HVAC - Airflow Distribution - Front: Overhaul Dodge Durango II

Automatic HVAC System 21 illustrations ~1241 words

DISASSEMBLY

Note. The front HVAC housing must be removed from the vehicle and disassembled for service of the A/C evaporator, recirculation-air door, mode-air doors, blend-air doors and linkage.

Scheme 378

Scheme 378: DISASSEMBLY
Scheme 378: DISASSEMBLY

Scheme 379

Scheme 379
Scheme 379

Scheme 380

Scheme 380
Scheme 380

Scheme 381

Scheme 381
Scheme 381

Scheme 382

Scheme 382
Scheme 382

Scheme 383

Scheme 383
Scheme 383

Scheme 384

Scheme 384
Scheme 384

Scheme 385

Scheme 385
Scheme 385

Scheme 386

Scheme 386
Scheme 386
  1. Remove the front HVAC housing (1) and place it on a workbench (Refer to «REMOVAL»(ref-212853-S34186963672005122700000) ).
  2. Disconnect the HVAC wire harness (2) from the recirculation door actuator (3).
  3. Remove the screws (4) that secure the air inlet housing (5) to the HVAC housing.
  4. Remove the air inlet housing from the HVAC housing.
  5. If required, remove the recirculation door actuator from the air inlet housing (Refer to «ACTUATOR-RECIRCULATION DOOR»(ref-212851-S11822758312005122700000) ).
  6. Disconnect the HVAC wire harness (1) from blend door actuator (2) and two mode door actuators (3).
  7. Remove the blend door actuator and the mode door actuators from the HVAC housing (4) (Refer to «ACTUATOR-BLEND DOOR»(ref-212851-S28806104232005122700000) ) and (Refer to «ACTUATOR-MODE DOOR»(ref-212851-S11925140292005122700000) ).
  8. Remove the two actuator couplers (1) from the left end of the HVAC housing (2).
  9. Carefully remove the foam seal (1) from the flange on the HVAC housing (2). If the seal is deformed or damaged, it must be replaced.
  10. Remove the screw (3) that secures the heater core tube retaining bracket (4) to the top of the HVAC housing.
  11. Remove the heater core tube retaining bracket from the HVAC housing.
  12. Remove the two screws (1) that secure the HVAC housing retaining bracket (2) to the top of the HVAC housing (3).
  13. Remove the HVAC housing retaining bracket from the HVAC housing.
  14. Remove the two screws (4) that secure the heater core retaining bracket (5) to the top of the HVAC housing.
  15. Carefully remove the heater core (6) from the HVAC housing.
  16. Disconnect the HVAC wiring harness (1) from the evaporator temperature sensor (2) and the blower motor (3).
  17. Remove the blower motor from the HVAC housing (4) (Refer to «REMOVAL»(ref-212853-S04434938772005122700000) ).
  18. Remove the evaporator temperature sensor (Refer to «SENSOR-EVAPORATOR TEMPERATURE»(ref-212851-S25345641672005122700000) ).
  19. Disconnect the HVAC wiring harness (1) from the blower motor resistor block power module (2), depending on application.
  20. If necessary, remove the blower motor resistor block or power module, depending on application (Refer to «RESISTOR BLOCK-BLOWER MOTOR»(ref-212851-S15381382052005122700000) ) or (Refer to «MODULE-POWER-BLOWER MOTOR»(ref-212851-S23899404152005122700000) ).
  21. Remove the HVAC wiring harness from the HVAC housing (3).
  22. Remove the screws (4) that secure the two halves of the HVAC housing together.
  23. Separate the two halves of the HVAC housing.
  24. If necessary, remove the mode-air doors from the upper half of the HVAC housing.
  25. Carefully lift the A/C evaporator (1) and insulator (3) out of the top of the HVAC housing (2).
  26. Remove the blend-air doors and linkage (1), mode-air door (2), baffle (3) and the duct plate (4) from the lower half of the HVAC housing (6).
  27. If necessary, remove the floor distribution duct (5) from the HVAC housing (Refer to «REMOVAL»(ref-212853-S35252385882005122700000) ).

Scheme 387

Scheme 387: ASSEMBLY
Scheme 387: ASSEMBLY

Scheme 388

Scheme 388
Scheme 388

Scheme 389

Scheme 389
Scheme 389

Scheme 390

Scheme 390
Scheme 390

Scheme 391

Scheme 391
Scheme 391

Scheme 392

Scheme 392
Scheme 392

Scheme 393

Scheme 393
Scheme 393

Scheme 394

Scheme 394
Scheme 394

Scheme 395

Scheme 395
Scheme 395

Scheme 396

Scheme 396
Scheme 396
  1. If removed, install the floor distribution duct (5) to the HVAC housing (6) (Refer to «INSTALLATION»(ref-212853-S02581810432005122700000) ).
  2. Install the blend-air doors and linkage (1), mode-air door (2), baffle (3) and the duct plate (4) into the lower half of the HVAC housing.
  3. Install the A/C evaporator (1) into the lower half of the HVAC housing (2). Make sure that the evaporator drain is clean and unrestricted and that the evaporator insulator (3) is properly installed.
  4. If removed, install the mode-air doors into the upper half of the HVAC housing (2).
  5. Align the ends of the blend-air door pivot shafts (1) to the openings in the upper half of the HVAC housing and install the upper housing half to the lower housing half.
  6. Install the screws (4) that secure the two halves of the HVAC housing (3) together. Tighten the screws to 2.2 N.m (20 in lbs.).
  7. Install the HVAC wiring harness (1). Make sure the harness is routed through all wiring retainers.
  8. If removed, install the blower motor resistor block or power module (2), depending on application.
  9. Connect the HVAC wire harness to the blower motor resistor block or power module, depending on application.
  10. Install the evaporator temperature sensor (2) (Refer to «SENSOR-EVAPORATOR TEMPERATURE»(ref-212851-S25345641672005122700000) ).
  11. Install the blower motor (3) to the HVAC housing (4) (Refer to «INSTALLATION»(ref-212853-S16376825882005122700000) ).
  12. Connect the HVAC wire harness (1) to the evaporator temperature sensor and the blower motor.
  13. Carefully install the heater core (6) into the top of the HVAC housing (3). Make sure that the heater core insulator is properly positioned.
  14. Install the two screws (4) that secure the heater core retaining bracket (5) to the HVAC housing. Tighten the screws to 2.2 N.m (20 in. lbs.).
  15. Install the HVAC housing bracket (2) to the top of HVAC housing.
  16. Install the two screws (1) that secure the HVAC housing bracket to the HVAC housing. Tighten the screws to 2.2 N.m (20 in. lbs.).
  17. Install the heater core tube retaining bracket (4) to the top of the HVAC housing (2).
  18. Install the screw (3) that secures the heater core tube retaining bracket to the HVAC housing. Tighten the screw to 2.2 N.m (20 in. lbs.).
  19. Install the foam seal (1) to the flange on the HVAC housing.
  20. Align the two actuator couplers (1) with the mode-air door pivot shafts and install the couplers into the left side of the HVAC housing. Be sure to install the couplers with the coupler arm located between the two stop tabs on the HVAC housing.
  21. Install the blend door actuator (2) and the mode door actuators (3) to the HVAC housing (4) (Refer to «ACTUATOR-BLEND DOOR»(ref-212851-S28806104232005122700000) ) and (Refer to «ACTUATOR-MODE DOOR»(ref-212851-S11925140292005122700000) ).
  22. Connect the HVAC wire harness (1) to the blend door actuator and the mode door actuators.
  23. If removed, install the recirculation door actuator (3) to the air inlet housing (5).
  24. Install the air inlet housing onto the top of the HVAC housing (1).
  25. Install the screws (4) that secure the air inlet housing to the HVAC housing. Make sure the HVAC wire harness retainer is properly installed.
  26. Connect the HVAC wire harness to the recirculation door actuator (3).
  27. Install the HVAC housing (Refer to «INSTALLATION»(ref-212853-S09428561812005122700000) ).

Scheme 397

Scheme 397: INSTALLATION
Scheme 397: INSTALLATION

Scheme 398

Scheme 398
Scheme 398
  1. Position the HVAC housing (2) into the passenger compartment with the mounting studs and the condensate drain tube in their proper mounting locations in the dash panel (3).
  2. Loosely install the two bolts (1) that secure the HVAC housing to the passenger compartment side of the dash panel.
  3. Install the four nuts (1) that secure the HVAC housing (2) to the engine compartment side of the dash panel (3). Tighten the nuts to 7 N.m (62 in. lbs.).
  4. Tighten the two bolts that secure the HVAC housing to the passenger compartment side of the dash panel. Tighten the bolt(s) to 3 N.m (26 in. lbs.).
  5. Connect the intermediate floor distribution duct to front floor distribution duct.
  6. Install the instrument panel (Refer to «ASSEMBLY-INSTRUMENT PANEL»(ref-212841-S41548306542005122700000) ).
  7. Remove previously installed plugs or caps and reconnect the heater hoses to the heater core tubes.
  8. Remove previously installed plugs or caps and reconnect the suction line and liquid line to the expansion valve(Refer to «LINE-A/C LIQUID»(ref-212855-S20817824442005122700000) ).
  9. Reconnect the negative battery cable.
  10. Refill the engine cooling system (Refer to «REFILLING COOLING SYSTEM»(ref-212747-S15342466592005122700000) ).
  11. Evacuate the refrigerant system (Refer to «REFRIGERANT SYSTEM EVACUATE»(ref-212855-S27996684662005122700000) ).
  12. Charge the refrigerant system (Refer to «REFRIGERANT SYSTEM CHARGE»(ref-212855-S42838088152005122700000) ).
