Wiring diagram: Shift interlock — Shift interlock circuit, with column shift Dodge Pickup R1500
All systems — 72 systems
- Air conditioning 5
- Anti-lock brakes 4
- Anti-lock brakes 3.7l
- Anti-lock brakes 4.7l
- Anti-lock brakes 4.7l flex fuel
- Anti-lock brakes 5.7l
- Anti-theft
- Body computer 4
- Body control modules
- Computer data lines 2
- Computer data lines 3.7l
- Computer data lines 4.7l
- Computer data lines 5.7l
- Computer data lines 5.9l
- Computer data lines 8.3l
- Cooling fan
- Cruise control
- Cruise control 3.7l
- Cruise control 4.7l
- Cruise control 4.7l flex fuel
- Cruise control 5.7l
- Cruise control 5.9l
- Cruise control 8.3l
- Defoggers 4
- Electronic power steering
- Engine performance 3.7l 2
- Engine performance 3.9l
- Engine performance 4.7l 2
- Engine performance 4.7l flex fuel
- Engine performance 5.2l 2
- Engine performance 5.7l
- Engine performance 5.9l 2
- Engine performance 8.3l
- Exterior lights 5
- Ground distribution
- Headlights 8
- Horn
- Instrument cluster 3
- Interior lights 3
- Memory systems 2
- Navigation 4
- Passive restraints 2
- Power distribution
- Power door locks 6
- Power mirrors 5
- Power seats 13
- Power top/sunroof
- Power windows 4
- Radio 12
- Shift interlock 3
- Shift interlocks
- Starting/charging 2
- Starting/charging 3.7l 2
- Starting/charging 3.9l 2
- Starting/charging 4.7l 2
- Starting/charging 4.7l flex fuel 2
- Starting/charging 5.2l 2
- Starting/charging 5.7l 2
- Starting/charging 5.9l 2
- Starting/charging 8.3l 2
- Supplemental restraints 2
- Transmission 5
- Transmission 3.7l 3
- Transmission 3.9l 2
- Transmission 4.7l 2
- Transmission 4.7l flex fuel 2
- Transmission 5.2l 3
- Transmission 5.7l 3
- Transmission 5.9l 3
- Transmission 8.3l
- Warning systems 4
- Wiper/washer
Components on these wiring diagrams 21
Click a component to highlight it on every diagram it appears on.
