SPECIFICATIONS
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Air Line Fitting to Spring And Shock Assembly (With SER) | 5.5 | 49 | |
| Shock Absorber Upper Nuts | 28 | 21 | |
| Shock upper Mounting Nut | 50 | 37 | |
| Clevis Bracket to Lower Control Arm | 235 | 173 | |
| Upper Control Arm Bolt/Nut to Body | 95 | 70 | |
| Lower Control Arm Rear Pivot Vertical Bolt/Nut | 220 | 162 | |
| Lower Control Arm Rear Pivot Horizontal Bolt/Nut | 90 | 66 | |
| Lower Control Arm Front Pivot Bolt/Nut | 120 | 89 | |
| Upper Ball Joint Nut | 95 | 70 | |
| Lower Ball Joint Nut | 230 | 170 | |
| Stabilizer Bar Retainer Bolts | 122 | 90 | |
| Stabilizer Bar Link Upper Nut | 122 | 90 | |
| Stabilizer Bar Link Lower Bolt | 122 | 90 | |
| Tie Rod End Ball Stud Nut | 95 | 70 | |
| Half Shaft Nut | 310 | 229 | |
| Intermediate Shaft Pinch Bolt | 45 | 33 | |
| Hub Bearing Knuckle Bolts | 105 | 78 | |
| Brake Caliper Slide Bolts (Guide Pins) | 55 | 41 | |
| Brake Caliper Adapter Bolts | 200 | 148 | |
| Speed Sensor Bolts | 10.7 | 95 |
TORQUE
Scheme 1
- Raise and support the vehicle. Refer to «HOISTING, STANDARD PROCEDURE»(ref-465919-S07448334682012042300000) .
- Remove the tire and wheel assembly.
- Remove the knuckle. Refer to «KNUCKLE, STEERING, REMOVAL»(ref-465917-S12296124132012042300000) .
- Remove the stabilizer link (7) to lower control arm nut. NOTE: If equipped with four wheel drive, support the half shaft or remove with the lower control arm.
- Remove the shock clevis bracket to lower control arm nut/bolt (6).
- Remove the lower control arm front pivot nut and bolt (4) from the lower control arm (3).
- Remove the lower control arm rear pivot vertical bolt and nut (1) and the lower control arm rear pivot horizontal bolt and nut (2) from the lower control arm (3) and remove from the vehicle.
