12 VOLT POWER
The 12v power outlet consists of two major components: a knob and heating element unit, and a cigar lighter base or receptacle shell. The receptacle shell is connected to ground, and an insulated contact in the bottom of the shell is connected to battery current.
The cigar lighter knob and heating element are encased within a spring-loaded housing, which also features a sliding protective heat shield. When the knob and heating element are inserted in the receptacle shell, the heating element resistor coil is grounded through its housing to the receptacle shell. If the cigar lighter knob is pushed inward, the heat shield slides up toward the knob exposing the heating element, and the heating element extends from the housing toward the insulated contact in the bottom of the receptacle shell.
Two small spring-clip retainers are located on either side of the insulated contact inside the bottom of the receptacle shell. These clips engage and hold the heating element against the insulated contact long enough for the resistor coil to heat up. When the heating element is engaged with the contact, battery current can flow through the resistor coil to ground, causing the resistor coil to heat.
When the resistor coil becomes sufficiently heated, excess heat radiates from the heating element causing the spring-clips to expand. Once the spring-clips expand far enough to release the heating element, the spring-loaded housing forces the knob and heating element to pop back outward to their relaxed position. When the cigar lighter knob and element are pulled out of the receptacle shell, the protective heat shield slides downward on the housing so that the heating element is recessed and shielded around its circumference for safety.
The power outlet base or receptacle shell is connected to ground, and an insulated contact in the bottom of the shell is connected to battery current. The power outlet receives battery voltage from a fuse in the Power Distribution Center (PDC) when the ignition is in the ON or ACC positions.
Scheme 9
Scheme 10
- Disconnect and isolate the battery negative cable.
- Look inside and note position of the retaining bosses (2).
- Insert Remover, Power Outlet (special tool #10246, Remover, Power Outlet) (1) into the retaining bosses (2) of the power outlet.
- Pull out the base through the mounting ring by gently rocking the tool.
- Disconnect the harness (1) from the power outlet (2).
- Set the base aside and remove the base mount ring.
- Connect the wire connector (1) to the power outlet receptacle (2).
- Install the power outlet mount into the panel.
- Align the splines on the outside of the power outlet receptacle base connector receptacle with the grooves on the inside of the mount.
- Press firmly on the power outlet receptacle base until the retaining bosses of the mount are fully engaged in their receptacles.
- Connect the battery negative cable.
