Frame and Bumpers: Component Locations Dodge Durango III

Frames, Subframes & Crossmembers 6 illustrations ~305 words

SPECIAL TOOLS

6602 - Remover/Installer, Bushing 6602-2 - Remover/Installer, Bushing 8173-3 - Remover/Installer (Originally Shipped In Kit Number(s) 8180CC, 8263CC.) 8244 - Puller, Extension Housing (Originally Shipped In Kit Number(s) 8295CC.) 8534B - Support Fixture, Engine (Originally Shipped In Kit Number(s) 8534, 8534B, 8849, 9565.) 8838-2 - Screw Assembly (Originally Shipped In Kit Number(s) 8696, 8696CC, 8710, 8710CC, 8715.) 9031-7A - Installer, Bushing (Originally Shipped In Kit Number(s) 9074, 9076, 9090, 9329-SUP, 9396, 9515-SUP, 9516-SUP, 9517-SUP, 9518, 9519, 9540-SUP, 9541-SUP.) 9520-1 - Installer Disc (Originally Shipped In Kit Number(s) 9329, 9329-SUP, 9515-SUP, 9516, 9516-SUP, 9517-SUP, 9518, 9519, 9540-SUP, 9541-SUP.) 9520-4 - Cup, Receiver (Originally Shipped In Kit Number(s) 9329, 9329-SUP, 9515-SUP, 9516, 9516-SUP, 9517-SUP, 9518, 9519, 9540-SUP, 9541-SUP.) C-4150A - Press, Ball Joint (Originally Shipped In Kit Number(s) 6672, 6745.) C-4212F - Press, Ball Joint (Originally Shipped In Kit Number(s) 6745, 6880, 6881, MLR-C03.) C-4755 - Trim Stick (Originally Shipped In Kit Number(s) 9299, 9299CC, 9299CC, 9300A-CAN.)

Scheme 42

Scheme 42: SPECIAL TOOLS
Scheme 42: SPECIAL TOOLS

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46: REMOVAL
Scheme 46: REMOVAL

Scheme 47

Scheme 47
Scheme 47
  1. Disconnect and isolate the negative battery cable.
  2. Remove the radiator grille assembly. Refer to «GRILLE , REMOVAL»(ref-465921-S35029314672012042300000) .
  3. Remove the fasteners (5) that secure the hood latch assembly and the upper radiator support cross bracing.
  4. Remove both the side plastic air deflectors (1).
  5. Release the clips and position aside the power steering cooler assembly, if equipped.
  6. Release the clips securing the headlamp electrical harness and position the harness aside.
  7. Remove the push-pin type retainers (2) and remove the front bumper isolator pad (1).
  8. Remove the four bolts (4) securing the bumper beam to the vehicle frame
  9. Remove the outer two fasteners (3) that secure the bumper beam to the radiator closure panel and remove the beam (2).
  10. Remove the cross bracing from the bumper beam and any miscellaneous parts as needed.
