Maintenance Information: Overview Dodge Neon I

Procedures 2 illustrations ~406 words

FUSE PANEL IDENTIFICATION

The fuse block is behind the end cover at the left side of the instrument panel. Pull the cover straight away from the instrument panel for access to fuses. A Power Distribution center is located in the engine compartment. An identification label is located on the underside of the cover.

Scheme 1

Scheme 1: FUSE PANEL IDENTIFICATION
Scheme 1: FUSE PANEL IDENTIFICATION

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp (Lt. Blue) Cigarette Lighter
  2. 2 - 15 Amp (Lt. Blue) Taillights, License & Parking Lights, Illumination Lights
  3. 3 - 15 Amp (Lt. Blue) Front Door Lock Switches
  4. 4 - 10 Amp (Red) Fog Lights
  5. 5 - 10 Amp (Red) Air Bag Diagnostic Module, Ignition Run Only Feed
  6. 6 - 10 Amp (Red) Turn Signal Switch
  7. 7 - 25 Amp (Natural) A/C & Heater Blower Motor
  8. 8 - 10 Amp (Red) Rear Window Defrost Switch, A/C Cycling Clutch Switch, Fan Relay, Back-Up Lights
  9. 9 - 10 Amp (Red) Air Bag Diagnostic Module, Ignition Run Only Feed
  10. 10 - 15 Amp (Lt. Blue) Transaxle Lock Up Solenoid, ABS Controller, ABS Relay, Power Train Control Module (PCM), Evap/Purge Solenoid, EGR Solenoid
  11. 11 - 5 Amp (Tan) Daytime Running Light Module (Canada), Instrument Cluster Guages, Warning Lights and Chime
  12. 12 - 4 Amp (Pink) Rear Window Defrost and Fog Light Switch Illumination, Instrument Cluster, A/C Blower Switch, Radio, Ashtray Light, Transmission Range Light Indicator
  13. 13 - Not Used
  14. 14 - Not Used
  15. 15 - 20 Amp (Yellow) Wiper/Washer Switch, Wiper Motor
  16. 16 - 10 Amp (Red) Radio Accessory Feed
  17. 17 - 10 Amp (Red) Left Headlight
  18. 18 - 10 Amp (Red) Right High Beam Headlight, High Beam Indicator
  19. 19 - Not Used
  20. 20 - Not Used

Relay Identification

  1. A - Time Delay Relay
  2. B - Combination Flasher
  3. C - Not Used

Scheme 2

Scheme 2: FUSE PANEL IDENTIFICATION
Scheme 2: FUSE PANEL IDENTIFICATION
WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. 1 - 20 Amp Fuel Pump
  2. 2 - 16 Amp Horn
  3. 3 - 15 Amp Stop Lamp
  4. 4 - 10 Amp Hazard Flasher
  5. 5 - 18 Amp Air Conditioning
  6. 6 - Not Used
  7. 7 - 10 Amp Interior Lights
  8. 8 - 40 Amp ABS
  9. 9 - 30 Amp Starter
  10. 10 - 30 Amp Rear Window Defroster
  11. 11 - 30 Amp Radiator Fan
  12. 12 - 40 Amp Headlamps
  13. 13 - 30 Amp Ignition
  1. A - Not Used
  2. B - Fuel Pump Relay
  3. C - Automatic Shutdown Relay
  4. D - Horn Relay
  5. E - Not Used
  6. F - Radiator Fan Relay
  7. G - A/C Compressor Clutch Relay
  8. H - Engine Starter Relay
