TORQUE
| DESCRIPTION | N-m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Plug, Detent | 16-24 | 12-18 | |
| Plug, Drain/Fill | 20-34 | 15-25 | |
| Bolt, Extension Housing | 16-24 | 12-18 | |
| Bolt, Case Half | 20-27 | 15-24 | |
| Screw, Oil Pump | 12-16 | 8-12 | |
| Nuts, Mounting | 30-41 | 20-30 | |
| Bolts, Shift Motor and Mode Sensor Assembly | 16-24 | 12-18 | |
| Bolts , Transfer Case to Transmission | 27-34 | 20-25 |
TORQUE
Scheme 88
Scheme 89
Scheme 90
Scheme 91
Scheme 92
Scheme 93
Scheme 94
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
Scheme 101
| 1 - I.D. TAG |
|---|
| 2 - FILL PLUG |
| 3 - DRAIN PLUG |
The fill (2) (Scheme 101) and drain (3) plugs are both in the rear case.
- Raise vehicle.
- Position drain pan under transfer case.
- Remove drain and fill plugs and drain lubricant completely.
- Install drain plug. Tighten plug to 20-34 N.m (15-25 ft. lbs.).
- Remove drain pan.
- Fill transfer case to bottom edge of fill plug opening with Mopar® ATF +4, Automatic Transmission fluid.
- Install and tighten fill plug to 20-34 N.m (15-25 ft. lbs.).
- Lower vehicle.
