Engine Controls - Tests W/codes - 5.2L: Overview Dodge Dakota WS

Testing & Diagnostics 20 illustrations ~998 words

MODEL IDENTIFICATION

Vehicle body codes are used throughout self-diagnostic tests. See VEHICLE BODY IDENTIFICATION table for model identification.

Model NameBody Type
DakotaAN
PickupBR
Ram Van/Ram WagonAB

VEHICLE BODY IDENTIFICATION

CONNECTOR IDENTIFICATION

ConnectorSee
A/C Clutch Relay(Scheme 1), (Scheme 2) & (Scheme 3)
Auto Shutdown (ASD) Relay(Scheme 4) & see scheme 5
Camshaft Sensor(Scheme 5)
Crankshaft Sensor(Scheme 6)
Engine Coolant Temperature (ECT) Sensor(Scheme 8)
Evaporative Purge Solenoid(Scheme 9)
Exhaust Gas Recirculation (EGR) Solenoid(Scheme 7)
Fuel Pump(Scheme 10)
Fuel Pump RelaySee scheme 12
Idle Air Control (IAC) Motor(Scheme 11)
Intake Air Temperature (IAT) Sensor(Scheme 12)
Manifold Absolute Pressure (MAP) Sensor(Scheme 13)
Overdrive Solenoid(Scheme 14)
Oxygen Sensor(Scheme 15) & see scheme 18
Powertrain Control Module (PCM)(Scheme 20)
Torque Converter Clutch (TCC) Relay(Scheme 16)
Throttle Position Sensor (TPS)(Scheme 17)
Transmission Solenoid(Scheme 18)
Transmission Temperature Sensor(Scheme 19)

CONNECTOR IDENTIFICATION

TerminalWire ColorFunction
ADark BlueIgnition 12-Volt Feed
BRed/Light GreenOutput
CDark Blue/OrangeControl
DDark Blue/BlackBattery Voltage

A/C CLUTCH RELAY CONNECTOR TERMINAL ID (AB BODY)

Scheme 1

Scheme 1
Scheme 1
TerminalWire ColorFunction
ADark BlueIgnition 12-Volt Feed
BGrayBattery Voltage
CDark Blue/OrangeControl
DDark Blue/BlackOutput

A/C CLUTCH RELAY CONNECTOR TERMINAL ID (AN BODY)

Scheme 2

Scheme 2
Scheme 2
TerminalWire ColorFunction
ALight Green/BlackIgnition 12-Volt Feed
BDark Blue/BlackOutput
CDark Blue/OrangeControl
DVioletBattery Voltage

A/C CLUTCH RELAY CONNECTOR TERMINAL ID (BR BODY)

Scheme 3

Scheme 3
Scheme 3
TerminalWire ColorFunction
ADark BlueIgnition 12-Volt Feed
BRed/WhiteBattery Voltage
CDark Blue/YellowControl
DDark Green/OrangeOutput

ASD RELAY CONNECTOR TERMINAL ID (AN BODY)

Scheme 4

Scheme 4
Scheme 4
TerminalWire ColorFunction
A(1) Dark Blue/WhiteIgnition 12-Volt Feed
B(2) RedBattery Voltage
CDark Blue/YellowControl
DDark Green/OrangeOutput
(1) Light Green/Black on BR body. (2) Gray/White on BR body.
(1)Light Green/Black on BR body.
(2)Gray/White on BR body.

ASD RELAY CONNECTOR TERMINAL ID (AB/BR BODY)

TerminalWire ColorFunction
1Tan/YellowSignal
2Black/Light BlueGround
3Orange8-Volt Supply

CAMSHAFT POSITION SENSOR CONNECTOR TERMINAL ID

Scheme 5

Scheme 5
Scheme 5
TerminalWire ColorFunction
1Gray/BlackSignal
2Black/Light BlueGround
3Orange8-Volt Supply

CRANKSHAFT POSITION SENSOR CONNECTOR TERMINAL ID

Scheme 6

Scheme 6
Scheme 6
TerminalWire ColorFunction
1. Light Green/BlackIgn. 12-Volt Feed
2Gray/YellowControl

EGR SOLENOID CONNECTOR TERMINAL IDENTIFICATION

Scheme 7

Scheme 7
Scheme 7
TerminalWire ColorFunction
1Tan/BlackSignal
2Black/Light BlueGround

ECT SENSOR CONNECTOR TERMINAL IDENTIFICATION

Scheme 8

Scheme 8
Scheme 8
TerminalWire ColorFunction
1(1) Light BlueIgnition 12-Volt Feed
2Pink/BlackControl
(1) Light Green/Black on BR body.
(1)Light Green/Black on BR body.

EVAPORATIVE PURGE SOLENOID CONNECTOR TERMINAL ID

Scheme 9

Scheme 9
Scheme 9
TerminalWire ColorFunction
ADark BlueIgnition 12-Volt Feed
BRed/WhiteBattery Voltage
CDark Blue/YellowASD Relay Control
DDrk Green/BlackFuel Pump Relay Output
EN/aNot Used

FUEL PUMP RELAY CONNECTOR TERMINAL ID (AN BODY)

Scheme 10

Scheme 10
Scheme 10
TerminalWire ColorFunction
ALight Green/BlackIgnition 12-Volt Feed
BDark Green/BlackBattery Voltage
CDark Blue/YellowASD Relay Control
DRed/WhiteFuel Pump Relay Output
EN/aNot Used

FUEL PUMP RELAY CONNECTOR TERMINAL ID (BR BODY)

TerminalWire ColorFunction
1Gray/RedIAC Driver No. 3
2Yellow/BlackIAC Driver No. 2
3Brown/WhiteIAC Driver No. 1
4Violet/BlackIAC Driver No. 4

IAC MOTOR CONNECTOR TERMINAL ID

Scheme 11

Scheme 11
Scheme 11
TerminalWire ColorFunction
1Black/RedSignal
2Black/Light BlueGround

IAT SENSOR CONNECTOR TERMINAL ID

Scheme 12

Scheme 12
Scheme 12
TerminalWire ColorFunction
1Black/Light BlueGround
2Dark Green/RedSignal
3Violet/White5-Volt Supply

MAP SENSOR CONNECTOR TERMINAL ID

Scheme 13

Scheme 13
Scheme 13
TerminalWire ColorFunction
1Orange/BlackTCC Solenoid Control
2Light Green/Black12-Volt Supply
3BrownSignal

OVERDRIVE SOLENOID CONNECTOR TERMINAL IDENTIFICATION

Scheme 14

Scheme 14
Scheme 14
TerminalWire ColorFunction
1Black/Light BlueSensor Ground
2(1) Dark Green/WhiteSignal
3(2) BlackHeater Ground
4Dark Green/OrangeHeater Feed
(1) Tan/White on BR body. (2) Black/White on BR body.
(1)Tan/White on BR body.
(2)Black/White on BR body.

OXYGEN SENSOR CONNECTOR TERMINAL ID (LEFT SENSOR)

Scheme 15

Scheme 15
Scheme 15
TerminalWire ColorFunction
1Black/Light BlueSensor Ground
2(1) Black/Dark GreenSignal
3(2) Black/WhiteHeater Ground
4Dark Green/OrangeHeater Feed
(1) Tan/White on AB and AN body. (2) Black/Tan on AB and AN body.
(1)Tan/White on AB and AN body.
(2)Black/Tan on AB and AN body.

O2 SENSOR CONNECTOR TERMINAL ID (Right Sensor)

TerminalWire ColorFunction
ADark BlueIgnition 12-Volt Feed
BDark BlueBattery Voltage
COrange/BlackControl
DDark Blue/WhiteOutput
EBlackGround

TCC RELAY CONNECTOR TERMINAL IDENTIFICATION

Scheme 16

Scheme 16
Scheme 16
TerminalWire ColorFunction
1Black/Light BlueGround
2Orange/Dark BlueSignal
3Violet/White5-Volt Supply

TPS CONNECTOR TERMINAL IDENTIFICATION

Scheme 17

Scheme 17
Scheme 17
TerminalWire ColorFunction
1BrownOverdrive Solenoid Control
2(1) Dark BlueIgnition 12-Volt Feed
3Orange/BlackTCC Solenoid Control
(1) Light Green/Black on BR body.
(1)Light Green/Black on BR body.

TRANSMISSION SOLENOID CONNECTOR TERMINAL ID

Scheme 18

Scheme 18
Scheme 18
TerminalWire ColorFunction
1VioletSensor Signal
2Black/Light BlueGround

TRANSMISSION TEMPERATURE SENSOR CONNECTOR TERMINAL ID

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
CAUTIONWhen battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section before disconnecting battery.

TEST NTC-9A - CHECKING SOLENOID OPERATIONS

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION in this article. For wiring diagram, see appropriate WIRING DIAGRAMS .

  1. Using DRB, actuate purge solenoid. While touching top of purge solenoid, feel for operation. If purge solenoid does not operate, replace purge solenoid. Perform «TEST VER-2»(ref-10877-S16703568862000111300000) .
  2. If purge solenoid operates, actuate EGR solenoid. While touching top of EGR solenoid, feel for operation. If EGR solenoid does not operate, replace EGR solenoid. Perform TEST VER-2. If EGR solenoid operates, test is complete.

TEST NS-7A - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION in this article. For wiring diagram, see appropriate WIRING DIAGRAMS .

  1. Disconnect Idle Air Control (IAC) motor connector. Turn ignition on. Using DRB, actuate IAC motor. Using DRB in voltmeter mode, check voltage on IAC motor connector, driver No. 3 circuit (Gray/Red wire on AB, AN and BR bodies). If voltage is less than one volt, go to TEST NS-7B.
  2. If voltage is more than one volt, check voltage on IAC motor connector, driver No. 1 circuit (Brown/White wire). If voltage is less than one volt, go to «TEST NS-7C»(ref-10877-S20779499432000111300000) .
  3. If voltage is more than one volt, check voltage on IAC motor connector, driver No. 4 circuit (Violet/Black wire on AB, AN and BR bodies). If voltage is less than one volt, go to «TEST NS-7D»(ref-10877-S02589309502000111300000) .
  4. If voltage is more than one volt, check voltage on IAC motor connector, driver No. 2 circuit (Yellow/Black wire on AB, AN and BR bodies). If voltage is less than one volt, go to «TEST NS-7E»(ref-10877-S24612009172000111300000) .
  5. If voltage is more than one volt, turn ignition off. Remove IAC motor from throttle body. Reconnect IAC motor connector. Turn ignition on. Using DRB, actuate IAC motor. If IAC motor pintle moves in and out, go to «TEST NS-8A»(ref-10877-S38592155882000111300000) . If IAC motor pintle does not move in and out, replace IAC motor. Perform «TEST VER-1»(ref-10877-S34287435522000111300000) .

TEST NS-7B - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION in this article. For wiring diagram, see WIRING DIAGRAMS .

  1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect connectors for damaged, pushed-out or miswired terminals. Repair as required. Perform «TEST VER-1»(ref-10877-S34287435522000111300000) . If PCM terminals are okay, go to next step.
  2. Using an external ohmmeter, check resistance of driver No. 3 circuit (Gray/Red wire on AB, AN and BR bodies) between IAC motor connector and PCM connector terminal No. 39. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-1. If resistance is more than 5 ohms, repair open Gray/Red wire or Yellow/Black wire. Perform TEST VER-1.

TEST NS-7C - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION in this article. For wiring diagram, see appropriate WIRING DIAGRAMS .

  1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect connectors for damaged, pushed-out or miswired terminals. Repair as required. Perform «TEST VER-1»(ref-10877-S34287435522000111300000) . If PCM terminals are okay, go to next step.
  2. Using an external ohmmeter, check resistance of driver No. 1 circuit (Brown/White wire) between IAC motor connector and PCM connector terminal No. 40. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-1. If resistance is more than 5 ohms, repair open Brown/White wire. Perform TEST VER-1.

TEST NS-7D - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION in this article. For wiring diagram, see appropriate WIRING DIAGRAMS .

  1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect connectors for damaged, pushed-out or miswired terminals. Repair as required. Perform «TEST VER-1»(ref-10877-S34287435522000111300000) . If PCM terminals are okay, go to next step.
  2. Using an external ohmmeter, check resistance of driver No. 4 circuit (Violet/Black wire on AB, AN and BR bodies) between IAC motor connector and PCM connector terminal No. 59. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-1. If resistance is more than 5 ohms, repair open Violet/Black wire. Perform TEST VER-1.

TEST NS-7E - INSPECTING IDLE AIR CONTROL MOTOR OPERATION

Note. For connector terminal identification, see CONNECTOR IDENTIFICATION in this article. For wiring diagram, see appropriate WIRING DIAGRAMS .

  1. Turn ignition off. Disconnect Powertrain Control Module (PCM) connector. Inspect connectors for damaged, pushed-out or miswired terminals. Repair as required. Perform «TEST VER-1»(ref-10877-S34287435522000111300000) . If PCM terminals are okay, go to next step.
  2. Using external ohmmeter, check resistance of driver No. 2 circuit (Yellow/Black wire on AB, AN and BR bodies) between IAC motor connector and PCM connector terminal No. 60. If resistance is more than 5 ohms, repair open Yellow/Black wire or Violet/Black wire. Perform TEST VER-1. If resistance is less than 5 ohms, replace PCM. Perform TEST VER-1.
