DIAGNOSIS AND TESTING
| DTC | Description |
|---|---|
| VER 1 | TRANSFER CASE VERIFICATION TEST VER 1 |
| C1401 | TRANSFER CASE RANGE SELECT SWITCH CIRCUIT LOW |
| C1402 | TRANSFER CASE RANGE SELECT SWITCH CIRCUIT HIGH |
| C1404 | TRANSFER CASE RANGE POSITION SENSOR CIRCUIT LOW |
| C1405 | TRANSFER CASE RANGE POSITION SENSOR CIRCUIT HIGH |
| C1407 | TRANSFER CASE BRAKE CONTROL CIRCUIT LOW |
| C1408 | TRANSFER CASE BRAKE CONTROL CIRCUIT HIGH |
| C140B | TRANSFER CASE MOTOR CONTROL CIRCUIT LOW |
| C140C | TRANSFER CASE MOTOR CONTROL CIRCUIT HIGH |
| C230A | NEUTRAL INDICATOR CONTROL CIRCUIT LOW |
| C230B | NEUTRAL INDICATOR CONTROL CIRCUIT HIGH |
DTC INDEX
Diagnostic Test
- TRANSFER CASE VERIFICATION TEST - VER 1 Disconnect all jumper wires and reconnect all previously disconnected components and connectors. With the scan tool, Clear DTCs. Make sure that all accessories are turned off and that the battery is fully charged. Move the Transfer Case Selector Switch to the desired position. Test drive the vehicle in each Transfer Case range and verify proper operation in each range. NOTE: To select or deselect 2WD, AWD or 4HI mode, vehicle speed must be below 55 MPH (88 KM/H) with all wheels at vehicle speed. NOTE: Shifts will not take place with a wheel speed difference of greater than 13 MPH between the front and rear wheels. NOTE: To select or deselect 4LO (if equipped), vehicle speed must be below 3 MPH (5 KM/H) with the ignition ON and the transmission in neutral (auto trans) or the clutch pedal pressed (man trans). NOTE: To select or deselect Transfer Case Neutral, vehicle speed must be 0 MPH with the ignition ON, engine OFF, the brake pedal applied, and the transmission in neutral (auto trans) or the clutch pedal pressed (man trans). Press the Neutral button (if equipped) on the Transfer Case Selector Switch until the Neutral Indicator is illuminated. WARNING: Apply the parking brake. The vehicle may roll with the Transfer Case in neutral. NOTE: To verify that the Transfer Case is in Neutral, shift the automatic transmission into reverse and release the brake pedal for three seconds or shift the manual transmission into gear and slowly release the clutch pedal. There should be no vehicle movement if the Transfer Case is in Neutral. With the scan tool, read DTCs in the Front Control Module (FCM) and the Instrument Cluster Module (CCN). Are there any Transfer Case DTCs present in the Front Control Module (FCM) or the Instrument Cluster Module (CCN)? Yes : Return to the symptom list and perform the appropriate «DIAGNOSTIC TEST»(ref-212831-S15318701702005122700000) . NO : Repair is complete.
