SPECIFICATIONS - STARTER MOTOR

Engine ApplicationPower Rating* Cranking Amperage Draw Test
2.7L1.2 Kilowatt/1.6 Horsepower100 - 300 Amperes
3.0L Diesel2.0 Kilowatt/2.68 Horsepower200 - 500 Amperes
3.5L1.2 Kilowatt/1.6 Horsepower100 - 300 Amperes
5.7L1.4 Kilowatt/1.87 Horsepower100 - 300 Amperes
6.1L1.4 Kilowatt/1.87 Horsepower100 - 300 Amperes
* Test at operating temperature. Cold engine, tight (new) engine, or heavy oil will increase starter amperage draw. Starters are equipped with permanent magnets. Never strike the starter case to attempt to loosen a sticking/stuck armature as permanent magnets may crack or break.

SPECIFICATIONS - TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Battery Cable Nut545
Intermediate Shaft Pinch Bolt4332
Remote Start Antenna Bolts2.522
Starter B+ Nut1197
Starter Mounting Bolts 2.7, 3.5, 5.7, 6.1L5440
Starter Mounting Bolts 3.0L Diesel5440

Scheme 1

Scheme 1: MOTOR - STARTER - 2.7L

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10
  1. Disconnect and isolate negative battery cable at battery.
  2. Install steering wheel holder locking steering wheel in straight-ahead position.
  3. Raise vehicle and support.
  4. Remove the underbody splash shield.
  5. Starter assembly.
  6. Remove the intermediate steering shaft center bolt.
  7. Bolt removed.
  8. Separate the intermediate steering shaft upper and lower shaft.
  9. Disconnect the electrical connection from the starter.
  10. Remove the 3 starter mounting bolts and wiring clip.
  11. Pull starter forward and down.
  12. Position the starter up and around exhaust.
  13. Position the starter past the intermediate steering shaft.
  14. Remove starter from vehicle.

Scheme 11

Scheme 11: MOTOR - STARTER - 3.0L DIESEL

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16
  1. Disconnect negative battery cable.
  2. Raise vehicle and support.
  3. Remove the rear belly pan.
  4. Remove the middle belly pan.
  5. Disconnect the battery connection.
  6. Disconnect the solenoid connection.
  7. Remove the 2 mounting bolts.
  8. Remove starter from vehicle.

Scheme 17

Scheme 17: MOTOR - STARTER - 3.5L
1 - OXYGEN SENSOR
2 - OXYGEN SENSOR CONNECTOR
3 - BALL FLANGE NUT
4 - LH CATALYTIC CONVERTER

Note. All Wheel Drive procedure shown in illustration. Rear Wheel Drive Similar.

Scheme 18

Scheme 18

Scheme 19

Scheme 19
  1. Disconnect and isolate negative battery cable at battery.
  2. Remove the left side catalytic converter (4). Refer to «REMOVAL»(ref-304469-S40093066892008111000000) .
  3. Remove battery cable nut (5) and battery cable (4) from solenoid stud (2).
  4. Disconnect electrical connector (3) from starter solenoid terminal (1).
  5. Remove starter mounting bolts (3), the electrical harness mounting bracket (4) should remain in position.
  6. Rotate and remove starter assembly (1) from transmission.
  7. Remove starter motor dust shield (2).

Scheme 20

Scheme 20: REAR WHEEL DRIVE (RWD)
  1. Disconnect and isolate negative battery cable.
  2. Raise and support vehicle.
  3. Remove three starter mounting bolts (1).
  4. Move starter motor (2) towards front of vehicle far enough for nose of starter to clear. Always support starter motor (2) during this process. Do not let starter motor hang from wire harness.
  5. Remove battery cable-to-solenoid nut.
  6. Remove solenoid wire from solenoid stud.
  7. Remove starter motor.

Scheme 21

Scheme 21: ALL WHEEL DRIVE (AWD)
  1. Disconnect and isolate negative battery cable.
  2. Raise and support vehicle. The steering gear assembly must be partially lowered to gain access to starter. Do not disconnect any hydraulic hoses or remove any steering linkage. Proceed.
  3. Remove coupling bolt (pinch bolt) securing steering gear to steering column.
  4. Remove three steering gear mounting bolts and slightly lower gear. Temporarily support the steering gear.
  5. Remove steering gear heat-shield.
  6. Remove two starter mounting bolts (2).
  7. Move starter motor (1) towards front of vehicle far enough for nose of starter to clear. Always support starter motor (1) during this process. Do not let starter motor hang from wire harness.
  8. Remove battery cable-to-solenoid nut.
  9. Remove solenoid wire from solenoid stud.
  10. Remove starter motor.

Scheme 22

Scheme 22: MOTOR - STARTER - 6.1L
  1. Disconnect and isolate negative battery cable.
  2. Raise and support vehicle.
  3. Remove two heat shield nuts (2) and remove heat shield (3).
  4. Remove three starter mounting bolts (1).
  5. Move starter motor (2) towards front of vehicle far enough for nose of starter to clear. Always support starter motor (2) during this process. Do not let starter motor hang from wire harness.
  6. Remove battery cable-to-solenoid nut.
  7. Remove solenoid wire from solenoid stud.
  8. Remove starter motor.

Scheme 23

Scheme 23

Scheme 24

Scheme 24
  1. Position starter up and pass the transmission and exhaust.
  2. Move starter up and pass the intermediate shafts.
  3. Starter pass the intermediate shaft.
  4. Position starter up toward engine.
  5. Install plastic retainer into starter dust shield. The dust shield has TOP marked on it and the plastic retainer goes in the hole.
  6. Plastic retainer installed.
  7. Install dust shield to the engine block using the plastic retainer to hold dust shield in place.
  8. Install starter and starter bolts. Tighten bolts to 54.2 N.m (40 ft. lbs.).
  9. Install electrical connection to starter.
  10. Match flats inside intermediate shaft with that in intermediate shaft extension, then slide intermediate shaft onto extension.
  11. Align the hole in the shafts.
  12. Install pinch bolt fastening intermediate shaft to intermediate shaft extension.
  13. Tighten pinch bolt to 43 N.m (32 ft. lbs.).
  14. Install the underbody splash shield.
  15. Lower vehicle.
  16. Remove the steering wheel holder.
  17. Connect negative battery cable.
