Wiring diagram: Body control modules — Body control modules circuit Dodge Journey I

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• A/C Clutch Ctrl Backup Lamp Sw Sig
• A/C Press Trans Sig
• Accessory Rly Out Fused B
• Asd/Main Rly Ctrl
• Battery
• Can C Bus Can C Bus A/C Press Sens Gnd
• Can C Bus Can C Bus Ignition Run-Start Out Rear Wiper Park Sw Sen
• Computer Data Lines System Navigation, Sound Systems
• Diagnostic Can C Diagnostic Can C
• Fuel Level Signal 2 Driver Seat Belt Sw Sen
• Fuse Asd/Main Rly Out
• Fuse Run/St Rly Out
• Fused B
• Fused B Blower Motor Sply Accessory Rly Out
• Fused B Fused B2
• Fused B Fused B Fused B
• Fused B Gnd
• Fused Run Rly Out Fused B Accessory Rly Out
• Fused Run/St Rly Out
• Fused Starter Rly Out Fused B
• Hood Ajar Sw Sen
• Ign Unlk-Run-St Out A/C Clutch Ctrl Out
• Inverter Sw Sig
• Left High Beam Drv Right Low Beam Drv Rf Side Mark Lp Drv Left Hdlp Rtn Sig
• Lr Door Lck Drv Fused Run Rly Out Rr Dr Lck Drv Fused B
• Rf Fog Lamp Ctrl
• Rr Door Ajar Sw Sen Liftgate Ajar Sw Sen Lf Door Ajar Sw Sen
• Sensor Ground Aat Signal Left Front Fog Lamp Ctrl
• Starter Rly Ctrl
• Switch Return
• Totally Integrated Power Module2
• Transmission Ctrl A/C Press Sens Sply
• Transmission Ctrl Out
