SPECIFICATIONS
| Component | Fluids, Lubricants and Genuine Parts |
|---|
| Engine Coolant | Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. |
| Engine Oil (2.7L) | Use API Certified SAE 5W-20 Engine Oil meeting the requirements of Chrysler Material Standard MS-6395. Refer to the engine oil fill cap for correct SAE grade. |
| Engine Oil (3.5L) | Use API Certified engine oil. SAE 10W-30 is recommended. Refer to the engine oil viscosity chart for the correct SAE grade meeting Chrysler Material Standard MS-6395. |
| Engine Oil (5.7L) | Use API Certified SAE 5W-20 Engine Oil meeting the requirements of Chrysler Material Standard MS-6395. Refer to the engine oil fill cap for correct SAE grade. |
| Engine Oil (6.1L) | For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) categories of SM or SM/CF, and meet the requirements of Chrysler Material Standard MS-10725. The manufacturer recommends the use of a full synthetic engine oil, such as Mobil 1® SAE 0W-40 or equivalent. For additional information, refer to the "Engine Oil Selection" and "Engine Oil Viscosity (SAE Grade)" in MAINTENANCE SCHEDULES . |
| Spark Plugs (2.7L) | RE14PMC5 (Gap .050 in [1.27 mm]) |
| Spark Plugs (3.5L) | ZFR5LP-13G (Gap .050 in [1.27 mm]) |
| Spark Plugs (5.7L) | REC14MCC4 (Gap .043 in [1.1 mm]) |
| Spark Plugs (6.1L) | PLZTR5A-13 (Gap .050 in [1.27 mm]) |
| Oil Filter (2.7L) | Mopar ® 05281090 or equivalent. |
| Oil Filter (3.5L) | Mopar ® 05281090 or equivalent. |
| Oil Filter (5.7L) | Mopar ® 05281090 or equivalent. |
| Oil Filter (6.1L) | Mopar ® 05281090 or equivalent. |
| Fuel Selection (2.7L) | 87 Octane |
| Fuel Selection (3.5L) | 87 to 89 Octane |
| Fuel Selection (5.7L) | 87 to 89 Octane |
| Fuel Selection (6.1L) | Premium Unleaded 91 Octane Only or higher. |
| Component | Fluids, Lubricants and Genuine Parts |
|---|
| Engine Coolant | Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) |
| Engine Oil (2.7L & 5.7L) - Non ACEA Categories | Use API Certified SAE 5W-20 engine oil, meeting the requirements of Chrysler Material Standard MS-6395. Refer to your engine oil filler cap for correct SAE grade. SAE 5W-30 engine oil approved to MB 229.31 or MB 229.51 may be used when SAE 5W-20 engine oil is not available. |
| Engine Oil (2.7L & 5.7L) - ACEA Categories | For countries that use the ACEA European Oil Categories for Service Fill Oils, use engine oils meeting the requirements of ACEA C3, and approved to MB 229.31 or MB 229.51. SAE 5W-30 engine oil approved to MB 229.31 or MB 229.51 may be used when SAE 5W-20 engine oil is not available. |
| Engine Oil (3.5L) - Non ACEA Categories | Use API Certified SAE 10W-30 engine oil, meeting Chrysler Material Standard MS-6395 and approved to MB 229.31 or MB 229.51. Refer to your engine oil filler cap for correct SAE grade. |
| Engine Oil (3.5L) - ACEA Categories | For countries that use the ACEA European Oil Categories for Service Fill Oils, use SAE 10W-30 engine oil meeting the requirements of ACEA C3, and approved to MB 229.31 or MB 229.51. |
| Engine Oil (3.0L Diesel) - ACEA Categories | Use SAE 5W-30 Synthetic Low Ash engine oil, meeting the requirements of Chrysler Material Standard MS-11106 and approved to MB 229.31 or MB 229.51 and ACEA C3. |
| Engine Oil (6.1L) - Non ACEA Categories | For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils approved to MB 229.31 or MB 229.51, and meeting the requirements of Chrysler Material Standard MS-10725. The manufacturer recommends the use of a full synthetic engine oil, such as Mobil 1® SAE 0W-40 or equivalent. |
| Engine Oil (6.1L) - ACEA Categories | For countries that use the ACEA European Oil Categories for Service Fill Oils, use SAE 0W-40 engine oil meeting the requirements of ACEA C3 and approved to MB 229.31 or MB 229.51. |
| Spark Plugs (2.7L) | RE14PMC5 (Gap .050 in [1.27 mm]) |
| Spark Plugs (3.5L) | ZFR5LP-13G (Gap .050 in [1.27 mm]) |
| Spark Plugs (5.7L) | REC14MCC4 (Gap .043 in [1.1 mm]) |
| Spark Plugs (6.1L) | PLZTR5A-13 (Gap .050 in [1.27 mm]) |
| Oil Filter (2.7L) | Mopar ® 05281090 or equivalent. |
| Oil Filter (3.5L) | Mopar ® 05281090 or equivalent. |
| Oil Filter (5.7L) | Mopar ® 05281090 or equivalent. |
| Oil Filter (6.1L) | Mopar ® 05281090 or equivalent. |
| Oil Filter (3.0L Diesel) | Mopar ® 05175571AA or equivalent. |
| Fuel Selection (2.7L) | 91 Octane |
| Fuel Selection (3.5L) | 91 Octane Acceptable - 95 Octane Recommended |
| Fuel Selection (5.7L | 91 Octane Acceptable - 95 Octane Recommended |
| Fuel Selection (6.1L) | Premium Unleaded 98 Octane |
| Fuel Selection (3.0 L Diesel) | Use good quality diesel fuel from a reputable supplier in your vehicle. The manufacturer requires that you must fuel this vehicle with Ultra Low Sulfur Highway Diesel fuel (15 ppm Sulfur maximum) and prohibits the use of Low Sulfur Highway Diesel fuel (500 ppm Sulfur maximum) to avoid damage to the emissions control system. For most year-round service, No. 2 diesel fuel meeting ASTM specification D-975 Grade S15 will provide good performance. If the vehicle is exposed to extreme cold (below 20F or -7C), or is required to operate at colder-than-normal conditions for prolonged periods, use climatized No. 2 diesel fuel or dilute the No. 2 diesel fuel with 50% No. 1 diesel fuel. This will provide better protection from fuel gelling or wax-plugging of the fuel filters. This vehicle is fully compatible with biodiesel blends up to 5% biodiesel meeting ASTM specification D-975. |
| Component | Fluids, Lubricants, and Genuine Parts |
|---|
| Automatic Transmission | Mopar ® ATF+4 Automatic Transmission Fluid |
| Brake Master Cylinder | Mopar ® DOT 3, SAE J1703 or equivalent should be used. If DOT 3 brake fluid is not available, then DOT 4 is acceptable. Use only recommended brake fluids. |
| Front Axle | API GL-5 SAE 75W90 Synthetic Gear Lubricant or equivalent |
| Power Steering Reservoir | Mopar ® Power Steering Fluid + 4, Mopar ® ATF+4 Automatic Transmission Fluid |
| Rear Axle | API GL-5 SAE 75W140 Synthetic Gear Lubricant or equivalent |
| Transfer Case | Mopar ® Transfer Case Lubricant LX, P/N 05170055AA, or equivalent |
| DESCRIPTION | U.S. | Metric |
|---|
| Fuel (approximate) |
| 2.7/3.5 Liter Engines RWD | 18 Gallons | 68 Liter |
| 2.7/3.5 Liter Engines AWD | 19 Gallons | 72 Liter |
| 5.7 Liter Engines | 19 Gallons | 72 Liter |
| 6.1 Liter Engine | 19 Gallons | 72 Liter |
| Engine Oil-With Filter |
| 2.7 Liter Engines | 6.0 Quarts | 5.7 Liter |
| 3.5 Liter Engines | 6.0 Quarts | 5.7 Liter |
| 5.7 Liter Engines | 7.0 Quarts | 6.6 Liter |
| 6.1 Liter Engine | 7.0 Quarts | 6.6 Liter |
| Cooling System * |
| 2.7 Liter Engines (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile or equivalent. | 9.9 Quarts | 9.4 Liter |
| 3.5 Liter Engine without All Wheel Drive Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile or equivalent. | 11.1 Quarts | 10.5 Liter |
| 3.5 Liter Engine with All Wheel Drive Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile or equivalent. | 11.4 Quarts | 10.8 Liter |
| 5.7 Liter Engines Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile or equivalent. | 14.7 Quarts | 13.9 Liter |
| 5.7 Liter Engine with Severe Duty II Cooling System (Mopar® Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent | 15.1 Quarts | 14.3 Liter |
| 6.1 Liter Engine Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile or equivalent. | 15.2 Quarts | 14.4 Liter |
| * Includes heater and coolant recovery bottle filled to MAX level. |
| Power Steering System |
| Power steering fluid capacities are dependent on engine/chassis options as well as steering gear/cooler options. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these capacities may vary. Refer to STEERING for proper fill and bleed procedures. |
| A/C Refrigerant System |
| All Models | 1.625 Pounds | 0.737 kilograms |
| Automatic Transmission |
| Service Fill - NAG1 | 10.6 Pints | 5.0 Liter |
| Overhaul Fill - NAG1 | 16.3 Pints< | 7.7 Liter |
| Service Fill - 42RLE | 4.0 Quarts | 3.8 Liter |
| Overhaul Fill - 42RLE | 17.6 Pints< | 8.3 Liter |
| <--Dry fill capacity. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. Refer to STANDARD PROCEDURE . |
| Transfer Case |
| MS140 | 1.3 Pints | 0.6 Liter |
| Axle - Front |
| 175 MM FIA Axle | 0.63 Quarts | 600 ml |
| Axle - Rear |
| 198 MM RII Axle | 1.5 Quarts. | 1.4 Liter |
| 210 MM RII Axle | 1.7 Quarts. | 1.6 Liter |
| 215 MM RII Axle | 1.7 Quarts. | 1.6 Liter |
CAPACITIES - EXCEPT EXPORT
| DESCRIPTION | U.S. | Metric |
|---|
| Fuel (approximate) |
| 2.7/3.5 Liter Engine RWD | 18 Gallons | 68 Liter |
| 3.5 Liter Engine with AWD | 19 Gallons | 72 Liter |
| 5.7 Liter Engine | 19 Gallons | 72 Liter |
| 6.1 Liter Engine | 19 Gallons | 72 Liter |
| 3.0 Liter Diesel Engine | 19 Gallons | 72 Liter |
| Engine Oil with Filter |
| 2.7 Liter Engine | 6.0 Quarts | 5.7 Liter |
| 3.5 Liter Engine | 6.0 Quarts | 5.7 Liter |
| 5.7 Liter Engine | 7.0 Quarts | 6.6 Liter |
| 6.1 Liter Engine | 7.0 Quarts | 6.6 Liter |
| 3.0 Liter Diesel Engine | 10 Quarts | 9.5 Liter |
| Cooling System * |
| 2.7 Liter Engine (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile) or equivalent. | 10.4 Quarts | 9.8 Liter |
| 3.5 Liter Engine (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile) or equivalent. | 11.4 Quarts | 10.8 Liter |
| 5.7 Liter Engine (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile) or equivalent. | 15.1 Quarts | 14.3 Liter |
| 6.1 Liter Engine (Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile) or equivalent. | 15.2 Quarts | 14.4 Liter |
| 3.0 Liter Diesel Engine (Mopar ® Antifreeze/Engine Coolant 5 Year/100,000 Mile) | 13.2 Quarts | 12.5 Liter |
| * Includes heater and coolant recovery bottle filled to MAX level. |
| Power Steering System |
| Power steering fluid capacities are dependent on engine/chassis options as well as steering gear/cooler options. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these capacities may vary. Refer to STEERING for proper fill and bleed procedures. |
| A/C Refrigerant System |
| All Models | 1.625 Pounds | 0.737 kilograms |
| Automatic Transmission |
| Service Fill - NAG1 | 10.6 Pints | 5.0 Liter |
| Overhaul Fill - NAG1 | 16.3 Pints< | 7.7 Liter |
| Service Fill - 42RLE | 4.0 Quarts | 3.8 Liter |
| Overhaul Fill - 42RLE | 17.6 Pints< | 8.3 Liter |
| <--Dry fill capacity. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. Refer to STANDARD PROCEDURE . |
| Transfer Case |
| MS140 | 1.3 Pints | 0.6 Liter |
| Axle - Front |
| 175MM FIA Axle | 0.63 Quarts | 600 ml |
| Axle - Rear |
| 198 MM RII Axle | 1.5 Quarts. | 1.4 Liter |
| 210 MM RII Axle | 1.7 Quarts. | 1.6 Liter |
| 215 MM RII Axle | 1.7 Quarts. | 1.6 Liter |
Scheme 9
Scheme 9: Front Power Distribution Center Fuses
A power distribution center is located in the engine compartment. This center contains fuses and relays.
| CAUTION | When installing the Power Distribution Center cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Power Distribution Center, and possibly result in an electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
| Cavity | Cartridge Fuse | Mini-Fuse | Description |
|---|
| 1 | | 15 Amp Blue | Washer Motor |
| 2 | | 25 Amp Neutral | Powertrain Control Module (PCM) |
| 3 | | 25 Amp Neutral | Ignition Run/Start |
| 4 | | 25 Amp Neutral | Alternator/EGR Solenoid |
| 5 | | 15 Amp Blue | Engine Control Module (Diesel) |
| 6 | | 25 Amp Neutral | Ignition Coils/Injectors/Short Runner Valve |
| 7 | | 25 Amp Neutral | Interior Lamps/Under Hood Lamps (Police) |
| 8 | | 25 Amp Neutral | Starter |
| 9 | | | Starter Relay |
| 10 | 30 Amp Pink | | Windshield Wiper |
| 11 | 30 Amp Pink | | Anti-Lock Brake System (ABS) Valves - if equipped |
| 12 | 40 Amp Green | | Radiator Fan |
| 13 | 50 Amp Red | | Anti-Lock Brake System (ABS) Pump Motor - if equipped |
| 14 | | | |
| 15 | 50 Amp Red | | Radiator Fan |
| 16 | | | Wiper On/Off Relay |
| 17 | | | Wiper High/Low Relay |
| 18 | | | Radiator Fan Control Relay |
| 19 | | | Radiator Fan High/Low Control Relay |
| 20 | | | Radiator Fan High Relay |
| 21 | | | Auto Shut Down Relay |
| 22 | | | Run/Start Relay |
Scheme 10
Scheme 10: Rear Power Distribution Center Fuses
There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays.
| CAUTION | When installing the Power Distribution Center cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Power Distribution Center, and possibly result in an electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
| Cavity | Cartridge Fuse | Mini Fuse | Description |
|---|
| 1 | 60 Amp Yellow | | Ignition Off Draw (IOD) |
| 2 | 40 Amp Green | | Battery |
| 3 | | 20 Amp Yellow | Lamp Dome (Police) |
| 4 | 40 Amp Green | | Battery |
| 5 | 30 Amp Pink | | Heated Seats - if equipped |
| 6 | | 20 Amp Yellow | Fuel Pump |
| 7 | | 15 Amp Blue | Lamp Spot Right (Police) |
| 8 | | 15 Amp Blue | Ignition Switch/Airbag Control Module (ACM) |
| 9 | | 20 Amp Yellow | Console Power Outlet |
| 10 | | | |
| 11 * | | | Circuit Breaker 1 |
| 12 * | | | Circuit Breaker 2 |
| 13 * | | | Circuit Breaker 3 |
| 14 | | 10 Amp Red | AC Heater Control/Cluster/Sentry Key Remote Keyless Entry |
| 15 | | 20 Amp Yellow | Trailer Tow Brake Module - if equipped |
| 16 | | 20 Amp Yellow | Power Outlet Rear |
| 17 | | 20 Amp Yellow | Cluster |
| 18 | | 20 Amp Yellow | Selectable Power Outlet |
| 19 | | 10 Amp Red | Stop Lights |
| 20 | | 20 Amp Yellow | Rear Wiper Relay |
| 21 | | | Run Relay |
| 22 | | | Rear Window Defogger relay |
| 23 | | | Accessory Delay Relay |
| 24 | | | Transmission Relay (NAG1) |
| 25 | | | |
| 26 | | | Rear Wiper Relay |
| 27 | | 10 Amp Red | Airbag/Airbag Control Module (ACM) |
| 28 | | 10 Amp Red | Curtain Airbag - if equipped |
| 29 | | 5 Amp Orange | Anti-lock Brakes Module - if equipped/Cluster/Front Control Module (FCM)/Powertrain Control Module (PCM)/Sentry Key Remote Keyless Entry/Stop Lights |
| 30 | | 10 Amp Red | Door Modules/Power Mirrors - if equipped/Steering Control Module |
| 31 | | | Diode 2 |
| 32 | | | Diode 1 (NAG1) |
| 33 | | | Diode - Zener |
| 34 | | | Spare |
| 35 | | 5 Amp Orange | Amplifier - if equipped/Antenna/Ignition Delay/Overhead Console/Passenger Door Lock & Express Power Window Switch - if equipped/Power Mirrors - if equipped/Rain Sensor - if equipped/Rear Defrost |
| 36 | | 20 Amp Yellow | Hands Free Phone - if equipped/Media System Monitor DVD - if equipped/Radio/Satellite Receiver - if equipped |
| 37 | | 15 Amp Blue | Transmission - NAG1 |
| 38 | | 5 Amp Orange | Analog Clock/Cargo Light/Overhead Console |
| 39 | | 10 Amp Red | Heated Mirrors - if equipped |
| 40 | | 5 Amp Orange | Heated Seats - if equipped/Inside Rearview Mirror |
| 41 | | 10 Amp Red | AC Heater Control/Park Assist - if equipped/Tire Pressure Monitoring - if equipped |
| 42 | 30 Amp Pink | | Front Blower Motor |
| 43 | 30 Amp Pink | | Amplifier - if equipped/Antenna/Rear Defrost |
| 44 | 20 Amp Blue | | Amplifier - if equipped/Front Control Module (FCM)/Sunroof - if equipped |
| 45 | | | Lamp Activation relay |
| 46 | | | Fuel Pump Relay |
| 47 | | | Rear Heated Seats Relay |
* Cavities 11, 12, and 13 contain self-resetting fuses (circuit breakers) that are only serviceable by an authorized dealer. The Cluster (without power memory seat), the Driver Seat Switch (with power memory seat), and the Memory Module (if equipped) are fused by the 25 amp circuit breaker in Cavity 11. The Passenger Seat Switch is fused by the 25 amp circuit breaker in Cavity 12. The Door Modules (except base), the Driver Door Lock Switch (base), the Driver Express Power Window Switch (if equipped), and the Passenger Door Lock Switch (base) are fused by the 25 amp circuit breaker in Cavity 13. If you experience temporary or permanent loss of these systems, see your authorized dealer for service.
Scheme 11
Scheme 11: Diesel Fuse/Relay Block
| Cavity | Cartridge Fuse | Description |
|---|
| 1 | 50 Amp | Relay Switched Fuse PTC # 1 |
| 2 | 50 Amp | Relay Switched Fuse PTC # 2 |
| 3 | 50 Amp | Relay Switched Fuse PTC # 3 |
| 4 | | Relay-PTC # 3 |
| 5 | | Relay-PTC # 2 |
| 6 | | Relay-PTC # 1 |
Scheme 12
Scheme 12: Police Fuse/Relay Block
| Cavity | Cartridge Fuse | Description |
|---|
| 1 | 20 Amp | Fused Circuit |
| 2 | 20 Amp | Relay Switched Fuse Police # 1 Relay |
| 3 | 20 Amp | Fused Circuit |
| 4 | 20 Amp | Relay Switched Fuse Police # 2 Relay |
| 5 | 20 Amp | Fused Circuit |
| 6 | 20 Amp | Relay Switched Fuse Police # 3 Relay |
| 7 | 20 Amp | Spare |
| 8 | 20 Amp | Spare |
| 9 | | Police # 1 Relay |
| 10 | | Police # 2 Relay |
| 11 | | Police # 3 Relay |
| 12 | | |
SPECIFICATIONS - EXTERIOR
| LIGHT BULBS - Exterior (300, 300 Touring Models) | Bulb Number |
|---|
| Low Beam Headlamp | 9006 |
| High Beam Headlamp | 9005 |
| Front Park/Turn Lamp | 3157 |
| Front Inner Park Lamp | 194NA |
| Front Outer Park Lamp | 194NA |
| Front Fog Lamp-If Equipped | 9145/H10 (Serviced at Dealer) |
| Front Sidemarker | W5W (Serviced at Dealer) |
| Tail/Stop/Turn Lamp | 3057 |
| Rear Sidemarker | 194 |
| Backup Lamp | 3057 |
| Center High Mount Stop Lamp (CHMSL) | LED (Serviced at Authorized Dealer) |
| License | 168 |
| LIGHT BULBS - Exterior (300C Models) | Bulb Number |
|---|
| Low Beam Headlamp (Standard Halogen) | 9006XS |
| Low Beam Headlamp - High Intensity Discharge (HID) | D1S (Serviced at Dealer) |
| High Beam Headlamp | 9005 |
| Front Park/Turn Lamp | 3157AK |
| Front Fog Lamp | 9145/H10 (Serviced at Dealer) |
| Front Sidemarker | W5W (Serviced at Dealer) |
| Tail/Stop Lamp | 3057 |
| Tail Lamp | 3057 |
| Turn Signal Lamp | 3757A |
| Backup Lamp | 3057 |
| Center High Mount Stop Lamp (CHMSL) | LED (Serviced at Authorized Dealer) |
| Outside Mirror Turn Signal & Approach Lights | LED (Serviced at Authorized Dealer) |
| License | W5W |
SPECIFICATIONS - INTERIOR
| LIGHT BULBS - Interior | Bulb Number |
|---|
| Rear Courtesy/Reading Lights | W5W |
| Rear Compartment (Trunk) Light | 562 |
| Overhead Console Reading Lights | 578 |
| Visor Vanity Lights | A6220 |
| Glove Box Light | 194 |
| Door Courtesy | 562 |
| Shift Indicator Light | JKLE14140 |
Note. For lighted switches, see your dealer for replacement instructions.
All of the interior bulbs are glass wedge base or glass cartridge types. Aluminum base bulbs are not approved and should not be used for replacement.
In this service information, you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer, carefully review this information to tow your load as efficiently and safely as possible.
To maintain warranty coverage, follow the requirements and recommendations in this service information concerning vehicles used for trailer towing.
