DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Diagnostic Test

1. CHECK FOR ACTIVE DTC NOTE: Make sure the Battery is in good condition. Using the Midtronics Battery Tester, test the Battery before continuing. NOTE: Inspect the vehicle for after market accessories that may exceed the Generator System output. NOTE: Make sure the generator drive belt is in good operating condition. NOTE: Inspect the fuses in the TIPM. If an open fuse is found, use the wire diagram/schematic as a guide, inspect the wiring and connectors for damage. NOTE: Check for active PCM DTCs. If any are found diagnose and repair the PCM DTC before proceeding with this test. Using the appropriate tester/voltmeter measure battery voltage. Battery voltage must be greater than 9 Volts. With the scan tool, erase DTC's. Turn the ignition on. With the scan tool, read active DTC's. Does the scan tool display this DTC as active? Yes Replace the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Check the above conditions that can cause a low voltage condition. Repair as necessary. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. CHECK FOR ACTIVE DTC NOTE: Make sure the Battery is in good condition. Using the Midtronics Battery Tester, test the Battery before continuing. NOTE: Inspect the vehicle for after market accessories that may exceed the Generator System output. NOTE: Make sure the generator drive belt is in good operating condition. NOTE: Inspect the fuses in the TIPM. If an open fuse is found, use the wire diagram/schematic as a guide, inspect the wiring and connectors for damage. NOTE: Check for active PCM DTCs. If any are found diagnose and repair the PCM DTC before proceeding with this test. Using the appropriate tester/voltmeter measure battery voltage. Battery voltage must be less than 16 Volts. With the scan tool, erase DTC's. Turn the ignition on. With the scan tool, read active DTC's. Does the scan tool display this DTC as active? Yes Replace the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Check the above conditions that can cause a high voltage condition. Repair as necessary. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on at least 5 times, leaving the ignition on for a minimum of 90 seconds per cycle. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
2. CONFIGURE THE TIPM TO THE VEHICLE With the scan tool enter program network configuration and program the TIPM to the vehicle configuration. With the scan tool, erase TIPM DTC's. Cycle the ignition switch from off to on at least 5 times, leaving the ignition on for a minimum of 90 seconds per cycle. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Repair is complete.

1. REPLACE THE TOTALLY INTEGRATED POWER MODULE IF DTC IS ACTIVE With the scan tool, read the active TIPM DTC's. Does the scan tool display this DTC as active? Yes Replace and program the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.

1. CHECK FOR ACTIVE DTC With the scan tool, read the active DTC's. Cycle the ignition switch from off to on at least 5 times, leaving the ignition on for a minimum of 90 seconds per cycle. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
2. CONFIGURE THE TIPM TO THE VEHICLE With the scan tool enter program network configuration and program the TIPM to the vehicle configuration. With the scan tool, erase TIPM DTC's. Cycle the ignition switch from off to on at least 5 times, leaving the ignition on for a minimum of 90 seconds per cycle. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Repair is complete.

Scheme 1

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article . Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE ECM/PCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the ECM/PCM is active on the bus. Is the ECM/PCM active on the bus? Yes Go To 4 . No Perform the appropriate No Response diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the ECM/PCM? Yes Replace/update the ECM/PCM in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article . Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE TCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the TCM is active on the bus. Is the TCM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM TCM - NAG1»(ref-304477-S27528684832008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the TCM? Yes Replace/update the TCM in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article . Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE SHIFTER LEVER ASSEMBLY (NAG 1 ONLY) OR IF APPLICABLE THE ELECTRONIC SHIFT MODULE (COLUMN NAG 1) IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the Shifter Lever Assembly (NAG 1 Only) or if applicable the Electronic Shift Module (Column NAG 1) is active on the bus. Is the Shifter Lever Assembly (NAG 1 Only) or if applicable the Electronic Shift Module (Column NAG 1) active on the bus? Yes Go To 4 . No Perform the appropriate No Response diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the Shifter Lever Assembly (NAG 1 Only) or if applicable the Electronic Shift Module (Column NAG 1)? Yes Replace/update the Shifter Lever Assembly (NAG 1 Only) or if applicable the Electronic Shift Module (Column NAG 1) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article . Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE ACC IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the ACC is active on the bus. Is the ACC active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM ACC»(ref-304477-S41772549742008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the ACC? Yes Replace/update the Cruise Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE ABS IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the ABS is active on the bus. Is the ABS active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM ABS»(ref-304477-S24699837132008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the ABS? Yes Replace/update the Antilock Brake Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE TIPM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the TIPM is active on the bus. Is the TIPM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM TIPM (TOTALLY INTEGRATED POWER MODULE)»(ref-304477-S25454868902008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the TIPM? Yes Replace/update the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE MPM (PTIM) IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the MPM (PTIM) is active on the bus. Is the MPM (PTIM) active on the bus? Yes Go To 4 . No Perform the appropriate No Response diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the MPM (PTIM)? Yes Replace/update the Multi-Purpose Module (PTIM) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE ORC IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the ORC is active on the bus. Is the ORC active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM ORC»(ref-304477-S18820241342008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the ORC? Yes Replace/update the Occupant Restraint Controller in accordance with the service information. Perform «*ORC VERIFICATION TEST - VER 1»(ref-304495-S34727557412008111000000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE CCN IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the CCN is active on the bus. Is the CCN active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM CCN»(ref-304477-S01486988512008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the CCN? Yes Replace/update the Cluster (CCN) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE EOM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the EOM is active on the bus. Is the EOM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM EOM»(ref-304477-S18499720642008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the EOM? Yes Replace/update the Electronic Overhead Module (EOM) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read all active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE PTS IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the PTS is active on the bus. Is the PTS active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM PTS (PARK ASSIST MODULE)»(ref-304477-S05638024102008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the PTS? Yes Replace/update the Park Assist Module (PTS) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE HVAC IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the HVAC is active on the bus. Is the HVAC active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM HVAC (ATC)»(ref-304477-S03317909262008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the HVAC? Yes Replace/update the A/C Heater Control in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set the DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. No Go To 3 .
3. VERIFY THAT THE ITM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the ITM is active on the bus. Is the ITM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM ITM (INTRUSION TRANSCEIVER MODULE)»(ref-304477-S23348327922008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the ITM? Yes Replace/update the Intrusion Transceiver Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set the DTC in accordance with the service information Perform the appropriate VERIFICATION TEST.

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE WCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the WCM is active on the bus. Is the WCM active on the bus? Yes Go To 4 . No Perform the appropriate No Response diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the WCM? Yes Replace/update the Sentry Key Remote Entry Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE SUNR IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the SUNR is active on the bus. Is the SUNR active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM SUNR (SUNROOF MOTOR/MODULE)»(ref-304477-S06883849922008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the SUNR? Yes Replace/update the Sunroof Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE HIDT IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the HIDT is active on the bus. Is the HIDT active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM HEADLAMP LEVELING MODULE (HIDT)»(ref-304477-S23063629082008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the HIDT? Yes Replace/update the Headlamp Leveling Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE RADIO IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the Radio is active on the bus. Is the Radio active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM RADIO»(ref-304477-S20628188802008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the Radio? Yes Replace/update the Radio in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE AMPLIFIER IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the Amplifier is active on the bus. Is the Amplifier active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM AMP»(ref-304477-S02017988672008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the Amplifier? Yes Replace/update the Amplifier in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

Scheme 2

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE VES IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the VES is active on the bus. Is the VES active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM VES (MONITOR/DVD MEDIA SYSTEM)»(ref-304477-S09091588532008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the VES? Yes Replace/update the Monitor/DVD Media System in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE HFM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the HFM is active on the bus. Is the HFM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM HFM»(ref-304477-S14046664042008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the HFM? Yes Replace/update the Hands Free Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE DDM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the DDM is active on the bus. Is the DDM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM DDM»(ref-304477-S06356821722008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the DDM? Yes Replace/update the Driver Door Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE PDM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the PDM is active on the bus. Is the PDM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM PDM»(ref-304477-S11036868732008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the PDM? Yes Replace/update the Passenger Door Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE DMFL IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the DMFL is active on the bus. Is the DMFL active on the bus? Yes Go To 4 . No Perform the appropriate No Response diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the DMFL? Yes Replace/update the Door Module Front Left in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE DMFR IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the DMFR is active on the bus. Is the DMFR active on the bus? Yes Go To 4 . No Perform the appropriate No Response diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the DMFR? Yes Replace/update the Door Module Front Right in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE HSM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the HSM is active on the bus. Is the HSM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM HSM»(ref-304477-S19497738932008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the HSM? Yes Replace/update the Heated Seat Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE MSMD IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the MSMD is active on the bus. Is the MSMD active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM MSMD»(ref-304477-S07608270852008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the MSMD? Yes Replace/update the Memory Seat Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE SCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the SCM is active on the bus. Is the SCM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM SCM»(ref-304477-S21896913612008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the SCM? Yes Replace/update the Steering Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE LRSM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the LRSM is active on the bus. Is the LRSM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM LRSM (RAIN SENSOR)»(ref-304477-S31328922322008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the LRSM? Yes Replace/update the Rain Sensor in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. No Go To 3 .
3. VERIFY THAT THE AHBM (SMART-BEAM) IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network View and select Advanced. Verify that the AHBM (SMART-BEAM) is active on the bus. Is the AHBM (SMART-BEAM) active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM AHBM (SMART-BEAM)»(ref-304477-S21963792202008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the AHBM (SMART-BEAM)? Yes Replace/update the Inside Rearview Mirror (AHBM) (SMART-BEAM) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform the appropriate VERIFICATION TEST.

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. No Go To 3 .
3. VERIFY THAT THE VES 2 IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network View and select Advanced. Verify that the VES 2 is active on the bus. Is the VES 2 active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM VES (MONITOR/DVD MEDIA SYSTEM)»(ref-304477-S09091588532008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the VES 2? Yes Replace/update the Vehicle Entertainment Control Module - Rear 2 (VES2) in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform the appropriate VERIFICATION TEST.

Scheme 3

1. CHECK FOR ACTIVE DTCS With the scan tool, read the active DTC's. Cycle the ignition switch from off to on at least 5 times, leaving the ignition on for a minimum of 90 seconds per cycle. With the scan tool, read the active DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No If the DTC is stored, check for an intermittent condition. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals.
2. CHECK TOTALLY INTEGRATED POWER MODULE FOR U0019 DTC With the scan tool, read Totally Integrated Power Module active DTC's Does the scan tool display this DTC as active? Yes Refer to DIAGNOSTIC CODE INDEX and perform «U0019-CAN B BUS»(ref-304477-S32723315232008111000000) diagnostic procedure. No Go To 3 .
3. (D55) CAN B BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the Totally Integrated Power Module C5 connector. Turn the ignition on. Measure the voltage of the (D55) CAN B Bus (+) circuit. Is any voltage present on this circuit? Yes Go To 4 . No Repair the (D55) CAN B Bus (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
4. (D54) CAN B BUS (-) CIRCUIT OPEN Measure the voltage of the (D54) CAN B Bus (-) circuit. Is any voltage present on this circuit? Yes Replace the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Repair the (D54) CAN B Bus (-) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. TEST FOR INTERMITTENT CONDITION NOTE: Check for, diagnose and repair other CAN C DTCs first before proceeding. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 2 . No The conditions that caused this code to set has been repaired or are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. ANTILOCK BRAKE MODULE - INTERNAL SHORT Turn the ignition off. Disconnect the Antilock Brake Module harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 3 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Antilock Brake Module in accordance with the service information. Perform «ABS VERIFICATION TEST»(ref-304475-S20609067312008111000000) .
3. POWERTRAIN CONTROL MODULE - INTERNAL SHORT Turn the ignition off. Disconnect the Powertrain Control Module C1 harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes, with Floor Shift Go To 4 . Yes, with Column Shift Go To 5 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Powertrain Control Module in accordance with the service information. Perform «*PCM VERIFICATION TEST»(ref-304545-S42850134272008111000000) .
4. SHIFTER LEVER ASSEMBLY (NAG1 ONLY)- INTERNAL SHORT Turn the ignition off. NOTE: If the vehicle is not equipped with a NAG1 controller then skip this step. Disconnect the Shifter Lever Assembly harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 6 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Shifter Lever Assembly in accordance with the service information. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(ref-304549-S36649155802008111000000) .
5. ELECTRONIC SHIFT MODULE (COLUMN NAG1)- INTERNAL SHORT Turn the ignition off. NOTE: If the vehicle is not equipped with a NAG1 controller then skip this step. Disconnect the Electronic Shift Module harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 6 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Electronic Shift Module in accordance with the service information. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(ref-304549-S36649155802008111000000) .
6. TRANSMISSION CONTROL MODULE (NAG1 ONLY)- INTERNAL SHORT Turn the ignition off. NOTE: If the vehicle is not equipped with a NAG1 controller then skip this step. Disconnect the Transmission Control Module C2 harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 7 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Transmission Control Module in accordance with the service information. Perform «NAG1 TRANSMISSION VERIFICATION TEST»(ref-304549-S36649155802008111000000) .
7. ENGINE CONTROL MODULE (DIESEL)- INTERNAL SHORT Turn the ignition off. Disconnect the Engine Control Module C2 harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 8 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Engine Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
8. STEERING CONTROL MODULE - INTERNAL SHORT Turn the ignition off. Disconnect the Steering Control Module (Steering Angle Sensor) harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 9 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Steering Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
9. WIRELESS CONTROL MODULE - INTERNAL SHORT Turn the ignition off. Disconnect the WCM harness connector. Turn the ignition on. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 10 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Wireless Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
10. OCCUPANT RESTRAINT CONTROLLER - INTERNAL SHORT Turn the ignition off. WARNING: To avoid serious or fatal injury, turn the ignition off, disconnect the battery and wait two minutes before proceeding. Disconnect the Occupant Restraint Controller Module harness connectors. WARNING: To avoid serious or fatal injury, turn the ignition on, then reconnect the battery. With the scan tool, record and erase TIPM DTC's. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read active TIPM DTC's. Does the scan tool display this DTC as active? Yes Go To 11 . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Occupant Restraint Controller in accordance with the service information. Perform «*ORC VERIFICATION TEST - VER 1»(ref-304495-S34727557412008111000000) .
11. (D65) CAN C BUS (+) CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect the Totally Integrated Power Module C1 harness connector. Turn the ignition on. Measure the voltage between the (D65) CAN C Bus (+) circuit and ground. Is there any voltage present? Yes Repair the (D65) CAN C Bus (+) circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 12 .
12. (D64) CAN C BUS (-) CIRCUIT SHORTED TO VOLTAGE Measure the voltage between the (D64) CAN C Bus (-) circuit and ground. Is there any voltage present? Yes Repair the (D64) CAN C Bus (-) circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 13 .
13. (D65) CAN C BUS (+) CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (D65) CAN C Bus (+) circuit. Is any resistance present? Yes Repair the (D65) CAN C Bus (+) circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 14 .
14. (D64) CAN C BUS (-) CIRCUIT SHORTED TO GROUND Measure the resistance between ground and the (D64) CAN C Bus (-) circuit. Is any resistance present? Yes Repair the (D64) CAN C Bus (-) circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 15 .
15. (D65) CAN C BUS (+) CIRCUIT SHORTED TO (D64) CAN C BUS (-) CIRCUIT Measure the resistance between the (D65) CAN C Bus (+) circuit and the (D64) CAN C Bus (-) circuit. Is any resistance present? Yes Repair the (D65) CAN C Bus (+) circuit for a short to the (D64) CAN C Bus (-) circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Inspect the wiring and connectors for damage or shorted circuits. If OK, replace and program the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. RECONFIGURE THE TOTALLY INTEGRATED POWER MODULE Turn the ignition on. With the scan tool, select network view and press the gateway button. This will list the CAN modules on the vehicle. Read and record the listed modules. With the scan tool, select TIPM, miscellaneous functions then add/remove ECUs. With the scan tool, add or remove the module that was not configured in the TIPM. With the scan tool, erase DTC's. Cycle the ignition from on to off 3 times and read the active TIPM DTC's. Does the scan tool display this DTC as active? Yes Retest system and attempt to reconfigure the TIPM. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Repair is complete. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN B or C hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 3 .
3. VERIFY THAT THE SCM IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select ECU View. Verify that the SCM is active on the bus. Is the SCM active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM SCM»(ref-304477-S21896913612008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the SCM? Yes Replace/update the Steering Control Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. REPROGRAM THE TOTALLY INTEGRATED POWER MODULE (TIPM) Turn the ignition on. With the scan tool, select network view and select the CAN C Bus network. This will list the CAN C Bus modules on the vehicle. Read and record the listed modules. With the scan tool, select TIPM, miscellaneous functions then add/remove ECUs. With the scan tool, add or remove the module that was not configured in the TIPM. With the scan tool, erase DTC's. Cycle the ignition from on to off 3 times and read the active TIPM DTC's. Does the scan tool display this DTC as active? Yes Retest system and attempt to reprogram the TIPM. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Repair is complete. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. VERIFY DTC IS ACTIVE NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read active DTCs. Is this DTC active? Yes Go To 2 . No Refer to the «*STORED LOST COMMUNICATION DTCS»(ref-304477-S11282446922008111000000) diagnostic procedure.
2. CHECK FOR ANY OF THE FOLLOWING ACTIVE DTCS With the scan tool, read active DTCs from all modules. NOTE: Check for TIPM configuration, CAN Interior Bus hardware electrical, VIN Missing/Mismatch, battery or ignition related DTCs. Does the scan tool display any active DTCs to the conditions listed above? Yes Diagnose and repair the DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article. No Go To 3 .
3. VERIFY THAT THE SDARV IS ACTIVE ON THE BUS Turn the ignition on. With the scan tool, select Network Diagnostics. Verify that the SDARV is active on the bus. Is the SDARV active on the bus? Yes Go To 4 . No Perform the «*NO RESPONSE FROM SDARV»(ref-304477-S32794281362008111000000) diagnostic procedure.
4. CHECK FOR ADDITIONAL COMMUNICATION RELATED DTCS With the scan tool, select Network Diagnostics. Is there more than one module with active DTCs "Logged Against" the SDARV? Yes Replace/update the Satellite Video Receiver in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 5 .
5. CLEAR DTC IN MODULE SETTING FAULT With the scan tool, select the module setting the DTC against the SDARV. Clear active DTCs. Is this DTC still active? Yes Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 6 .
6. CYCLE IGNITION Cycle the ignition from RUN to OFF three times ending with the key in the RUN position. Does this DTC become active? Yes Go To 7 . No The condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
7. CHECK FOR ADDITIONAL LOST COMMUNICATION FAULTS With the scan tool, select Network Diagnostics. Does the TIPM and other CAN Interior BUS (125K) modules show Lost Communication with the remaining CAN Interior BUS (125K) modules? Yes Go To 8 . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
8. (D265) CAN INTERIOR BUS(+) (125K) CIRCUIT SHORTED TO VOLTAGE Measure the voltage between the (D265) CAN Interior Bus(+) (125K) circuit and ground. Is the voltage above 5 volts? Yes Repair the (D265) CAN Interior Bus(+) (125K) circuit for a short to voltage. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To 9 .
9. (D264) CAN INTERIOR BUS(-) (125K) CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (D264) CAN Interior Bus(-) (125K) circuit. Is the resistance below 10K Ohms? Yes Repair the (D264) CAN Interior Bus(-) (125K) circuit for a short to ground. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace/update the module that set this DTC in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

Scheme 4

1. CHECK THE STATUS OF THE ERROR MESSAGE NOTE: Ensure the vehicle being tested is a CAN BUS VEHICLE. If not, false error messages may be displayed. NOTE: Ensure the scan tool is updated to the latest software. With the scan tool, record the error message. Disconnect the scan tool from the DLC. Cycle the ignition from on to off 3 times. Turn the ignition on. Does the scan tool display this same error message? Yes Go To step 2 . No The conditions that caused this error message to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. (D72) DIAGNOSTIC CAN C (+) CIRCUIT OPEN Turn the ignition off. Disconnect the Totally Integrated Power Module C6 harness connector. Disconnect the scan tool from the DLC. Measure the resistance of the (D72) Diagnostic CAN C (+) circuit between the TIPM connector and the DLC. Is the resistance below 5.0 ohms? Yes Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Repair the (D72) Diagnostic CAN C (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

1. CHECK THE STATUS OF THE ERROR MESSAGE NOTE: Ensure the vehicle being tested is a CAN BUS VEHICLE. If not, false error messages may be displayed. NOTE: Ensure the scan tool is updated to the latest software. With the scan tool, record the error message. Disconnect the scan tool from the DLC. Cycle the ignition from on to off 3 times. Turn the ignition on. Does the scan tool display this same error message? Yes Go To step 2 . No The conditions that caused this error message to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
2. (D71) DIAGNOSTIC CAN C (-) CIRCUIT OPEN Turn the ignition off. Disconnect the Totally Integrated Power Module C6 harness connector. Disconnect the scan tool from the DLC. Measure the resistance of the (D71) Diagnostic CAN C (-) circuit between the TIPM connector and the DLC. Is the resistance below 5.0 ohms? Yes Inspect the wiring and connectors for damage or shorted circuits. If OK, replace the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Repair the (D71) Diagnostic CAN C (-) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

Scheme 5

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. With the scan tool, select ECU View. NOTE: A red X will be next to the module that is not communicating, indicating that the module is not active on the Bus network. A green check indicates that the module is active on the Bus network. NOTE: Check the TIPM for any active CAN C hardware DTCs, perform appropriate DTC before proceeding. Does the scan tool display a red X next to the module? Yes Go To step 2 . No The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals.
2. ATTEMPT TO COMMUNICATE WITH THE PCM With the scan tool in ECU view, observe the status of the PCM. Does the scan tool display a red X next to the PCM? Yes Refer to the «*NO RESPONSE FROM PCM»(ref-304477-S40274915262008111000000) test procedure. No Go To step 3 .
3. (Z904) GROUND CIRCUIT OPEN Turn the ignition off. Disconnect the PCM C1 harness connector. CAUTION: Do not probe the PCM harness connectors. Probing the PCM harness connectors will damage the PCM terminals resulting in poor terminal to pin connection. Install Miller Special Tool #8815 to perform diagnosis. Using a 12-volt test light connected to 12-volts, check each (Z904) ground circuit. Does the test light illuminate brightly for each circuit? Yes Replace and program the Powertrain Control Module in accordance with the service information. No Repair the (Z904) ground circuit for an open. Perform the appropriate TRANSMISSION VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10.0 and 16.0 volts. NOTE: Ensure the scan tool is updated to the latest software. NOTE: If the scan tool displays any error messages involving the Diagnostic CAN C circuits, diagnose and repair the error message before proceeding. NOTE: A loss of communication with the TIPM can cause the ECU View button on the scan tool to be inoperative (not highlighted). With the scan tool, attempt to select ECU View. Can the scan tool communicate with the TIPM? Yes The no response condition is not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals. No Go To step 2 .
2. FUSED B (+) CIRCUITS OPEN AT TIPM Disconnect the scan tool from the DLC. Using a 12-volt test light connected to ground, and using the wiring diagram as a guide, check all Fused B (+) circuits at the TIPM. Does the test light illuminate brightly for each circuit? Yes Go To step 3 . No Repair the Fused B(+) circuit for an open or short. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
3. FUSED IGNITION SWITCH OUTPUT CIRCUITS OPEN AT TIPM Turn the ignition on. Using a 12-volt test light connected to ground, and using the wiring diagram as a guide, check each Fused Ignition Switch Output circuit at the TIPM. Does the test light illuminate brightly for each circuit? Yes Go To step 4 . No Repair the Fused Ignition Switch Output circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
4. GROUND CIRCUITS OPEN AT TIPM Turn the ignition off. Using a 12-volt test light connected to 12-volts, and using the wiring diagram as a guide, check all ground circuits at the TIPM. Does the test light illuminate brightly on each circuit? Yes Go To step 5 . No Repair the ground circuit that did not light the test light for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
5. CHECK FOR (D52) DIAGNOSTIC CAN C (+) CIRCUIT OPEN AT DLC Disconnect the TIPM C3 harness connector. Measure the resistance on the (D52) Diagnostic CAN C (+) circuit between the TIPM C3 harness connector and the DLC. Is the resistance above 10.0 ohms? Yes Repair the (D52) Diagnostic CAN C (+) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To step 6 .
6. CHECK FOR (D51) DIAGNOSTIC CAN C (-) CIRCUIT OPEN AT DLC Measure the resistance on the (D51) Diagnostic CAN C (-) circuit between the TIPM C3 harness connector and the DLC. Is the resistance above 10.0 ohms? Yes Repair the (D51) Diagnostic CAN C (-) circuit for an open. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To step 7 .
7. CHECK FOR DIAGNOSTIC CAN C CIRCUITS SHORTED TOGETHER Measure the resistance between the (D52) Diagnostic CAN C (+) circuit and the (D51) Diagnostic CAN C (-) circuit at the TIPM C3 harness connector. Is the resistance below 100.0 ohms? Yes Repair the (D52) Diagnostic CAN C (+) circuit for a short to the (D51) Diagnostic CAN C (-) circuit. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Replace the Totally Integrated Power Module in accordance with the service information. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .

Scheme 6

1. VERIFY DTC IS STORED NOTE: Stored faults may indicate a customer perceived intermittent condition. NOTE: Ensure the IOD fuse is installed and battery voltage is between 10 and 16 volts before proceeding. With the scan tool, read stored DTCs. Is this DTC stored? Yes Go To step 2 . No Diagnose the active DTC. Refer to appropriate ELECTRICAL DIAGNOSTICS article Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) .
2. CHECK THE ENVIRONMENTAL DATA With the scan tool, read the loss of communication environmental data. Does the loss of communication environmental odometer data match up to any of the previous service procedures listed in the possible causes or are there any stored CAN B or C hardware electrical, battery, ignition voltage, VIN missing/mismatch, TIPM configuration DTCs present with match environmental data? Yes These DTCs may have been the result of other service procedures performed. Clear DTCs. Perform «BODY VERIFICATION TEST - VER 1»(ref-304477-S32224544052008111000000) . No Go To step 3 .
3. VERIFY INTERMITTENT LOST COMMUNICATION DTC-WIRING CONCERNS Turn the ignition on. With the scan tool, select Network View and select Advanced. Is there more than one ECU with stored DTCs "Logged Against" the module and one or more lost communication DTCs stored in the offending module? Yes Verify if the vehicle was recently in for this type of service. Otherwise, visually inspect the related wiring harness for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals. Repair as necessary. No Go To step 4 .
4. VERIFY INTERMITTENT LOST COMMUNICATION DTC-OFFENDING MODULE Turn the ignition on. With the scan tool, select Network View and select Advanced. Is there more than one ECU with stored DTCs "Logged Against" the module and NO lost communication DTCs stored in the offending module? Yes Check for TSB related to this offending module. No Go To step 5 .
5. VERIFY INTERMITTENT LOST COMMUNICATION DTC-REPORTING MODULE Turn the ignition on. With the scan tool, select Network View and select Advanced. Is there ONLY ONE ECU with stored DTCs "Logged Against" the module? Yes Check for TSB related to the module that set this DTC. No Verify if the vehicle was recently in for this type of service. Otherwise, visually inspect the related wiring harness for chafed, pierced, pinched, and partially broken wires and the wiring harness connectors for broken, bent, pushed out, and corroded terminals. Repair as necessary.

1. Perform Body Verification Test Disconnect all jumper wires and reconnect all previously disconnected components and connectors. Ensure that all accessories are turned off. Ensure that the battery is fully charged. If the battery was disconnected for any reason, refer to «STANDARD PROCEDURE»(ref-304460-S38978467932008111000000) for accessory calibration procedures. If the TIPM has been replaced, the Pinion Factor MUST be programmed into the TIPM. Refer to the scan tool for program procedure. Turn the ignition on. With the scan tool, record and erase DTCs from all modules. (Export only) If the Intrusion Transceiver Module (ITM) and/or Siren was replaced, select ITM from the from the scan tool ECU view menu then "Misc. Functions" and perform the applicable replacement procedure. If the vehicle is equipped with Express Up Power Windows and the battery was disconnected during repairs, run both front windows all the way down. Next, run the window all the way up and hold the switch in the up position for five seconds to re-initialize the express up feature. Perform this step only if diagnosing faults related to the HVAC system. The Manual Temperature Control (MTC) is not on the Bus and not addressed with a scan tool. Perform the following to clear DTCs from the MTC: 1. Turn the blower control on. 2. Press the A/C mode switch down, turn the blower control to off, wait until both LEDs illuminate (approximately 5 seconds) and then release the A/C mode switch. 3. When the A/C status indicator begins flashing DTCs, set the Mode switch to the floor position, simultaneously press the A/C mode switch and the EBL mode switch down until both LEDs start flashing (approximately 5 seconds) and then release the mode switches. For vehicles equipped with Automatic Temperature Control (ATC), if repairs were made to any of the HVAC doors, linkage, door actuators, or door actuator circuits, run the actuator calibration function by selecting the following from the scan tool menu: select HVAC, More Options, System Tests, Actuator Calibration Test, and Start. Follow the directions displayed by the scan tool. Allow the test to run to completion before proceeding. For vehicles equipped with MTC, if repairs were made to any of the HVAC doors, linkage, door actuators, or door actuator circuits, run the door calibration function by performing the following: 1. Turn the ignition on. 2. Turn the blower control to off. 3. Press the EBL mode switch down, turn the blower control on, wait until the EBL LED starts flashing (approximately 5 seconds) and then release the mode switch. Wait approximately 90 seconds for the calibration process to run to completion before proceeding. Turn the ignition off, wait 10 seconds, and then turn the ignition on. Operate all functions of the system that caused the original concern. If a repair or module replacement was done to the power windows, operate the motor fully down and then to the full up position and stall it for 2 seconds. With the scan tool, select ECU View and check for DTCs in the modules. Perform this step only if diagnosing faults related to the MTC HVAC system. NOTE: The A/C status indicator displays active DTCs when the EBL status indictor is not illuminated and stored DTCs when the EBL status indicator is illuminated. Perform the following to read DTCs from the MTC: 1. Turn the blower control on. 2. Press the A/C mode switch down, turn the blower control to off, wait until both LEDs illuminate (approximately 5 seconds) and then release the A/C mode switch. 3. Read the DTCs from the flashing A/C status indicator. Are DTCs present in any of the modules or is the original condition still present? Yes The repair is not complete. Refer to the «DIAGNOSTIC CODE INDEX»(ref-304477-S34318650902008111000000) for the DTC or symptom that is still present. No The repair is complete.
