COMPONENT MONITORS

There are several components that will affect vehicle emissions if they malfunction. If one of these components malfunctions the Malfunction Indicator Lamp (MIL) will illuminate.

Some of the component monitors are checking for proper operation of the part. Electrically operated components now have input (rationality) and output (functionality) checks. Previously, a component like the Throttle Position sensor (TPS) was checked by the PCM for an open or shorted circuit. If one of these conditions occurred, a DTC was set. Now there is a check to ensure that the component is working. This is done by watching for a TPS indication of a greater or lesser throttle opening than MAP and engine RPM indicate. In the case of the TPS, if engine vacuum is high and engine RPM is 1600 or greater, and the TPS indicates a large throttle opening, a DTC will be set. The same applies to low vacuum if the TPS indicates a small throttle opening.

All open/short circuit checks, or any component that has an associated limp-in, will set a fault after 1 trip with the malfunction present. Components without an associated limp-in will take two trips to illuminate the MIL.

BULB CHECK

Each time the ignition key is turned to the ON position, the malfunction indicator (check engine) lamp on the instrument panel should illuminate for approximately 2 seconds then go out. This is done for a bulb check.

TASK MANAGER

The Powertrain Control Module (PCM) is responsible for efficiently coordinating the operation of all the emissions-related components. The PCM is also responsible for determining if the diagnostic systems are operating properly. The software designed to carry out these responsibilities is called the TASK MANAGER.

TRIP DEFINITION

The term TRIP has different meanings depending on what the circumstances are. If the Malfunction Indicator Lamp (MIL) is OFF, a TRIP is defined as when the Oxygen Sensor Monitor and the Catalyst Monitor have been completed in the same drive cycle.

When any Emission DTC is set, the MIL on the dash is turned ON. When the MIL is ON, it takes 3 good trips to turn the MIL OFF. In this case, it depends on what type of DTC is set to know what a "Trip" is.

For the Fuel Monitor or Misfire Monitor (continuous monitor), the vehicle must be operated in the SIMILAR CONDITION WINDOW for a specified amount of time to be considered a GOOD TRIP.

If a Non-Continuous OBD II Monitor fails twice in a row and turns ON the MIL, re-running that monitor which previously failed, on the next start-up and passing the monitor, is considered to be a GOOD TRIP. These will include the following

1. Oxygen Sensor
2. Catalyst Monitor
3. Purge Flow Monitor
4. Leak Detection Pump Monitor (if equipped)
5. EGR Monitor (if equipped)
6. Oxygen Sensor Heater Monitor

If any other Emission DTC is set (not an OBD II Monitor), a GOOD TRIP is considered to be when the Oxygen Sensor Monitor and Catalyst Monitor have been completed; or 2 Minutes of engine run time if the Oxygen Sensor Monitor or Catalyst Monitor have been stopped from running.

It can take up to 2 Failures in a row to turn on the MIL. After the MIL is ON, it takes 3 GOOD TRIPs to turn the MIL OFF. After the MIL is OFF, the PCM will self-erase the DTC after 40 Warm-up cycles. A Warm-up cycle is counted when the Engine Coolant Temperature Sensor (ECT) has crossed 71° C (160° F) and has risen by at least 4.4° C (40° F) since the engine has been started.

The Task Manager determines which tests happen when and which functions occur when. Many of the diagnostic steps required by OBD II must be performed under specific operating conditions. The Task Manager software organizes and prioritizes the diagnostic procedures. The job of the Task Manager is to determine if conditions are appropriate for tests to be run, monitor the parameters for a trip for each test, and record the results of the test. Following are the responsibilities of the Task Manager software

1. Test Sequence
2. MIL Illumination
3. Diagnostic Trouble Codes (DTCs)
4. Trip Indicator
5. Freeze Frame Data Storage
6. Similar Conditions Window

MIL ILLUMINATION

The PCM Task Manager carries out the illumination of the MIL. The Task Manager triggers MIL illumination upon test failure, depending on monitor failure criteria.

The Task Manager Screen shows both a Requested MIL state and an Actual MIL state. When the MIL is illuminated upon completion of a test for a third trip, the Requested MIL state changes to OFF. However, the MIL remains illuminated until the next key cycle. (On some vehicles, the MIL will actually turn OFF during the third key cycle) During the key cycle for the third good trip, the Requested MIL state is OFF, while the Actual MIL state is ON. After the next key cycle, the MIL is not illuminated and both MIL states read OFF.

TRIP INDICATOR

The Trip is essential for running monitors and extinguishing the MIL. In OBD II terms, a trip is a set of vehicle operating conditions that must be met for a specific monitor to run. All trips begin with a key cycle.

Good Trip

The Good Trip counters are as follows

1. Specific Good Trip
2. Fuel System Good Trip
3. Misfire Good Trip
4. Alternate Good Trip (appears as a Global Good Trip on a scan tool) Comprehensive Components Major Monitor
5. Warm-Up Cycles

SPECIFIC GOOD TRIP

The term Good Trip has different meanings depending on the circumstances

1. If the MIL is OFF, a trip is defined as when the Oxygen Sensor Monitor and the Catalyst Monitor have been completed in the same drive cycle.
2. If the MIL is ON and a DTC was set by the Fuel Monitor or Misfire Monitor (both continuous monitors), the vehicle must be operated in the Similar Condition Window for a specified amount of time.
3. If the MIL is ON and a DTC was set by a Task Manager commanded once-per-trip monitor (such as the Oxygen Sensor Monitor, Catalyst Monitor, Purge Flow Monitor, Leak Detection Pump Monitor, EGR Monitor or Oxygen Sensor Heater Monitor), a good trip is when the monitor is passed on the next start-up.
4. If the MIL is ON and any other emissions DTC was set (not an OBD II monitor), a good trip occurs when the Oxygen Sensor Monitor and Catalyst Monitor have been completed, or two minutes of engine run time if the Oxygen Sensor Monitor and Catalyst Monitor have been stopped from running.

FUEL SYSTEM GOOD TRIP

To count a good trip (three required) and turn off the MIL, the following conditions must occur

1. Engine in closed loop
2. Operating in Similar Conditions Window
3. Short Term multiplied by Long Term less than threshold
4. Less than threshold for a predetermined time

If all of the previous criteria are met, the PCM will count a good trip (three required) and turn off the MIL.

MISFIRE GOOD TRIP

If the following conditions are met the PCM will count one good trip (three required) in order to turn off the MIL

1. Operating in Similar Condition Window
2. 1000 engine revolutions with no misfire

Warm-Up Cycles

Once the MIL has been extinguished by the Good Trip Counter, the PCM automatically switches to a Warm-Up Cycle Counter that can be viewed on a diagnostic scan tool. Warm-Up Cycles are used to erase DTCs and Freeze Frames. Forty Warm-Up cycles must occur in order for the PCM to self-erase a DTC and Freeze Frame. A Warm-Up Cycle is defined as follows

1. Engine coolant temperature must start below and rise above 71.1° C (160° F).
2. Engine coolant temperature must rise by 4.4° C (40° F)
3. No further faults occur

FREEZE FRAME DATA STORAGE

Once a failure occurs, the Task Manager records several engine operating conditions and stores it in a Freeze Frame. The Freeze Frame is considered one frame of information taken by an on-board data recorder. When a fault occurs, the PCM stores the input data from various sensors so that technicians can determine under what vehicle operating conditions the failure occurred.

The data stored in Freeze Frame is usually recorded when a system fails the first time for two trip faults. Freeze Frame data will only be overwritten by a different fault with a higher priority.

SIMILAR CONDITIONS WINDOW

The Similar Conditions Window displays information about engine operation during a monitor. Absolute MAP (engine load) and Engine RPM are stored in this window when a failure occurs. There are two different Similar conditions Windows: Fuel System and Misfire.

FUEL SYSTEM

1. Fuel System Similar Conditions Window - An indicator that 'Absolute MAP When Fuel System Fail' and 'RPM When Fuel System Failed' are all in the same range when the failure occurred. Indicated by switching from 'NO' to 'YES'.
2. Absolute MAP When Fuel System Fail - The stored MAP reading at the time of failure. Informs the user at what engine load the failure occurred.
3. Absolute MAP - A live reading of engine load to aid the user in accessing the Similar Conditions Window.
4. RPM When Fuel System Fail - The stored RPM reading at the time of failure. Informs the user at what engine RPM the failure occurred.
5. Engine RPM - A live reading of engine RPM to aid the user in accessing the Similar Conditions Window.
6. Adaptive Memory Factor - The PCM utilizes both Short Term Compensation and Long Term Adaptive to calculate the Adaptive Memory Factor for total fuel correction.
7. Upstream O2S Volts - A live reading of the Oxygen Sensor to indicate its performance. For example, stuck lean, stuck rich, etc.
8. SCW Time in Window (Similar Conditions Window Time in Window) - A timer used by the PCM that indicates that, after all Similar Conditions have been met, if there has been enough good engine running time in the SCW without failure detected. This timer is used to increment a Good Trip.
9. Fuel System Good Trip Counter - A Trip Counter used to turn OFF the MIL for Fuel System DTCs. To increment a Fuel System Good Trip, the engine must be in the Similar Conditions Window, Adaptive Memory Factor must be less than calibrated threshold and the Adaptive Memory Factor must stay below that threshold for a calibrated amount of time.
10. Test Done This Trip - Indicates that the monitor has already been run and completed during the current trip.

MISFIRE

1. Same Misfire Warm-Up State - Indicates if the misfire occurred when the engine was warmed up above 160° F (71.1°C).
2. In Similar Misfire Window - An indicator that 'Absolute MAP When Misfire Occurred' and 'RPM When Misfire Occurred' are all in the same range when the failure occurred. Indicated by switching from 'NO' to 'YES'.
3. Absolute MAP When Misfire Occurred - The stored MAP reading at the time of failure. Informs the user at what engine load the failure occurred.
4. Absolute MAP - A live reading of engine load to aid the user in accessing the Similar Conditions Window.
5. RPM When Misfire Occurred - The stored RPM reading at the time of failure. Informs the user at what engine RPM the failure occurred.
6. Engine RPM - A live reading of engine RPM to aid the user in accessing the Similar Conditions Window.
7. Adaptive Memory Factor - The PCM utilizes both Short Term Compensation and Long Term Adaptive to calculate the Adaptive Memory Factor for total fuel correction.
8. 200 Rev Counter - Counts 0-100 720 degree cycles.
9. SCW Cat 200 Rev Counter - Counts when in similar conditions.
10. SCW FTP 1000 Rev Counter - Counts 0-4 when in similar conditions.
11. Misfire Good Trip Counter - Counts up to three to turn OFF the MIL.
12. Misfire Data - Data collected during test.
13. Test Done This Trip - Indicates YES when the test is done.

NON-MONITORED CIRCUITS

The PCM does not monitor the following circuits, systems and conditions that could have malfunctions causing driveability problems. The PCM might not store diagnostic trouble codes for these conditions. However, problems with these systems may cause the PCM to store diagnostic trouble codes for other systems or components. EXAMPLE: a fuel pressure problem will not register a fault directly, but could cause a rich/lean condition or misfire. This could cause the PCM to store an oxygen sensor or misfire diagnostic trouble code

FUEL PRESSURE

The fuel pressure regulator controls fuel system pressure. The PCM cannot detect a clogged fuel pump inlet filter, clogged in-line fuel filter, or a pinched fuel supply or return line. However, these could result in a rich or lean condition causing the PCM to store an oxygen sensor or fuel system diagnostic trouble code.

SECONDARY IGNITION CIRCUIT

The PCM cannot detect an inoperative ignition coil, fouled or worn spark plugs, ignition cross firing, or open spark plug cables.

CYLINDER COMPRESSION

The PCM cannot detect uneven, low, or high engine cylinder compression.

EXHAUST SYSTEM

The PCM cannot detect a plugged, restricted or leaking exhaust system, although it may set a fuel system fault.

FUEL INJECTOR MECHANICAL MALFUNCTIONS

The PCM cannot determine if a fuel injector is clogged, the needle is sticking or if the wrong injector is installed. However, these could result in a rich or lean condition causing the PCM to store a diagnostic trouble code for either misfire, an oxygen sensor, or the fuel system.

EXCESSIVE OIL CONSUMPTION

Although the PCM monitors engine exhaust oxygen content when the system is in closed loop, it cannot determine excessive oil consumption.

THROTTLE BODY AIR FLOW

The PCM cannot detect a clogged or restricted air cleaner inlet or filter element.

VACUUM ASSIST

The PCM cannot detect leaks or restrictions in the vacuum circuits of vacuum assisted engine control system devices. However, these could cause the PCM to store a MAP sensor diagnostic trouble code and cause a high idle condition.

PCM SYSTEM GROUND

The PCM cannot determine a poor system ground. However, one or more diagnostic trouble codes may be generated as a result of this condition. The module should be mounted to the body at all times, also during diagnostic.

PCM CONNECTOR ENGAGEMENT

The PCM may not be able to determine spread or damaged connector pins. However, it might store diagnostic trouble codes as a result of spread connector pins.

EMISSION SYSTEM

The Powertrain Control Module (PCM) monitors many different circuits in the fuel injection, ignition, emission and engine systems. If the PCM senses a problem with a monitored circuit often enough to indicate an actual problem, it stores a Diagnostic Trouble Code (DTC) in the PCM's memory. If the problem is repaired or ceases to exist, the PCM cancels the code after 40 warm-up cycles. Diagnostic trouble codes that affect vehicle emissions illuminate the Malfunction Indicator Lamp (MIL). The MIL is displayed as an engine icon (graphic) on the instrument panel. Refer to Malfunction Indicator Lamp in this section.

Certain criteria must be met before the PCM stores a DTC in memory. The criteria may be a specific range of engine RPM, engine temperature, and/or input voltage to the PCM.

The PCM might not store a DTC for a monitored circuit even though a malfunction has occurred. This may happen because one of the DTC criteria for the circuit has not been met. For example, assume the diagnostic trouble code criteria requires the PCM to monitor the circuit only when the engine operates between 750 and 2000 RPM. Suppose the sensor's output circuit shorts to ground when engine operates above 2400 RPM (resulting in 0 volt input to the PCM). Because the condition happens at an engine speed above the maximum threshold (2000 RPM), the PCM will not store a DTC.

There are several operating conditions for which the PCM monitors and sets DTCs. Refer to Monitored Systems, Components, and NON-MONITORED CIRCUITS .

Technicians must retrieve stored DTCs by connecting a scan tool to the 16-way data link connector. The connector is located on the bottom edge of the instrument panel near the steering column.

Note. Various diagnostic procedures may actually cause a diagnostic monitor to set a DTC. For instance, pulling a spark plug wire to perform a spark test may set the misfire code. When a repair is completed and verified, connect a scan tool to the 16-way data link connector to erase all DTCs and extinguish the MIL.

EVAPORATIVE EMISSIONS - HIGH AND LOW LIMITS

The PCM compares input signal voltages from each input device with established high and low limits for the device. If the input voltage is not within limits and other criteria are met, the PCM stores a diagnostic trouble code in memory. Other diagnostic trouble code criteria might include engine RPM limits or input voltages from other sensors or switches that must be present before verifying a diagnostic trouble code condition.

OBD II MONITOR RUN PROCESS

The following procedure has been established to assist DaimlerChrysler Dealer Technicians in the field with enabling and running OBD II Monitors. The order listed in the following procedure is intended to allow the technician to effectively complete each monitor and to set the CARB Readiness Status in the least time possible.

Note. Once the monitor run process has begun, do not turn off the ignition. By turning the ignition key off, monitor enabling conditions will be lost. NVLD Monitor runs after key off. By performing a Battery Disconnect, or Selecting Erase DTCs, the CARB Readiness and all additional OBD II information will be cleared.

MONITOR PRELIMINARY CHECKS

1. Plug a scan tool into the vehicle's Data Link Connector (DLC).
2. Turn the ignition, KEY ON - ENGINE OFF. Watch for MIL lamp illumination during the bulb check. MIL lamp must have illuminated, if not, repair MIL lamp.
3. Using a scan tool check for Powertrain related DTCs. Verify that No Emissions Related DTCs are Present. * If an Emissions DTC is Present, the OBD II Monitors may not run and the CARB Readiness will not update. The Emissions related DTC, will need to be repaired, then cleared. By clearing DTCs, the OBD Monitors will need to be run and completed to set the CARB Readiness Status.

Using the scan tool check the CARB Readiness Status.

Do all the CARB Readiness Status Locations read YES?

1. *YES, then all monitors have been completed and this vehicle is ready to be I/M or Emission Tested.
2. *NO, then the following procedure needs to be followed to run/complete all available monitors.

Note. Only the monitors, which are not YES in the CARB Readiness Status, need to be completed. Specific criteria need to be met for each monitor. The most efficient order to run the monitors has been outlined below, including suggestions to aid the process.

EVAPORATIVE EMISSION SYSTEM LEAK DETECTION WITH PURGE MONITOR

This monitor requires a cool down cycle, usually an overnight soak for at least 8 hours without the engine running. The ambient temperature must decrease overnight - parking the vehicle outside is advised. To run this test the fuel level must be between 15-85% full. For the monitor run conditions select the EVAP MON PRE-TEST in the scan tool, OBD II Monitors Menu. The Purge monitor will run if the small leak test reports a pass. Criteria for EVAP monitor

1. Engine off time greater than @ one hour.
2. Fuel Level between 15% and 85 %.
3. Start Up ECT and IAT within 10° C (18° F).
4. Vehicle started and run until Purge Monitor reports a result.

Note. If the vehicle does not report a result and the conditions where correct. It may take up to two weeks to fail the small leak monitor. DO NOT use this test to attempt to determine a fault. Use the appropriate service information procedure for finding a small leak. If there are no faults and the conditions are correct this test will run and report a pass. Note the Small leak test can find leaks less than 20 thousands of an inch. If a small leak is present it takes approximately two weeks of normal driving to report a failure.

CATALYST/O2 MONITOR

With NGC, Catalyst and O2 Monitor information are acquired and processed at the same time. Most vehicles will need to be driven at highway speed (< 50 mph) for a few minutes. Some vehicles run the monitor at idle in drive. If the vehicle is equipped with a manual transmission, using 4th gear may assist in meeting the monitor running criteria. For the monitor run conditions, select the BANK 1 CAT MON PRE-TEST in the scan tool, OBD II Monitors Menu.

EGR MONITOR

The EGR monitor now runs in a closed throttle decel or at idle on a warm vehicle. However, it is necessary to maintain the TPS, Map and RPM ranges to allow the monitor to complete itself. For the monitor run conditions, select the EGR PRE-TEST in the scan tool, OBD II Monitors Menu.

O2 SENSOR HEATER MONITOR

This monitor is now continuously running once the heaters are energized. Pass information will be processed at power down. For the monitor run conditions, select the O2S HEATER MON PRE-TEST in the scan tool, OBD II Monitors Menu.

MISFIRE MONITOR

The NGC Misfire Monitor is a continuous two-trip monitor. The monitor uses two different tests/counters

Note. The Adaptive Numerator must be learned before the PCM will run the Misfire Monitor. The PCM updates the Adaptive Numerator at every key-ON, and is relearned after battery disconnect. The Misfire Monitor will not run until the Adaptive Numerator has updated since the last battery disconnect. If the Adaptive Numerator is equal to the default value then the PCM knows that the Adaptive Numerator has not been learned and does not permit the Misfire Monitor to run. If the Adaptive Numerator exceeds a calibrated percentage, the PCM sets a DTC for CKP NOT LEARNED and illuminates the MIL.

1. 200 Revolution Counter - Looks for misfire that can cause immediate catalyst damage.
2. 1000 Revolution Counter - Looks for misfire that can cause emissions to increase 1.5 times the Federal Test Procedure (FTP) standards. This test must also identify misfire percentages that might cause a "durability demonstration vehicle" to fail an Inspection and Maintenance Program tailpipe emissions test.

DUTY CYCLE EVAP CANISTER PURGE SOLENOID

The duty cycle EVAP canister purge solenoid (1) is located in the engine compartment. It is attached to a tongue-type bracket near the brake power booster (3).

1. Connect vapor line quick-connect fitting (5) to solenoid.
2. Connect vapor line quick-connect fitting (4) to solenoid.
3. Connect electrical wiring connector (2) to solenoid.
4. Carefully push the solenoid assembly straight rearward onto the tongue-type bracket without bending the two vapor lines.

FUEL TANK FILLER TUBE CAP

The plastic fuel tank filler tube cap is threaded onto the end of the fuel fill tube. Certain models are equipped with a 1/4 turn cap.

The loss of any fuel or vapor out of fuel filler tube is prevented by the use of a pressure-vacuum fuel fill cap. Relief valves inside the cap will release fuel tank pressure at predetermined pressures. Fuel tank vacuum will also be released at predetermined values. This cap must be replaced by a similar unit if replacement is necessary. This is in order for the system to remain effective.

POSITIVE CRANKCASE VENTILATION (PCV) SYSTEM

A typical enclosed crankcase ventilation system is see scheme 18

The PCV system operates by engine intake manifold vacuum. Filtered air is routed into the crankcase through the air cleaner hose. The metered air, along with crankcase vapors, are drawn through the PCV valve (4) and into a passage in the intake manifold. The PCV system manages crankcase pressure and meters blow by gases to the intake system, reducing engine sludge formation.

The PCV valve contains a spring loaded plunger. This plunger meters the amount of crankcase vapors routed into the combustion chamber based on intake manifold vacuum.

When the engine is not operating or during an engine pop-back, the spring forces the plunger back against the seat. This will prevent vapors from flowing through the valve.

During periods of high manifold vacuum, such as idle or cruising speeds, vacuum is sufficient to completely compress spring. It will then pull the plunger to the top of the valve. In this position there is minimal vapor flow through the valve.

During periods of moderate manifold vacuum, the plunger is only pulled part way back from inlet. This results in maximum vapor flow through the valve.

4.7L V-8

The PCV valve is located on the oil filler tube. Two locating tabs are located on the side of the valve. These 2 tabs fit into a cam lock in the oil filler tube. An O-ring seals the valve to the filler tube.

1. Return PCV valve back to oil filler tube by placing valve locating tabs into cam lock. Press PCV valve in and rotate valve upward. A slight click will be felt when tabs have engaged cam lock. Valve should be pointed towards rear of vehicle.
2. Connect PCV line/hose and rubber hose to PCV valve.

5.7L V-8

1. Clean out intake manifold opening.
2. Check condition of 2 O-rings on PCV valve.
3. Apply engine oil to 2 O-rings.
4. Place PCV valve into intake manifold and rotate 90 degrees clockwise for installation.

VACUUM LINES

A vacuum schematic for emission related items can be found on the vehicles VECI label. Refer to Vehicle Emission Control Information (VECI) Label for label location.

EVAPORATIVE (EVAP) CANISTER

The EVAP canister is filled with granules of an activated carbon mixture. Fuel vapors entering the EVAP canister is absorbed by the charcoal granules.

Fuel tank pressure vents into the EVAP canister. Fuel vapors are temporarily held in the canister until they can be drawn into the intake manifold. The duty cycle EVAP canister purge solenoid allows the EVAP canister to be purged at predetermined times and at certain engine operating conditions.

Scheme 26

The EVAP canister (1) is located at the front of the fuel tank. The ESIM (Evaporative System Integrity Monitor) switch (2) is attached to the EVAP canister.

Scheme 27

Scheme 28

1. Raise and support vehicle.
2. If equipped, remove fuel tank skid plate.
3. Remove electrical connector (3) at ESIM switch.
4. Disconnect rubber hose (2) from ESIM switch.
5. Disconnect quick-connect fitting (5) at EVAP canister.
6. Three lock tabs are used to mount the canister (2) to its bracket. Press on lock tab (1) to unlock canister from mounting bracket. An upper, symmetrical lock tab is located on top of canister above (1).
7. Slip canister from outer (third) mounting tab.

1. Snap canister into lock tabs (1).
2. Connect quick-connect fitting (5) to EVAP canister.
3. Connect rubber hose (2) to ESIM switch.
4. Connect electrical connector (3) to ESIM switch.
5. If equipped, install fuel tank skid plate.
6. Lower vehicle.
7. All vapor/vacuum lines and hoses must be firmly connected. Also check the vapor/vacuum lines at the EVAP canister purge solenoid for damage or leaks. If a leak is present, a Diagnostic Trouble Code (DTC) may be set.

Scheme 29

The ESIM (Evaporative System Integrity Monitor) is very similar to the NVLD. However, the design of the ESIM has been simplified and unlike the NVLD the ESIM does not require a solenoid. The ESIM mounts directly to the canister, eliminating the need for a mounting bracket. It is critical that the ESIM is mounted vertically. On vehicles where the canister is mounted on an angle, the ESIM requires an adaptor to maintain a vertical position. When the ESIM is installed vertically, the electrical connector is in the 3 o'clock position.

Scheme 30

The ESIM assembly consists of a housing, a small weight and a large weight that serve as check valves, a diaphragm, a switch and a cover. There is one large weight and one small weight check valve in the ESIM assembly. A seal is attached at the end of each weighted check valve. The large weight check valve seals for pressure. The small weight check valve seals for vacuum. The weighted check valves are contained within the ESIM housing.

Scheme 31

The ESIM (Evaporative System Integrity Monitor), while physically different than the NVLD system, performs the same basic function as the NVLD does - controlling evaporative emissions. The ESIM has been simplified because the solenoid used on the NVLD is not used on the ESIM.

The ESIM consists of housing, two check valves (sometimes referred to as weights), a diaphragm, a switch and a cover. The larger check valve seals for pressure and the smaller one seals for vacuum.

During refueling, pressure is built up in the evaporative system. When pressure reaches approximately .5 inches of water, the large check valve unseats and pressure vents to the fresh air filter.

Conversely, when the system cools, and the resulting vacuum lifts the small check valve from its seat and allows fresh air to enter the system and relieves the vacuum condition. When a calibrated amount of vacuum is achieved in the evaporative system, the diaphragm is pulled inward, pushing on the spring and closing the contacts.

The ESIM conducts test on the evaporative system as follows: An engine off, non-intrusive test for small leaks and an engine running, intrusive test for medium/large leaks.

The ESIM weights seal the EVAP system during engine off conditions. If the EVAP system is sealed, it will be pulled into a vacuum, either due to the cool down from operating temperature or diurnal ambient temperature cycling. When the vacuum in the system exceeds about 1" H20, the vacuum switch closes. The switch closure sends a signal to the PCM. In order to pass the non-intrusive small leak test, the ESIM switch must close within a calculated amount of time and within a specified amount of key-off events.

If the ESIM switch does not close as specified, the test is considered inconclusive and the intrusive engine running test will be run during the next key-on cycle. This intrusive test will run on the next cold engine running condition.

Conditions for running the intrusive test are

1. After the vehicle is started, the engine coolant temperature must be within 50°F (10°C) of ambient to indicate a cold start.
2. The fuel level must be between 12% and 88%.
3. The engine must be in closed loop.
4. Manifold vacuum must be greater than a minimum specified value.
5. Ambient temperature must be between 39°F and 98°F (4°C and 37°C) and the elevation level must be below 8500 feet (2591 meters).

The test is accomplished by the PCM activating the purge solenoid to create a vacuum in the evaporative system. The PCM then measures the amount of time it takes for the vacuum to dissipate. This is known as the vacuum decay method. If the switch opens quickly a large leak is recorded. If the switch opens after a predetermined amount of time, then the small leak matures. If the switch does not close, then a general evaporative failure is recorded. The purge monitor tests the integrity of the hose attached between the purge valve and throttle body/intake. The purge monitor is a two stage test and it runs only after the evaporative system passes the small leak test.

Even when all of the thresholds are met, a small leak won't be recorded until after the medium/large leak monitor has been run. This is accomplished by the PCM activating the purge solenoid to create a vacuum in the evaporative system. The PCM then measures the amount of time it takes for the vacuum to dissipate. This is known as the vacuum decay method. If the switch opens quickly a large leak is recorded. If the switch opens after a predetermined amount of time, then the small leak matures. If the medium/large leak test runs and the ESIM switch doesn't close, a general evaporative test is run. The purge solenoid is activated for approximately 10 seconds, increasing the amount of vacuum in the system. If the ESIM switch closes after the extended purge activation, a large leak fault is generated. If the switch doesn't close, a general evaporative system fault is generated.

The purge monitor tests the integrity of the hose attached between the purge valve and throttle body/intake. The purge monitor is a two stage test and it runs only after the evaporative system passes the small leak test.

Stage one of the purge monitor is non-intrusive. The PCM monitors the purge vapor ratio. If the ratio is above a calibrated specification, the monitor passes. Stage two is an intrusive test and it runs only if stage one fails. During the stage two test, the PCM commands the purge solenoid to flow at a specified rate to force the purge vapor ratio to update. The vapor ratio is compared to a calibrated specification and if it is less than specified, a one-trip failure is recorded.

The ESIM switch stuck closed monitor checks to see if the switch is stuck closed. This is a power down test that runs at key-off; when the PCM sees 0 RPM's, the purge solenoid is energized for a maximum of 30 seconds, venting any vacuum trapped in the evaporative system. If the switch opens or was open before the test began, the monitor passes. If the switch doesn't open, the monitor fails. This is a two-trip MIL. The star scan tool can be used to force the ESIM switch stick closed monitor to run.

The PCM also uses the ESIM to detect a loose or missing gas cap. The PCM controller looks for a change in the fuel level (25% minimum) and then gas cap is loose or missing. If a medium/large leak is detected, a loose gas cap light illuminates and a pending one-trip fault code is set. On the PCM, this is a three-trip fault before the code matures

VALVE - EGR - 3.7L

1. Clean gasket area (1) at rear of left cylinder head where it joins base of EGR valve.
2. Clean EGR tube where it joins EGR valve.
3. Position new gasket between EGR valve and cylinder head.
4. Position EGR valve to cylinder head. Install and tighten two bolts (2). Torque to 9 N.m (80 in. lbs.).
5. Position new gasket (3) between EGR tube flange and EGR valve assembly.
6. Position EGR tube (1) to side of EGR valve. Position end of tube (6) into intake manifold. Install two bolts (2). Torque to 11 N.m (8.5 ft. lbs.).
7. Connect electrical connector (3) to top of EGR valve solenoid (1).
8. Install windshield wiper motor.
9. Install plastic windshield cowl panel.
10. Connect negative battery cable.
11. Using a diagnostic scan tool, erase any previously recorded DTC's (Diagnostic Trouble Codes).

Scheme 32

The electronic EGR valve and solenoid assembly (4) is attached to the rear of the left cylinder head. An exhaust gas routing tube (3) connects the EGR valve to the intake manifold.

Scheme 33

1. Use a diagnostic scan tool to record any DTC's (Diagnostic Trouble Codes).
2. Disconnect and isolate the negative battery cable.
3. Remove plastic windshield cowl panel.
4. Remove windshield wiper motor.
5. Remove electrical connector (5) at top of EGR valve solenoid.
6. Remove tube mounting bolt (1) at intake manifold.
7. Remove two bolts (4) connecting EGR tube (1) to valve assembly.
8. Remove gasket located between EGR tube flange and EGR valve assembly.
9. Remove two EGR valve mounting bolts (5).
10. Separate valve assembly (3) from engine.
11. Remove and discard metal gasket located between cylinder head and valve assembly.

VALVE - EGR - 4.7L

1. Clean area at rear of left cylinder head where it joins base of EGR valve.
2. Clean EGR tube where it joins EGR valve.
3. Position new gasket between EGR valve and cylinder head.
4. Position EGR valve to cylinder head. Install and tighten two bolts (5). Torque to 9 N.m (80 in. lbs.).
5. Position new gasket between EGR tube flange and EGR valve assembly.
6. Position EGR tube (1) to side of EGR valve and into intake manifold. Install two bolts (4) finger tight (temporarily).
7. Install EGR tube flange bolt (1) at intake manifold. Torque to 11 N.m (8.5 ft. lbs.).
8. Connect electrical connector (5) to top of EGR valve solenoid (4).
9. Do a final tightening of two EGR tube bolts (4). Torque to 11 N.m (8.5 ft. lbs.).
10. Install windshield wiper motor.
11. Install plastic windshield cowl panel.
12. Connect negative battery cable.
13. Using a diagnostic scan tool, erase any previously recorded DTC's (Diagnostic Trouble Codes).

Scheme 34

The electronic EGR valve and solenoid assembly (3) is attached to the front of the right cylinder head (1). An exhaust gas routing tube connects the EGR valve to the intake manifold.

Scheme 35

1. Use a diagnostic scan tool to record any DTC's (Diagnostic Trouble Codes).
2. Disconnect and isolate the negative battery cable.
3. Disconnect electrical connector (1) from EGR solenoid (2).
4. Remove two bolts (3) connecting EGR tube (4) to valve assembly.
5. Remove gasket located between EGR tube flange and EGR valve assembly.
6. Remove two mounting bolts (2).
7. Separate valve assembly (3) from cylinder head (1).
8. Remove and discard metal gasket located between cylinder head and valve assembly.

VALVE - EGR - 5.7L

1. Position a new metal gasket between cylinder head (1) and valve assembly (3).
2. Install two mounting bolts (2) and tighten to 20 ft. lbs. (27 N.m).
3. Clean EGR tube where it joins EGR valve.
4. Position new gasket between EGR tube flange and EGR valve assembly.
5. Install two bolts (3) connecting EGR tube (4) to valve assembly (2). Tighten bolts to 20 ft. lbs. (27 N.m).
6. Connect electrical connector (1) to EGR solenoid (2).
7. Connect negative battery cable.
8. Using a diagnostic scan tool, erase any previously recorded DTC's (Diagnostic Trouble Codes).

GLOSSARY OF TERMS

The following procedure has been established to assist technicians in the field with enabling and running OBD II Monitors. The order listed in the following procedure is intended to allow the technician to effectively complete each monitor and to set the CARB Readiness Status in the least time possible.

Note. Once the monitor run process has begun, do not turn off the ignition. By turning the ignition key off, monitor enabling conditions will be lost. EVAP Monitor runs after key off. By performing a Battery Disconnect, or Selecting Erase DTCs, the CARB Readiness and all additional OBD II information will be cleared.

1. Plug a scan tool into the vehicle's Data Link Connector (DLC).
2. Turn the ignition, KEY ON - ENGINE OFF. Watch for MIL lamp illumination during the bulb check. MIL lamp must have illuminated, if not, repair MIL lamp.
3. Using a scan tool check for Powertrain related DTCs. Verify that No Emissions Related DTCs are Present. If an Emissions DTC is Present, the OBD II Monitors may not run and the CARB Readiness will not update. The Emissions related DTC, will need to be repaired, then cleared. By clearing DTCs, the OBD Monitors will need to be run and completed to set the CARB Readiness Status.

Using the scan tool check the CARB Readiness Status.

Do all the CARB Readiness Status Locations read YES?

1. YES - all monitors have been completed and this vehicle is ready to be I/M or Emission Tested.
2. NO - then the following procedure needs to be followed to run/complete all available monitors.

Note. Only the monitors, which are not YES in the CARB Readiness Status, need to be completed. Specific criteria need to be met for each monitor. The most efficient order to run the monitors has been outlined below, including suggestions to aid the process.

This monitor requires a cool down cycle, usually an overnight soak for at least 8 hours without the engine running. The ambient temperature must decrease overnight - parking the vehicle outside is advised. To run this test the fuel level must be between 15-85% full. Criteria for EVAP monitor

1. Engine off time greater than one hour.
2. Fuel Level between 15% and 85%.
3. Start Up ECT and IAT within 10°C (18°F).
4. Vehicle started and run until Purge Monitor reports a result.

Note. If the vehicle does not report a result and the conditions where correct. It may take up to two weeks to fail the small leak monitor. DO NOT use this test to attempt to determine a fault. Use the appropriate service information procedure for finding a small leak. If there are no faults and the conditions are correct this test will run and report a pass. Note the Small leak test can find leaks less than 10 thousands of an inch. If a small leak is present it takes approximately one week of normal driving to report a failure.

The Catalyst and O2 Monitor information are acquired and processed at the same time. Most vehicles will need to be driven at highway speed (less than 50 mph) (73 km/h) for a few minutes. Some vehicles run the monitor at idle in drive. If the vehicle is equipped with a manual transmission, using 4th gear may assist in meeting the monitor running criteria.

1. Engine RPM between 1200 to 3000.
2. Engine temperature greater than 70°C (158°F)
3. Engine run time greater than 92 seconds
4. MAP between 10 - 20 kPa (7.5 - 15 Hg)
5. Vehicle speed between 20 - 70 mph (29-103 km/h)

After the vehicle has reached the below conditions and during a throttle decel the EGR monitor will run.

1. Engine RPM between 1375 - 2500
2. Engine temperature greater than 70°C (158°F)
3. Engine run time greater than 125 seconds
4. Vehicle speed between 25 - 70 mph (37-103 km/h)

This monitor is now continuously running once the heaters are energized. Pass information will be processed at power down.

The Misfire Monitor is a continuous two-trip monitor. The monitor uses two different tests/counters

Note. The Adaptive Numerator must be learned before the PCM will run the Misfire Monitor. The PCM updates the Adaptive Numerator at every key-ON, and is relearned after battery disconnect. The Misfire Monitor will not run until the Adaptive Numerator has updated since the last battery disconnect. If the Adaptive Numerator is equal to the default value then the PCM knows that the Adaptive Numerator has not been learned and does not permit the Misfire Monitor to run. If the Adaptive Numerator exceeds a calibrated percentage, the PCM sets a DTC for CKP NOT LEARNED and illuminates the MIL.

1. 200 Revolution Counter - Looks for misfire that can cause immediate catalyst damage.
2. 1000 Revolution Counter - Looks for misfire that can cause emissions to increase 1.5 times the Federal Test Procedure (FTP) standards. This test must also identify misfire percentages that might cause a "durability demonstration vehicle" to fail an Inspection and Maintenance Program tailpipe emissions test.
