TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Battery Hold-Down Bolt | 10 (13.5) |
| Exhaust Gas Recirculation Valve System Fasteners | 17 (23) |
| Generator Mounting Bolts & Nuts (8 mm) | 30 (41) |
| Generator Mounting Bolts & Nuts (10 mm) | 40 (54.0) |
| Intake Manifold Plenum Bolts | 14 (19) |
| INCH Lbs. (N.m) |
| Generator BAT Terminal Nut | 75 (8.5) |
| Negative Battery Terminal Nut | 90 (10) |
Charging System Wiring Diagram (Avenger & Sebring Coupe). Scheme 1
Scheme 1: Charging System Wiring Diagram (Avenger & Sebring Coupe)
Charging System Wiring Diagram (Breeze, Cirrus & Stratus). Scheme 2
Scheme 2: Charging System Wiring Diagram (Breeze, Cirrus & Stratus)
Charging System Wiring Diagram (Concorde, Intrepid, LHS & 300M). Scheme 3
Scheme 3: Charging System Wiring Diagram (Concorde, Intrepid, LHS & 300M)
Charging System Wiring Diagram (Neon). Scheme 4
Scheme 4: Charging System Wiring Diagram (Neon)
