Power door locks — Power door locks circuit Dodge Journey I

Components on these wiring diagrams 34

Click a component to highlight it on every diagram it appears on.

• Circuit Breaker
• Driver Door Latch
• Driver Window/ Door Lock Switch
• Drv Dr Ajar Sw Sns
• Drv Dr Lck Drv
• Drv Dr Lk Sw Mux
• Drv Dr Unlk Drv
• Early Production
• Fused B
• Ground
• Hood Ajar Sw Sns
• Hood Ajar Switch
• Lift Gate Ajar Sw Sen
• Lift Gate Lk Drv
• Liftgate Door Latch
• Lr Dr Ajar Sw Sns
• Lr Dr Lck Drv
• Lr Dr Unlk Drv
• Pass Dr Ajar Sw Sns
• Pass Dr Lck Drv
• Pass Dr Lk Sw Mux
• Pass Dr Unlk Drv
• Passenger Door Latch
• Passenger Door Module
• Passenger Window/ Door Lock Switch
• Rr Dr Ajar Sw Sns
• Rr Dr Lck Drv
• Rr Dr Unlk Drv
• Run/Acc Rly Out
• Steering Column Lock Module
• Sw Return
• Sw Return Pass Dr Lk Sw Mux
• Totally Integrated Power Module Electronics
• Wireless Ignition Mode
