SPECIFICATIONS - TRANSFER CASE - NV233
| DESCRIPTION | N-m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Plug, Detent | 16-24 | 12-18 | |
| Plug, Drain/Fill | 20-34 | 15-25 | |
| Bolt, Front Brg. Retainer | 16-25 | 12-18 | |
| Bolt, Case Half | 27-34 | 20-25 | |
| Nut, Companion Flange | 122-176 | 90-130 | |
| Bolt, Shift motor and Mode Sensor Assembly | 16-25 | 12-18 | |
| Bolt, Rear Retainer | 27-34 | 20-25 | |
| Bolt, Extension Housing | 27-34 | 20-25 | |
| Nut, Mounting | 27-34 | 20-25 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
| 1 - I.D. TAG |
|---|
| 2 - FILL PLUG |
| 3 - DRAIN PLUG |
The fill (2) and drain (3) plugs are both in the rear case. (Scheme 15)
- Raise vehicle.
- Position drain pan under transfer case.
- Remove drain and fill plugs and drain lubricant completely.
- Install drain plug. Tighten plug to 20-34 N.m (15-25 ft. lbs.).
- Remove drain pan.
- Fill transfer case to bottom edge of fill plug opening with Mopar® ATF +4, Automatic Transmission fluid.
- Install and tighten fill plug to 20-34 N.m (15-25 ft. lbs.).
- Lower vehicle.
