SPECIFICATIONS - SPARK PLUGS

EngineSpark PlugElectrode GapThread Size
2.7LRE14PMC51.27 mm (0.050 in.)M14 X 1.25
3.5LZFR5LP-13G1.27 mm (0.050 in.)M14 X 1.25
5.7LREC14MCC41.01 mm (0.040 in.)M14 X 1.25
6.1LPLZTR5A-131.01 mm (0.040 in.)M14 X 1.25

SPECIFICATIONS - TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Camshaft Position Sensor (CMP) - 2.7/3.5L12106
Camshaft Position Sensor (CMP) - 5.7/6.1L12106
Crankshaft Position Sensor (CKP) - 2.7/3.5L12106
Crankshaft Position Sensor (CKP) - 5.7/6.1L12106
Ignition Coil Capacitor Nut 2.7L 1st1088.5
Ignition Coil Capacitor Bolt 2.7L 2nd2820.5
Ignition Coil Capacitor Nut 3.5L2820.5
Ignition Coil Mounting - 2.7L7.565
Ignition Coil Mounting - 3.5L871
Ignition Coil Mounting - 5.7/6.1L12106
Knock Sensor - 2.7L1088.5
Knock Sensor - 3.5L2015
* Knock Sensor - 5.7/6.1L2015
Spark Plugs - 2.7L17.513
Spark Plugs - 3.5L2720
Spark Plugs - 5.7/6.1L17.513
Negative Battery Cable Nut545
* Do not apply any sealant, thread-locker or adhesive to bolts. Poor sensor performance may result.

Scheme 15

Scheme 15: CAPACITOR - IGNITION COIL - 2.7L - 1ST
  1. Disconnect and isolate the negative battery cable.
  2. Disconnect the electrical connector.
  3. Remove nut and capacitor.

Scheme 16

Scheme 16: CAPACITOR - IGNITION COIL - 2.7L - 2ND

The ignition capacitor is located under the intake manifold on the drivers side of the engine.

  1. Disconnect and isolate negative battery cable at battery.
  2. Remove electrical connector (3).
  3. Remove mounting bolt (1) and ignition capacitor (2).

Scheme 17

Scheme 17: CAPACITOR - IGNITION COIL - 3.5L

The ignition capacitor is located on the drivers side of the engine.

  1. Disconnect and isolate negative battery cable at battery.
  2. Remove electrical connector (3).
  3. Remove mounting bolt (1) and ignition capacitor (2).

Scheme 18

Scheme 18: CAPACITOR - IGNITION COIL - 5.7/6.1L

The ignition capacitor (2) is attached to the left-rear corner of the intake manifold (3).

  1. Disconnect and isolate the negative battery cable.
  2. Remove electrical connector (1).
  3. Remove mounting bolt and remove capacitor (2).
