Audio System (Amplifier) - Electrical Diagnostics: Diagnosis Dodge Dakota III рестайлинг

Entertainment Systems 9 illustrations ~1780 words

DIAGNOSTIC CODE INDEX

DTCDescription
B1460CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1461CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1462CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1463CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1464CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1465CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1466CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1467CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1468CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1469CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B146ACHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B146BCHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B146CCHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B146DCHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B146ECHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B146FCHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1470CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1471CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1472CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1473CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1474CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1475CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1476CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1477CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1478CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1479CHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B147ACHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B147BCHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B147CCHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B147DCHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B147ECHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B147FCHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1480CHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1481CHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1482CHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1483CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1484CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1485CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1486CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1487CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1488CABIN EQ MISMATCH PERFORMANCE
B210DBATTERY VOLTAGE LOW
B210EBATTERY VOLTAGE HIGH
B221FAMPLIFIER INTERNAL
U0019CAN B BUS
U0020CAN B BUS OFF PERFORMANCE
U0141LOST COMMUNICATION WITH FRONT CONTROL MODULE
U0151LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER (ORC)
U0155LOST COMMUNICATION WITH CLUSTER/CCN
U0156LOST COMMUNICATION WITH EOM
U0164LOST COMMUNICATION WITH HVAC CONTROL MODULE
U0168LOST COMMUNICATION WITH VEHICLE SECURITY CONTROL MODULE (SKREEM/WCM)
U0184LOST COMMUNICATION WITH RADIO
U0197LOST COMMUNICATION WITH HANDS FREE PHONE MODULE

DIAGNOSTIC CODE INDEX

Diagnostic Test

  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off, and then on again. With the scan tool, read Amplifier DTCs. Does the scan tool display active: B1460-CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)

Scheme 61

Scheme 61: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off, and then on again. With the scan tool, read Amplifier DTCs. Does the scan tool display active: B1465-CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .

Scheme 62

Scheme 62: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off, and then on again. With the scan tool, read Amplifier DTCs. Does the scan tool display active: B146A-CHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the service information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .

Scheme 63

Scheme 63: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off, and then on again. With the scan tool, read Amplifier DTCs. Does the scan tool display active: B146F-CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the service information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .

Scheme 64

Scheme 64: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off, and then on again. With the scan tool, read Amplifier DTCs. Does the scan tool display active: B1474-CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the service information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .

Scheme 65

Scheme 65: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off, and then on again. With the scan tool, read Amplifier DTCs. Does the scan tool display active: B1479-CHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the service information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .

Scheme 66

Scheme 66: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off, and then on again. With the scan tool, read Amplifier DTCs. Does the scan tool display active: B147E-CHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .

Scheme 67

Scheme 67: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off and then on again. Using the scan tool, read the Amplifier DTCs. Does the scan tool display active: B1483-CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the service information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) . No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .

Scheme 68

Scheme 68: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on. Turn the radio on. With the scan tool, erase Amplifier DTCs. With the scan tool, reset the amplifier. With the scan tool, read Amplifier DTCs. Does the scan tool display active: B1488-CABIN EQ MISMATCH PERFORMANCE? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)
  2. CHECK AMPLIFIER BUSSED INPUTS/OUTPUTS With the scan tool in Amplifier Data Display, read the Cabin EQ# settings in the Bussed Inputs and Bussed Outputs Service Information. NOTE: The Cabin EQ# settings in the Inputs/Outputs service information should match one another. The Cabin EQ# in the Inputs section is the information that is received form the FCM. The Cabin EQ# in the Outputs section is the information that is Stored in the Amplifier's memory. The Cabin EQ# settings are as follows: $51: HB Premium 1 (w/o Subwoofer) $52: HB Premium 2 (with Subwoofer)
  3. VERIFY COMMUNICATION WITH FRONT CONTROL MODULE With the scan tool in ECU VIEW, read active modules on the bus. Does the scan tool show the Front Control Module active on the bus? Yes Go to step 4 No Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)
  4. CHECK FRONT CONTROL MODULE FOR ACTIVE DTCs With the scan tool, erase FCM DTCs. Turn the ignition off. Wait approximately 10 seconds. Turn the ignition on. With the scan tool, read FCM DTCs. Are any active DTCs present? Yes Refer to the «DIAGNOSTIC CODE INDEX»(ref-352654-S13784041962010010600000) for problems related to the Front Control Module. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) No Replace the Front Control Module in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off and then on again. With the scan tool, read the Amplifier DTCs. Does the scan tool display active: B210D-BATTERY VOLTAGE LOW? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .
  2. CHECK THE BATTERY VOLTAGE TO THE AMPLIFIER With the scan tool in Data Display, read the Amplifier battery voltage. Is the battery voltage less than 9.0 volts? Yes Go to step 3 No Replace the Amplifier in accordance with the Service Information. Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .
  3. CHECK FOR CHARGING SYSTEM RELATED DTCs IN THE POWERTRAIN CONTROL MODULE (PCM) With the scan tool in ECU View, select PCM and check for any charging system related DTCs. Does the scan tool display any charging system related DTCs? Yes Diagnose and repair the DTCs. Refer to «DTC-Based Diagnostics/MODULE, Powertrain Control (PCM) - Diagnosis and Testing»(/dodge/dakota/iii-2007-2011/remont/testing-diagnostics/#diagnostic-code-index) . No Replace the Amplifier in accordance with the Service Information. Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on, then off, and then on again. With the scan tool, read Amplifier DTCs. Does the scan tool display active: B210E-BATTERY VOLTAGE HIGH? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)
  2. CHECK THE BATTERY VOLTAGE TO THE AMPLIFIER With the scan tool in Data Display, read Amplifier battery voltage. Is the battery voltage greater than 16.5 volts? Yes Go to step 3 No Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)
  3. CHECK FOR CHARGING SYSTEM RELATED DTCs IN THE POWERTRAIN CONTROL MODULE (PCM) With the scan tool in ECU View, select PCM and check for any Charging System related DTCs. Does the scan tool display any Charging System related DTCs? Yes Go to and perform the appropriate diagnostic procedure. No Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000)
  1. AMPLIFIER When this code is set, the Amplifier must be replaced. Repair Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Front Control (FCM) - Standard Procedure»(ref-352654-S37713291802010010600000) .

Scheme 69

Scheme 69: Circuit Schematic

Refer to DTC-Based Diagnostics/MODULE, Front Control (FCM) - Diagnosis and Testing for the diagnostic test procedure.

Refer to DTC-Based Diagnostics/MODULE, Front Control (FCM) - Diagnosis and Testing for the diagnostic test procedure.

Refer to DTC-Based Diagnostics/MODULE, Front Control (FCM) - Diagnosis and Testing for the diagnostic test procedure.

Refer to DTC-Based Diagnostics/MODULE, Front Control (FCM) - Diagnosis and Testing for the diagnostic test procedure.

Refer to DTC-Based Diagnostics/MODULE, Front Control (FCM) - Diagnosis and Testing for the diagnostic test procedure.

Refer to DTC-Based Diagnostics/MODULE, Front Control (FCM) - Diagnosis and Testing for the diagnostic test procedure.

Refer to DTC-Based Diagnostics/MODULE, Front Control (FCM) - Diagnosis and Testing for the diagnostic test procedure.
