Power Distribution: Removal & Installation Dodge Durango III

INSTALLATION

1. Slide the power inverter module (3) into the bracket.
2. Connect the electrical connector (1).
3. Install the two retainers (2).
4. Install the passenger side front seat Refer to «SEAT, FRONT, INSTALLATION»(ref-465921-S27937834052012042300000) .
5. Connect the negative battery cable.

1. Connect the wire connector (1) to the power outlet receptacle (2).
2. Install the power outlet mount into the panel.
3. Align the splines on the outside of the power outlet receptacle base connector receptacle with the grooves on the inside of the mount.
4. Press firmly on the power outlet receptacle base until the retaining bosses of the mount are fully engaged in their receptacles.
5. Connect the battery negative cable.

Scheme 11

The 115 Volt AC outlet (3) is mounted in the rear of the center floor console (2). The vehicle is able to supply 115 Volt AC power through the use of a inverter module. The inverter module is located under the right rear seat cushion. The inverter converts the 12 Volt DC from the vehicle battery system to a 115 Volt AC output.

Scheme 12

The inverter module provides A/C power for user accessories when the 115 Volt AC outlet switch (4) in the instrument panel center stack is in the "ON" position. The outlet switch is part of the instrument panel upper switch pod assembly and is not available for service as an individual part. If the switch is damaged or inoperative the complete upper switch pod assembly must be replaced, for the appropriate procedure. Refer to POD, SWITCH, REMOVAL .

1. Insert the 115v outlet into the panel.
2. Connect the electrical connector (1) to the 115v power outlet (2).
3. Install the duct to the trim panel.
4. Install the rear console trim panel.
5. Connect the negative battery cable.
