Removal & Installation
- Open door. Lower door glass. Remove door pull cup. While pulling door release handle, remove screw securing trim panel to door from behind inside door release handle.
- Disengage hidden clips securing trim panel to door from around perimeter of panel. Tilt trim panel outward to clear locator pins on backside of trim panel. Disengage trim panel from retainer channel at top of door.
- Move trim panel away from door and disengage clip holding door latch linkage to back of inside door handle. Separate latch rod from handle. Disconnect harness connectors for power door lock switch, mirror switch and power window switch. Remove trim panel from vehicle. To install, reverse removal procedure.
Removal and installation procedures are not available from manufacturer. Refer to illustration. (Scheme 1)
Scheme 1
Insert flat-blade screwdriver into slot on bottom of switch bezel. Pry bezel from door trim panel. Disconnect switch harness connector. Remove switch by releasing tabs from bezel. To install, reverse removal procedure.
