Front Suspension: Specifications Dodge Dakota III рестайлинг

Suspension Front 19 illustrations ~308 words

TORQUE

DESCRIPTIONN.mFt. Lbs.In. Lbs.
Shock Module Upper Nut to Spring Upper Mount Plate4533
Shock Module Upper Nuts to Frame6145
Shock Absorber Lower Bolt210155
Lower Control Arm Frame Nuts149110
Lower Control Arm Ball Joint Nut12995
Upper Control Arm Frame Nuts176130
Upper Control Arm Ball Joint Nut9570
Stabilizer Bar Retainer Bracket Frame Bolts6145
Stabilizer Link to Lower Control Arm10275
Stabilizer Link Stabilizer Bar Nut2317
Hub/Bearing Bolts163120
Tie Rod End to Knuckle Nut8160
Tie Rod End Jam Nut10880

TORQUE SPECIFICATIONS

Scheme 1

Scheme 1: FRONT SUSPENSION
Scheme 1: FRONT SUSPENSION

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Raise and support the vehicle.
  2. Remove the wheel and tire assembly.
  3. Remove the disc brake caliper assembly. Refer to «Brakes/Hydraulic/Mechanical/CALIPER, Disc Brake - Removal»(ref-352626-S27848961612010010600000) .
  4. Remove the disc brake rotor. Refer to «Brakes/Hydraulic/Mechanical/ROTOR, Brake - Removal»(ref-352626-S16824195272010010600000) .
  5. Disconnect the wheel speed sensor at the wheel well.
  6. Remove tie rod end jam nut (1).
  7. Disconnect the tie rod (2) from the knuckle using remover C-3894-A (1). Refer to «Steering/Linkage/END, Tie Rod - Removal»(ref-352627-S31819065002010010600000) . 1 - UPPER BALL JOINT NUT 2 - UPPER BALL JOINT 3 - UPPER CONTROL ARM 4 - LOWER CONTROL ARM 5 - LOWER BALL JOINT 6 - LOWER BALL JOINT NUT 7 - KNUCKLE
  8. Remove the front halfshaft nut 4X4 .
  9. Remove the upper ball joint nut (1).
  10. Separate the upper ball joint (1) from the steering knuckle (3) with Remover 8677 (2).
  11. Remove the lower ball joint nut (3). Separate the lower ball joint (3) from the steering knuckle (1) with puller 8677 (2).
  12. Remove the steering knuckle. See «Front Suspension/Front/KNUCKLE, Steering - Removal»(ref-352625-S34563634242010010600000) . 1 - SHOCK ASSEMBLY 2 - UPPER SHOCK NUTS 3 - LOWER CONTROL ARM 4 - LOWER SHOCK BOLT 5 - LOWER SHOCK BOLT NUT
  13. Remove the stabilizer bar link. See «Front Suspension/Front/LINK, Stabilizer Bar - Removal»(ref-352625-S32515934402010010600000) .
  14. Remove the shock absorber lower bolt (5) and nut (4). 1 - UPPER CONTROL ARM 2 - UPPER BOLT 3 - LOWER BOLT 4 - WASHER 5 - NUT 6 - LOWER CONTROL ARM
  15. Remove the lower control arm bolts (5) , nuts (3) and washers (4).
  16. Remove the lower control arm (6) from the vehicle.
