INTERIOR FUSES
The fuse block contains blade-type mini-fuses, relays, and circuit breakers for high-current circuits. It is located in the left kick panel. It is accessible through a snap-in cover.
| Cavity | Mini Fuse/Color | Description |
|---|---|---|
| F1 | 15 Amp Blue | Instrument Cluster Battery Feed |
| F 2 | 10 Amp Red | Spare |
| F3 | 10 Amp Red | Ignition Run/Start for Next Generation Controller (NGC), Integrated Power Module (IPM), AC Relay and Fuel Pump Relay |
| F4 | 10 Amp Red | Door Node and Non-Memory Power Mirror Switch Battery Feed |
| F5 | (2) 10 Amp Red | Airbags (2 Fuses in Yellow Holder) |
| F6 | 2 Amp Clear | Ignition Run/Start Unlock |
| F7 | 25 Amp Natural | Radio Battery Feed |
| F8 | 10 Amp Red | Ignition Run/Start for Cluster/Transfer Case/Seat Sw. Back lighting |
| F9 | 10 Amp Red | Satellite Digital Audio Receiver (SDAR)/Digital Video Disc (DVD) Battery Feed |
| F10 | 10 Amp Red | Spare |
| F11 | 10 Amp Red | Heated Mirrors |
| F12 | 20 Amp Yellow | Cluster Battery Feed |
| F13 | 10 Amp Red | Ignition Run HVAC Module/Heated Rear Glass (EBL) Relay |
| F14 | 10 Amp Red | ABS Module Ignition Run |
| F15 | 15 Amp Blue | Battery Feed Blue Tooth, Compass/Trip Computer (CMTC), Sentry Key Diagnostics |
| F16 | 20 Amp Yellow | Reconfigurable Power Outlets |
| F17 | 20 Amp Yellow | Ignition Run / Rear Park Assist / Second Row Heated Seats |
| F18 | 20 Amp Yellow | Cigar Lighter Ignition |
| F19 | 10 Amp Red | Spare Fuse |
| F20 | 15 Amp Blue | Heating & Air Conditioning w/ATC Only Battery Feed |
| F21 | 25 Amp Natural | Amplifier Battery Feed |
FUSES (INTERIOR)
UNDERHOOD FUSES (POWER DISTRIBUTION CENTER)
Your vehicle is equipped with an electrical power distribution center located in the left side of the engine compartment.
This center contains cartridge fuses, mini fuses and relays. A description of each fuse and component may be stamped on the inside cover otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart. These fuses and relays can be obtained from your dealer.
| Cavity | Cartridge Fuse / Relay | Mini Fuse | Description |
|---|---|---|---|
| 1 | 30 Amp Pink | Starter | |
| 2 | 30 Amp Pink | Front Wiper | |
| 3 | 40 Amp Green | Brake Batt | |
| 4 | 30 Amp Pink | JB Feed Acc # 2 | |
| 5 | 40 Amp Green | Power Seats | |
| 6 | 30 Amp Pink | Run Remote Relay Feed | |
| 7 | 40 Amp Green | Blower Motor Relay Feed | |
| 8 | 40 Amp Green | JB Feed Acc Delay | |
| 9 | Spare | ||
| 10 | 30 Amp Pink | ASD | |
| 11 | 40 Amp Green | Power Liftgate ( If Equipped) | |
| 12 | 40 Amp Green | JB Feed / Heated Rear Glass (EBL)/ T Case Brake | |
| 13 | 30 Amp Pink | JB Feed RR | |
| 14 | 40 Amp Green | ESP Pump | |
| 15 | 50 Amp Red | JB Feed | |
| 16 | 10 Amp Red | Spare | |
| 17 | Spare | ||
| 18 | 20 Amp Yellow | Fuel Pump | |
| 19 | 20 Amp Yellow | Next Generation Controller (NGC) | |
| 20 | 25 Amp Clear | 115v Power Inverter | |
| 21 | 20 Amp Yellow | ABS Batt | |
| 22 | 20 Amp Yellow | Next Generation Controller (NGC) Batt | |
| 23 | 20 Amp Yellow | Trailer Tow | |
| 24 | 15 Amp Blue | A/C Clutch | |
| 25 | 15 Amp Blue | Stop Lamp Switch | |
| 26 | Spare | ||
| 27 | 20 Amp Yellow | Run/Start Relay Feed | |
| 28 | Spare | ||
| 29 | Relay | Run Start | |
| 30 | Relay | Run Remote | |
| 31 | Spare | ||
| 32 | Relay | Starter | |
| 33 | Relay | Electronic Automatic Transaxle (EATX) | |
| 34 | Relay | AC Clutch | |
| 35 | Relay | Fuel Pump Rly | |
| 36 | Spare | ||
| 37 | Relay | Stop Lamp Switch | |
| 38 | Spare | ||
| 39 | Relay | Blower Motor | |
| 40 | Relay | Auto Shut Down (ASD) Rly |
UNDERHOOD FUSES (INTEGRATED POWER MODULE)
An integrated Power Module is located in the left side of the engine compartment. This center contains cartridge fuses, mini fuses and relays. A description of each fuse and component may be stamped on the inside cover otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
| Cavity | Cartridge Fuse / Relay | Mini Fuse | Description |
|---|---|---|---|
| 1 | Relay | Wiper On/Off Rly | |
| 2 | Relay | Wiper Hi/Lo Rly | |
| 3 | Relay | Horn Rly | |
| 4 | Relay | Rear Wiper Rly | |
| 5 | Relay | Lt Trailer-Tow Stop/Turn Rly | |
| 6 | Relay | Rt Trailer-Tow Stop/Turn Rly | |
| 7 | Relay | Park Lamps Rly | |
| 8 | 10 Amp Red | Lt Park Lamps | |
| 9 | 10 Amp Red | Trailer-Tow Park Lamps | |
| 10 | 10 Amp Red | Rt Park Lamps | |
| 11 | Relay | Radiator Fan Hi Rly | |
| 12 | 20 Amp Yellow | Front Control Module (FCM) Batt #4 | |
| 13 | 20 Amp Yellow | Front Control Module (FCM) Batt #2 | |
| 14 | 20 Amp Yellow | Adjustable Pedal | |
| 15 | 20 Amp Yellow | Ft Fog Lamps | |
| 16 | 20 Amp Yellow | Horn | |
| 17 | 20 Amp Yellow | Rear Wiper | |
| 18 | 20 Amp Yellow | Front Control Module (FCM) Batt #1 | |
| 19 | 20 Amp Yellow | Lt Trailer-Tow Stop/Turn | |
| 20 | 20 Amp Yellow | Front Control Module (FCM) Batt #3 | |
| 21 | 20 Amp Yellow | Rt Trailer-Tow Stop/Turn | |
| 22 | 30 Amp Pink | Front Control Module (FCM) BATT # 5 | |
| 23 | 40 Amp Green | Radiator Fan | |
| 24 | Relay | Radiator Fan Lo Rly | |
| 25 | Relay | Ft Fog Lamps Rly | |
| 26 | Relay | Adjustable Pedal Rly | |
| 27 | 30 Amp Green | Ignition Off Draw (IOD) #1 | |
| 28 | 30 Amp Green | Ignition Off Draw (IOD) #2 | |
| 29 | Spare | ||
| 30 | Spare |
SCHEDULE "B"
Follow schedule "B" if you usually operate your vehicle under one or more of the following conditions.
- Day or night temperatures are below 0° C (32° F).
- Stop and go driving.
- Extensive engine idling.
- Driving in dusty conditions.
- Short trips of less than 16 km (10 miles).
- More than 50% of your driving is at sustained high speeds during hot weather, above 32° C (90° F).
- Trailer towing.
- Taxi, police, or delivery service (commercial service).
- Off-road or desert operation.
- If equipped for and operating with E-85 (ethanol) fuel.
Note. If ANY of these apply to you then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first and follow schedule "B" of the "Maintenance Schedules".
Note. If ANY of these apply to you then change your coolant every 102,000 miles (175 000 km) or 60 months, whichever comes first and follow schedule "B" of the "Maintenance Schedules".
| Miles | 3,000 | 6,000 | 9,000 | 12,000 | 15,000 |
|---|---|---|---|---|---|
| (Kilometers) | (5 000) | (10 000) | (15 000) | (20 000) | (25 000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X |
| Miles | 18,000 | 21,000 | 24,000 | 27,000 | 30,000 |
|---|---|---|---|---|---|
| (Kilometers) | (30 000) | (35 000) | (40 000) | (45 000) | (50 000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Check transfer case fluid level (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary.* | X |
| Miles | 33,000 | 36,000 | 39, 000 | 42,000 | 45,000 |
|---|---|---|---|---|---|
| (Kilometers) | (55 000) | (60 000) | (65 000) | (70 000) | (75 000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X |
| Miles | 48,000 | 51,000 | 54,000 | 57,000 | 60,000 |
|---|---|---|---|---|---|
| (Kilometers) | (80 000) | (85 000) | (90 000) | (95 000) | (100 000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary.* | X | ||||
| Inspect auto tension drive belt and replace if required. | X | ||||
| Drain and refill automatic transmission fluid, change filter (3.7L). This applies only if your vehicle is used for police, taxi, fleet, or frequent trailer towing. | X | ||||
| Drain and refill automatic transmission fluid and change main sump filter (4.7L/5.7L only). This applies only if your vehicle is used for police, taxi, fleet, or frequent trailer towing. | X | ||||
| Check transfer case fluid (4X4). | X | ||||
| Flush and replace engine coolant at 60 months, or 102, 000 miles (170 000 km) whichever comes first. | X |
| Miles | 63,000 | 66,000 | 69,000 | 72,000 | 75,000 |
|---|---|---|---|---|---|
| (Kilometers) | (105 000) | (110 000) | (115 000) | (120 000) | (125 000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Inspect auto tension drive belt and replace if required. | X |
| Miles | 78,000 | 81,000 | 84,000 | 87,000 | 90,000 |
|---|---|---|---|---|---|
| (Kilometers ) | (130 000) | (135 000) | (140 000) | (145 000) | (150 000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Check transfer case fluid level (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary.* | X | ||||
| Inspect auto tension drive belt and replace if required. | X |
| Miles | 93,000 | 96,000 | 99,000 | 102,000 |
|---|---|---|---|---|
| (Kilometers) | (155 000) | (160 000) | (165 000) | (170 000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X |
| Rotate tires. | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | ||
| Flush and replace engine coolant, if not replaced at 60 months. | X | |||
| Change rear axle fluid. | X | |||
| Change front axle fluid (4X4). | X |
| Miles | 105,000 | 108,000 | 111,000 | 114,000 | 117,000 | 120,000 |
|---|---|---|---|---|---|---|
| (Kilometers) | (175 000) | (180 000) | (185 000) | (190 000) | (195 000) | (200 000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X | X |
| Rotate tires. | X | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | X | |||
| Change rear axle fluid. | X | X | ||||
| Change front axle fluid (4X4). | X | X | ||||
| Inspect brake linings. | X | |||||
| Inspect engine air cleaner filter, replace if necessary. | X | X | ||||
| Replace spark plugs. | X | |||||
| Inspect PCV valve, replace as necessary.* | X | |||||
| Inspect auto tension drive belt and replace if required. | X | X | ||||
| Drain and refill transfer case fluid (4X4). | X | |||||
| Drain and refill automatic transmission fluid, change filter (3.7L). This applies only if your vehicle is used for police, taxi, fleet, or frequent trailer towing. | X | |||||
| Drain and refill automatic transmission fluid and change main sump filter and spin-on cooler return filter if equipped. (4.7L/5.7L only). This applies only if your vehicle is used for police, taxi, fleet, or frequent trailer towing. | X | |||||
| Flush and replace engine coolant at 120 months, if not replaced at 102,000 miles (170 000 km). | X |
| Miles | 123,000 | 126,000 | 129,000 | 132,000 | 135,000 | 138,000 |
|---|---|---|---|---|---|---|
| (Kilometers) | (205 000) | (210 000) | (215 000) | (220 000) | (225 000) | (230 000) |
| Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. | X | X | X | X | X | X |
| Lubricate Front Drive Shaft Fitting (4X4). | X | X | X | X | X | X |
| Rotate tires. | X | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | X | |||
| Lubricate outer tie rod ends (4X4). | X | X | X | |||
| Change front and rear axle fluid (4X4). | X | |||||
| Inspect brake linings. | X | |||||
| Inspect engine air cleaner filter, replace if necessary. | X | |||||
| Replace spark plugs. | ||||||
| Inspect PCV valve, replace as necessary.* | ||||||
| Inspect auto tension drive belt and replace if required (3.7L/4.7L/5.7L). | X |
| Miles | 141,000 | 144,000 | 147,000 | 150,000 |
|---|---|---|---|---|
| (Kilometers) | (235 000) | (240 000) | (245 000) | (250 000) |
| Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. | X | X | X | X |
| Lubricate Front Drive Shaft Fitting (4X4). | X | X | X | X |
| Rotate tires. | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | ||
| Lubricate outer tie rod ends (4X4) models only. | X | X | ||
| Check transfer case fluid level (4X4). | X | |||
| Change front and rear axle fluid (4X4). | X | |||
| Inspect brake linings. | X | |||
| Inspect engine air cleaner filter, replace if necessary. | X | |||
| Replace spark plugs. | X | |||
| Inspect PCV valve, replace as necessary.* | X | |||
| Inspect auto tension drive belt and replace if required (3.7L/4.7L/5.7L). | X | |||
| Drain and refill automatic transmission fluid and change main sump and spin-on cooler return filter (if equipped). | X | |||
| Flush and replace engine coolant if not replaced at 120,000 miles (200 000 km). | X |
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
* This maintenance is recommended by the manufacturer to the owner, but not required to maintain the emissions warranty.
SCHEDULE "A"
| Miles | 6,000 | 12,000 | 18,000 | 24,000 | 30,000 |
|---|---|---|---|---|---|
| (Kilometers) | (10 000) | (20 000) | (30 000) | (40 000) | (50 000) |
| [Months] | [6] | [12] | [18] | [24] | [30] |
| Change engine oil and engine oil filter. | X | X | X | X | X |
| Rotate tires. | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X |
| Check transfer case fluid level (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace as necessary. | X | ||||
| Replace spark plugs. | X |
| Miles | 36,000 | 42,000 | 48,000 | 54,000 | 60,000 | 66,000 |
|---|---|---|---|---|---|---|
| (Kilometers) | (60 000) | (70 000) | (80 000) | (90 000) | (100 000) | (110 000) |
| [Months] | [36] | [42] | [48] | [54] | [60] | [66] |
| Change engine oil and engine oil filter. | X | X | X | X | X | X |
| Rotate tires. | X | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X | |
| Check transfer case fluid level (4X4). | X | |||||
| Flush and replace engine coolant at 60 months, if not replaced at 102,000 miles (170 000 km). | X | |||||
| Inspect brake linings. | X | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | |||||
| Replace spark plugs. | X | |||||
| Inspect PCV valve, replace as necessary.* | X | |||||
| Inspect auto tension drive belt and replace if required. | X |
| Miles | 72,000 | 78,000 | 84,000 | 90,000 | 96,000 |
|---|---|---|---|---|---|
| (Kilometers) | (120 000) | (130 000) | (140 000) | (150 000) | (160 000) |
| [Months] | [72] | [78] | [84] | [90] | [96] |
| Change engine oil and engine oil filter. | X | X | X | X | X |
| Rotate tires. | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X |
| Check transfer case fluid level (4X4). | X | ||||
| Inspect brake linings. | X | X | |||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary.* | X | ||||
| Inspect auto tension drive belt and replace if required. | X |
| Miles | 102,000 | 108,000 | 114,000 | 120,000 |
|---|---|---|---|---|
| (Kilometers) | (170 000) | (180 000) | (190 000) | (200 000) |
| [Months] | [102] | [108] | [114] | [120] |
| Change engine oil and engine oil filter. | X | X | X | X |
| Rotate tires. | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X |
| Drain and refill transfer case fluid (4X4). | X | |||
| Flush and replace engine coolant, if not replaced at 60 months. | X | |||
| Flush and replace engine coolant at 120 months, if not replaced at 102,000 miles (170 000 km). | X | |||
| Inspect brake linings. | X | |||
| Inspect engine air cleaner filter, replace as necessary. | X | |||
| Replace spark plugs. | X | |||
| Inspect PCV valve, replace as necessary.* | X |
| Miles | 126,000 | 132,000 | 138,000 | 144,000 | 150,000 |
|---|---|---|---|---|---|
| (Kilometers) | (210 000) | (220 000) | (230 000) | (240 000) | (250 000) |
| [Months] | [126] | [132] | [138] | [144] | [150] |
| Change engine oil and engine oil filter. | X | X | X | X | X |
| Rotate tires. | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X |
| Check transfer case fluid level (4X4). | X | ||||
| Lubricate Front Drive Shaft Fitting (4X4). | X | X | X | X | X |
| Flush and replace engine coolant, if not replaced at 120,000 miles (200 000 km). | X | ||||
| Lubricate outer tie rod ends (4X4) models only. | X | X | X | X | X |
| Inspect brake linings. | X | X | |||
| Inspect auto tension drive belt and replace if required (3.7L/4.7L/5.7L).**** | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV Valve, replace as necessary.* | X |
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
* This maintenance is recommended by the manufacturer to the owner, but not required to maintain the emissions warranty.
| WARNING | You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic. |
| Kilometers | 12 000 | 24 000 | 36 000 | 48 000 | 60 000 |
|---|---|---|---|---|---|
| (Miles) | (7,500) | (15,000) | (22,500) | (30,000) | (37,500) |
| [Months] | [6] | [12] | [18] | [24] | [30] |
| Change engine oil and engine oil filter. | X | X | X | X | X |
| Rotate tires. | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X |
| Check transfer case fluid level. | X | ||||
| Inspect brake linings. | X | ||||
| Replace engine air cleaner filter. | X | ||||
| Replace spark plugs. | X |
| Kilometers | 72 000 | 84 000 | 96 000 | 108 000 | 120 000 | 132 000 |
|---|---|---|---|---|---|---|
| (Miles) | (45,000) | (52,500) | (60,000) | (67,500) | (75,000) | (82,500) |
| [Months] | [36] | [42] | [48] | [54] | [60] | [66] |
| Change engine oil and engine oil filter. | X | X | X | X | X | X |
| Rotate tires. | X | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X | X |
| Check transfer case fluid level. | X | |||||
| Flush and replace engine coolant at 60 months, regardless of mileage. | X | |||||
| Inspect brake linings. | X | X | ||||
| Replace engine air cleaner filter. | X | |||||
| Replace spark plugs. | X | |||||
| Inspect PCV valve, replace as necessary.** | X | |||||
| Inspect auto tension drive belt and replace if required. | X |
| Kilometers | 144 000 | 156 000 | 160 000 | 168 000 | 181 000 | 192 000 |
|---|---|---|---|---|---|---|
| (Miles) | (90,000) | (97,500) | (100,000) | (105,000) | (112,500) | (120,000) |
| [Months] | [72] | [78] | [84] | [90] | [96] | |
| Change engine oil and engine oil filter. | X | X | X | X | X | |
| Rotate tires. | X | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X | |
| Flush and replace engine coolant, if not done at 60 mos. | X | |||||
| Drain and refill transfer case fluid. | X | |||||
| Check transfer case fluid level. | X | |||||
| Inspect brake linings. | X | X | ||||
| Replace engine air cleaner filter. | X | X | ||||
| Replace spark plugs. | X | X | ||||
| Inspect PCV valve, replace as necessary.** | X | X | ||||
| Inspect auto tension drive belt and replace if required. | X |
| Kilometers | 205 000 | 217 000 | 229 000 | 241 000 |
|---|---|---|---|---|
| (Miles) | (127,500) | (135,000 | (142,500) | (150,000) |
| [Months] | [102] | [108] | [114] | [120] |
| Change engine oil and engine oil filter. | X | X | X | X |
| Rotate tires. | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X |
| Flush and replace engine coolant, if not done at 192 000 km (120,000 miles). | X | |||
| Inspect the transfer case fluid. | X | |||
| Inspect brake linings. | X | |||
| Replace engine air cleaner filter. | X | |||
| Replace spark plugs. | X | |||
| Inspect PCV valve, replace as necessary.** | X | |||
| Inspect auto tension drive belt and replace if required. | X |
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
** This maintenance is recommended by the manufacturer to the owner, but not required to maintain the emissions warranty.
| WARNING | You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic. |
Follow schedule "B" if you usually operate your vehicle under one or more of the following conditions.
- Day or night temperatures are below 0° C (32° F).
- Stop and go driving.
- Extensive engine idling.
- Driving in dusty conditions.
- Short trips of less than 16 km (10 miles).
- More than 50% of your driving is at sustained high speeds during hot weather, above 32° C (90° F).
- Trailer towing.
- Taxi, police, or delivery service (commercial service).
- Off-road or desert operation.
Note. If ANY of these apply to you then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first and follow schedule "B" of the "Maintenance Schedules".
Note. If ANY of these apply to you then change your coolant every 102,000 miles (163 000 km) or 60 months, whichever comes first and follow schedule "B" of the "Maintenance Schedules".
| Kilometers | 5 000 | 10 000 | 14 000 | 19 000 | 24 000 |
|---|---|---|---|---|---|
| (Miles) | (3,000) | (6,000) | (9,000) | (12,000) | (15,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X |
| Kilometers | 29 000 | 34 000 | 38 000 | 43 000 | 48 000 |
|---|---|---|---|---|---|
| (Miles) | (18,000) | (21,000) | (24,000) | (27,000) | (30,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Check transfer case fluid level (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary.** | X |
| Kilometers | 53 000 | 58 000 | 62 000 | 67 000 | 72 000 |
|---|---|---|---|---|---|
| (Miles) | (33,000) | (36,000) | (39, 000) | (42,000) | (45,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X |
| Kilometers | 77 000 | 82 000 | 86 000 | 91 000 | 96 000 |
|---|---|---|---|---|---|
| (Miles) | (48,000) | (51,000) | (54,000 ) | (57,000 ) | (60,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary.** | X | ||||
| Inspect auto tension drive belt and replace if required. | X | ||||
| Drain and refill automatic transmission fluid, change filter (3.7L). This applies only if your vehicle is used for police, taxi, fleet, or frequent trailer towing. | X | ||||
| Drain and refill automatic transmission fluid and change main sump filter (4.7L/5.7L only). This applies only if your vehicle is used for police, taxi, fleet, or frequent trailer towing. | X | ||||
| Inspect transfer case fluid (4X4). | X | ||||
| Flush and replace engine coolant at 60 months, or 102, 000 miles (163 000 km) whichever comes first. |
| Kilometers | 101 000 | 106 000 | 110 000 | 115 000 | 120 000 |
|---|---|---|---|---|---|
| (Miles) | (63,000) | (66,000) | (69,000) | (72,000) | (75,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Inspect auto tension drive belt and replace if required. | X |
| Kilometers | 125 000 | 130 000 | 134 000 | 139 000 | 144 000 |
|---|---|---|---|---|---|
| (Miles) | (78,000) | (81,000) | (84,000) | (87,000) | (90,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X | ||||
| Check transfer case fluid level (4X4). | X | ||||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary.** | X | ||||
| Inspect auto tension drive belt and replace if required. | X |
| Kilometers | 149 000 | 154 000 | 158 000 | 160 000 | 163 000 |
|---|---|---|---|---|---|
| (Miles) | (93,000) | (96,000) | (99,000) | (100,000) | (102,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Flush and replace engine coolant, if not done at 60 months. | X | ||||
| Change rear axle fluid. | X | ||||
| Change front axle fluid (4X4). | X |
| Kilometers | 168 000 | 173 000 | 178 000 | 182 000 | 187 000 | 192 000 |
|---|---|---|---|---|---|---|
| (Miles) | (105,000) | (108,000) | (111,000) | (114,000) | (117,000) | (120,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X | X |
| Rotate tires. | X | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | X | |||
| Change rear axle fluid. | X | X | ||||
| Change front axle fluid (4X4). | X | X | ||||
| Inspect brake linings. | X | |||||
| Inspect engine air cleaner filter, replace if necessary. | X | X | ||||
| Replace spark plugs. | X | |||||
| Inspect PCV valve, replace as necessary.** | X | |||||
| Inspect auto tension drive belt and replace if required. | X | X | ||||
| Drain and refill transfer case fluid (4X4). | X | |||||
| Drain and refill automatic transmission fluid, change filter (3.7L). This applies only if your vehicle is used for police, taxi, fleet, or frequent trailer towing. | X | |||||
| Drain and refill automatic transmission fluid and change main sump filter and spin-on cooler return filter if equipped. (4.7L/5.7L only). This applies only if your vehicle is used for police, taxi, fleet, or frequent trailer towing. | X |
| (Kilometers) | (198 000) | (203 000) | (208 000) | (212 000) | (217 000) | (222 000) |
|---|---|---|---|---|---|---|
| Miles | 123,000 | 126,000 | 129,000 | 132,000 | 135,000 | 138,000 |
| Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. | X | X | X | X | X | X |
| Lubricate Front Drive Shaft Fitting 4X4. | X | X | X | X | X | X |
| Rotate tires. | X | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | X | |||
| Lubricate outer tie rod ends 4X4 models only. | X | X | X | |||
| Change front and rear axle fluid (4X4). | X | |||||
| Inspect brake linings. | X | |||||
| Inspect engine air cleaner filter, replace if necessary. | X | |||||
| Replace spark plugs. | ||||||
| Inspect PCV valve, replace as necessary.** | ||||||
| Inspect auto tension drive belt and replace if required (3.7L/4.7L/5.7L). | X |
| (Kilometers) | (227 000) | (232 000) | (237 000) | (241 000) |
|---|---|---|---|---|
| Miles | 141,000 | 144,000 | 147,000 | 150,000 |
| Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. | X | X | X | X |
| Lubricate Front Drive Shaft Fitting, 4X4. | X | X | X | X |
| Rotate tires. | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | ||
| Lubricate outer tie rod ends 4X4 models only. | X | X | ||
| Drain and refill transfer case fluid (4X4). | X | |||
| Change front and rear axle fluid (4X4). | X | |||
| Inspect brake linings. | X | |||
| Inspect engine air cleaner filter, replace if necessary. | X | |||
| Replace spark plugs. | X | |||
| Inspect PCV valve, replace as necessary.** | X | |||
| Inspect auto tension drive belt and replace if required (3.7L/4.7L/5.7L). | X | |||
| Drain and refill automatic transmission fluid and change main sump and spin-on cooler return filter (if equipped)*. | X | |||
| Flush and replace engine coolant if not replaced at 192 000 km (120,000 miles). | X |
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
** This maintenance is recommended by the manufacturer to the owner, but not required to maintain the emissions warranty.
| WARNING | You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic. |
EXTERIOR
| LIGHT BULBS - OUTSIDE | BULB NUMBER |
|---|---|
| Headlight | H13 |
| Front Park/Turn | 3457AK |
| Back-Up | 3057 |
| Center High Mounted Stoplight | 921 |
| Fog Lamp | 9006LL |
| Front Sidemarker | 168 |
| License Plate Light | 168 |
| Rear Tail, Stop, Turn Signal, and Side Marker | 3057 |
BULB SPECIFICATIONS (EXTERIOR)
INTERIOR
| LIGHT BULBS - INTERIOR | BULB NUMBER |
|---|---|
| Dome Light | WL212-2 |
| Liftgate Lamp | 567 |
| Overhead Console Lights | PLW214-2A |
| Reading Light | WL212-2 |
| Visor Vanity Lights | Not Serviceable |
BULB SPECIFICATIONS (INTERIOR)
COMMON TOWING DEFINITIONS
The following trailer towing related definitions will assist you in understanding the following information
Gross Vehicle Weight Rating (GVWR)
The GVWR is the total allowable weight of your vehicle. This includes driver, passengers, cargo and tongue weight. The total load must be limited so that you do not exceed the GVWR.
Gross Trailer Weight (GTW)
The gross trailer weight (GTW) is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or temporary) loaded in or on the trailer in its "loaded and ready for operation" condition. The recommended way to measure GTW is to put your fully loaded trailer on a vehicle scale. The entire weight of the trailer must be supported by the scale.
Gross Combination Weight Rating (GCWR)
The gross combination weight rating (GCWR) is the total permissible weight of your vehicle and trailer when weighed in combination. (Note that GCWR ratings include a 68 kg (150 lbs) allowance for the presence of a driver).
Gross Axle Weight Rating (GAWR)
The GAWR is the maximum capacity of the front and rear axles. Distribute the load over the front and rear axles evenly. Make sure that you do not exceed either front or rear GAWR.
| WARNING | It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. |
Tongue Weight (TW)
The downward force exerted on the hitch ball by the trailer. In most cases it should not be less than 10% or more than 15% of the trailer load. You must consider this as part of the load on your vehicle.
Frontal Area
The maximum height and maximum width of the front of a trailer.
TSC (Trailer Sway Control) - If Equipped
- Trailer Sway Control - Electronic TSC uses sensors in the vehicle to recognize a swaying trailer and will take the appropriate actions to attempt to stop the sway. The system will reduce engine power and apply individual brakes that will counter act the sway of the trailer. TSC will become active automatically once the swaying trailer is recognized. No driver action is required. TSC can not stop all trailers from swaying. Always use caution when towing a trailer and follow the tongue weight recommendations. Even if your vehicle is equipped with electronic trailer sway control, mechanical sway control is recommended when appropriate for the size of your trailer.
- Trailer Sway Control - Mechanical The trailer sway control is a telescoping link that can be installed between the hitch receiver and the trailer tongue that typically provides adjustable friction associated with the telescoping motion to dampen any unwanted trailer swaying motions while traveling.
Weight-Carrying Hitch
A weight-carrying hitch supports the trailer tongue weight, just as if it were luggage located at a hitch ball or some other connecting point of the vehicle. These kind of hitches are the most popular on the market today and they're commonly used to tow small- and medium-sized trailers.
Weight-Distributing Hitch
A weight-distributing system works by applying leverage through spring (load) bars. They are typically used for heavier loads, to distribute trailer tongue weight to the tow vehicle's front axle and the trailer axle(s). When used in accordance with the manufacturers' directions, it provides for a more level ride, offering more consistent steering and brake control thereby enhancing towing safety. The addition of a friction / hydraulic sway control also dampens sway caused by traffic and crosswinds and contributes positively to tow vehicle and trailer stability. Trailer sway control and a weight distributing (load equalizing) hitch are recommended for heavier Tongue Weights (TW) and may be required depending on Vehicle and Trailer configuration / loading to comply with gross axle weight rating (GAWR) requirements.
| WARNING | An improperly adjusted Weight Distributing Hitch system may reduce handling, stability, braking performance, and could result in an accident. Weight Distributing Systems may not be compatible with Surge Brake Couplers. Consult with your hitch and trailer manufacturer or a reputable Recreational Vehicle dealer for additional information. |
Scheme 9
Scheme 10
Fifth-Wheel Hitch
A special high platform with a coupling that mounts over the rear axle of the tow vehicle in the truck bed. Connects a vehicle and fifth-wheel trailer with a coupling king pin.
Gooseneck Hitch
The gooseneck hitch employs a pivoted coupling arm which attaches to a ball mounted in the bed of a pickup truck. The coupling arm connects to the hitch mounted over the rear axle in the truck bed.
TRAILER HITCH CLASSIFICATION
The rear bumper is intended to tow trailers up to 2,000 lbs (907 kg) without added equipment or alterations to the standard equipment. Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package. See your dealer for package content.
The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Refer to "Trailer Towing Weights (Maximum Trailer Weight Ratings)" for the website address that contains the necessary information for your specific drivetrain.
| Trailer Hitch Classification | |
|---|---|
| Class | Max. GTW (Gross Trailer Wt.) |
| Class I - Light Duty | 2,000 lbs (907 kg) |
| Class II - Medium Duty | 3,500 lbs (1587 kg) |
| Class III - Heavy Duty | 5,000 lbs (2268 kg) |
| Class IV - Extra Heavy Duty | 10,000 lbs (4540 kg) |
| Fifth Wheel/Gooseneck | Greater than 10,000 lbs (4540 kg) |
All trailer hitches should be professionally installed on your vehicle.
TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS)
For additional trailer towing information (maximum trailer weight ratings) refer to the following website addresses
- http:// www.dodge.com/towing .
- http:// www.dodge.ca (Canada).
TRAILER AND TONGUE WEIGHT
Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle. Loads balanced over the wheels or heavier in the rear can cause the trailer to sway severely side to side which will cause loss of control of the vehicle and trailer. Failure to load trailers heavier in front is the cause of many trailer accidents.
Never exceed the maximum tongue weight stamped on your bumper or trailer hitch.
Scheme 11
Consider the following items when computing the weight on the rear axle of the vehicle
- The tongue weight of the trailer.
- The weight of any other type of cargo or equipment put in or on your vehicle.
- The weight of the driver and all passengers.
Note. Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the Tire and Loading Information placard.
TOWING REQUIREMENTS
To promote proper break-in of your new vehicle drivetrain components the following guidelines are recommended
| CAUTION | Avoid towing a trailer for the first 500 miles (805 km) of vehicle operation. Doing so may damage your vehicle. During the first 500 miles (805 km) of trailer towing, limit your speed to 50 mph (80 km/h). |
When towing a trailer, never exceed the GAWR, or GCWR, ratings.
| WARNING | Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control. You could lose control of your vehicle and have an accident. |
- When hauling cargo or towing a trailer, do not overload your vehicle or trailer. Overloading can cause a loss of control, poor performance or damage to brakes, axle, engine, transmission, steering, suspension, chassis structure or tires.
- Safety chains must always be used between your vehicle and trailer. Always connect the chains to the frame or hook retainers of the vehicle hitch. Cross the chains under the trailer tongue and allow enough slack for turning corners.
- Vehicles with trailers should not be parked on a grade. When parking, apply the parking brake on the tow vehicle. Put the tow vehicle automatic transmission in P for Park. Always, block or "chock" the trailer wheels.
- GCWR must not be exceeded.
- Total weight must be distributed between the tow vehicle and the trailer such that the following four ratings are not exceeded: GVWR GTW GAWR Tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight).
Towing Requirements - Tires
- Do not attempt to tow a trailer while using a compact spare tire.
- Proper tire inflation pressures are essential to the safe and satisfactory operation of your vehicle.
- Also, check the trailer tires for proper tire inflation pressures before trailer usage.
- Check for signs of tire wear or visible tire damage before towing a trailer. Refer to Tires «DESCRIPTION»(ref-285323-S02533965422008052100000) of Tread Wear Indicators for the proper inspection procedure.
- When replacing tires, refer to «DESCRIPTION»(ref-285323-S02533965422008052100000) of Replacement Tires for proper tire replacement procedures. Replacing tires with a higher load carrying capacity will not increase the vehicle's GVWR and GAWR limits.
Towing Requirements - Trailer Brakes
- Do not interconnect the hydraulic brake system or vacuum system of your vehicle with that of the trailer. This could cause inadequate braking and possible personal injury.
- An electronically actuated trailer brake controller is required when towing a trailer with electronically actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required.
- Trailer brakes are recommended for trailers over 1,000 lbs (454 kg) and required for trailers in excess of 2,000 lbs (907 kg).
| CAUTION | If the trailer weighs more than 1,000 lbs (454 kg) loaded, it should have its own brakes and they should be of adequate capacity. Failure to do this could lead to accelerated brake lining wear, higher brake pedal effort, and longer stopping distances. |
| WARNING | Do not connect trailer brakes to your vehicle's hydraulic brake lines. It can overload your brake system and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping distance. When towing you should allow for additional space between your vehicle and the vehicle in front of you. Failure to do so could result in an accident. |
TOWING TIPS
Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic.
Towing Tips - Automatic Transmission
The "D" range can be selected when towing. However, if frequent shifting occurs while in this range, the "TOW HAUL" feature should be selected.
Note. Using the "TOW HAUL" feature while operating the vehicle under heavy operating conditions will improve performance and extend transmission life by reducing excessive shifting and heat build up. This action will also provide better engine braking.
The automatic transmission fluid and filter should be changed if you REGULARLY tow a trailer for more than 45 minutes of continuous operation. See Schedule "B" for transmission fluid change intervals.
Note. Check the automatic transmission fluid level before towing.
Towing Tips - Tow/Haul (If Equipped)
To reduce potential for automatic transmission overheating, turn the "TOW HAUL" feature ON when driving in hilly areas or shift the transmission to Drive position 2 on more severe grades.
Towing Tips - Electronic Speed Control (If Equipped)
- Don't use in hilly terrain or with heavy loads.
- When using the speed control, if you experience speed drops greater than 10 mph (16 km/h), disengage until you can get back to cruising speed.
- Use speed control in flat terrain and with light loads to maximize fuel efficiency.
Towing Tips - Cooling System
To reduce potential for engine and transmission overheating, take the following actions
- City Driving - When stopped for short periods of time, put transmission in neutral and increase engine idle speed.
- Highway Driving - Reduce speed.
- Air Conditioning - Turn off temporarily.
- Refer to «COOLING - OPERATION»(ref-285336-S08020047402008052100000) for more information.
