Ignition Control - Service Information: Specifications Dodge Journey I

Ignition System 4 illustrations ~123 words

TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
2.4 Camshaft Sensor Screw979.5
2.7, 3.5L Camshaft Sensor Screw12106
2.4L Ignition Coil Bolts979.5
2.7L Ignition Coil Bolts7.565
2.4L Spark Plugs2720
2.7L Spark Plugs1813
3.5L Spark Plugs2720
Knock Sensor 2.4, 2.7L107
Knock Sensor 3.5L2015
Ignition Coil Capacitor Bolt 2.4, 2.7L1088.5
Ignition Coil Capacitor Bolt 3.5L2820.5
Transmission Mounting Bolt6145

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: 2.4L
Scheme 1: 2.4L
1 - Bolt
2 - Capacitor
3 - Connector
  1. Disconnect and isolate negative battery cable at battery.
  2. Remove engine cover.
  3. Remove electrical connector (3).
  4. Remove mounting bolt (1) and ignition capacitor (2).

Scheme 2

Scheme 2: 2.7L 1st
Scheme 2: 2.7L 1st
  1. Disconnect and isolate the negative battery cable.
  2. Disconnect the electrical connector.
  3. Remove nut and capacitor.

Scheme 3

Scheme 3: 2.7L 2nd
Scheme 3: 2.7L 2nd

The ignition capacitor is located under the intake manifold on the drivers side of the engine.

  1. Disconnect and isolate negative battery cable at battery.
  2. Remove electrical connector (3).
  3. Remove mounting bolt (1) and ignition capacitor (2).

Scheme 4

Scheme 4: 3.5L
Scheme 4: 3.5L

The ignition capacitor is located on the drivers side of the engine.

  1. Disconnect and isolate negative battery cable at battery.
  2. Remove electrical connector (3).
  3. Remove mounting bolt (1) and ignition capacitor (2).
