearing cap. Place the socket (receiver) against the yoke and around the perimeter of the bearing cap to be removed.
  3. Locate a socket with an outside diameter that is smaller than the bearing cap. Place the socket (driver) against the opposite bearing cap.
  4. Position the yoke with the sockets in a vise (Scheme 132)
  5. Tighten the vise jaws to force the bearing cap into the larger socket (receiver).
  6. Release the vise jaws. Remove the sockets and bearing cap that was partially forced out of the yoke.
  7. Repeat the above procedure for the remaining bearing cap and remove spider from the propeller shaft yoke.
