FASTENER TORQUE
| Description | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| All Screws NOT Listed Below | 2 | 17 | |
| A/C Compressor to Engine | Specific fastener placement and torque pattern required. Refer to COMPRESSOR, A/C, INSTALLATION . | ||
| A/C Expansion Valve Bolts (Front and Rear) | 11 | 97 | |
| Air Distribution Housing Screws | 2.2 | 20 | |
| Air Distribution Housing to HVAC Housing Screws | 2.2 | 20 | |
| Air Inlet Housing to HVAC Housing Screws | 2.2 | 20 | |
| A/C Pressure Transducer | 5.1 | 45 | |
| Blower Motor Screws (Front and Rear) | 2.2 | 20 | |
| Compressor Shaft Bolt | 19 | 168 | |
| Flange to Housing Screw (Front and Rear) | 2.2 | 20 | |
| Heater Core Bracket Screw (Front) | 2.2 | 20 | |
| Heater Core Tube to Heater Core Clamp Screws (Front) | 1.7 | 15 | |
| Heater Core Tube Bracket Screw (Front) | 2.2 | 20 | |
| HVAC Air inlet Duct to Dash Panel Nuts | 4.5 | 40 | |
| HVAC Housing Screws | 2.2 | 20 | |
| HVAC Housing to Dash Panel Nuts | 4.5 | 40 | |
| HVAC Housing to Instrument Panel Nuts | 4.5 | 40 | |
| Rear Heater-A/C Housing to Body Bolts | 3 | 26 | |
| Rear Heater-A/C Housing Screws | 2.2 | 20 | |
| Refrigerant Line to A/C Compressor Nut | 20 | 15 | |
| Refrigerant Lines to A/C Condenser Nut | 20 | 15 | |
| Refrigerant Lines to A/C Expansion Valve Nut (Front and Rear) | 20 | 15 | |
| Refrigerant Line to Refrigerant Line Nut (Front and Rear) | 20 | 15 | |
SPECIFICATIONS
| Application | Capacity |
|---|---|
| Front A/C Only | 623.7g (1.38 lbs.) |
| Front and Rear A/C | 921.4g (2.03 lbs.) |
REFRIGERANT CHARGE CAPACITY
Scheme 1
The A/C expansion valve controls the amount of refrigerant entering the A/C evaporator and is of a thermostatic expansion valve (TXV) design. The A/C expansion valve consists of an aluminum H-valve type body (1) with an integral thermal sensor (2) and is located at the dash panel between the A/C refrigerant lines and the A/C evaporator.
