FLUID TYPES
When service is required, Chrysler recommends that only Mopar® brand parts, lubricants and chemicals be used. Mopar® provides the best engineered products for servicing Chrysler vehicles.
BRAKE FLUID
The brake fluid used in this vehicle must conform to DOT 3 specifications and SAE J1703 standards. No other type of brake fluid is recommended or approved for usage in the vehicle brake system. Use only Mopar® Brake Fluid or equivalent from a tightly sealed container.
| CAUTION | Never use reclaimed brake fluid or fluid from a container which has been left open. An open container of brake fluid will absorb moisture from the air and contaminate the fluid. |
| CAUTION | Never use any type of a petroleum-based fluid in the brake hydraulic system. Use of such type fluids will result in seal damage of the vehicle brake hydraulic system causing a failure of the vehicle brake system. Petroleum based fluids would be items such as engine oil, transmission fluid, power steering fluid, etc. |
BRAKE FLUID - EXPORT
The brake fluid used in this vehicle must conform to DOT 3 specifications and SAE J1703 standards. If DOT 3 brake fluid is not available, brake fluid conforming to DOT 4 specifications may be used in its place. The fluids are compatible, but DOT 4 usage may require additional fluid maintenance. No other type of brake fluid is recommended or approved for usage in the vehicle brake system. Use only Mopar® Brake Fluid or equivalent from a tightly sealed container.
| CAUTION | Never use reclaimed brake fluid or fluid from an container which has been left open. An open container of brake fluid will absorb moisture from the air and contaminate the fluid. |
| CAUTION | Never use any type of a petroleum-based fluid in the brake hydraulic system. Use of such type fluids will result in seal damage of the vehicle brake hydraulic system causing a failure of the vehicle brake system. Petroleum based fluids would be items such as engine oil, transmission fluid, power steering fluid, etc. |
FLUIDS, LUBRICANTS AND GENUINE PARTS
| Description | Type | Part Number | Capacities | |
|---|---|---|---|---|
| U.S. | Metric | |||
| Cooling System | ||||
| ? Engine Coolant (3.6L Engine) (1) | MOPAR® Antifreeze/Coolant 5 Year/100, 000 Mile Formula HOAT (Hybrid Organic Additive Technology) | 1 Gallon - 5066 386AA | 10 Quarts | 9.5 Liters |
| ? Engine Coolant (5.7L Engine) (1) | MOPAR® Antifreeze/Coolant 5 Year/100, 000 Mile Formula HOAT (Hybrid Organic Additive Technology) | 1 Gallon - 5066 386AA | 14.7 Quarts | 13.9 Liters |
| ? Engine Coolant (6.4L Engine) (1) | MOPAR® Antifreeze/Coolant 5 Year/100, 000 Mile Formula HOAT (Hybrid Organic Additive Technology) | 1 Gallon - 5066 386AA | 14.5 Quarts | 13.7 Liters |
| Engine Oil with Filter | ||||
| Engine Oil (3.6L Engines) | MOPAR® API Certified SAE 5W-30 engine oil, meeting the requirements of Chrysler Group LLC Material Standard MS-6395. | 1 Quart - 4761 838AB | 6 Quarts | 5.6 Liters |
| 1 Gallon- 4761 844AB | ||||
| Engine Oil (5.7L Engines) | MOPAR® API Certified SAE 5W-20 engine oil, meeting the requirements of Chrysler Group LLC Material Standard MS-6395. | 1 Quart - 4761 872MA | 7 Quarts | 6.6 Liters |
| 1 Gallon - 4761 851AF | ||||
| Engine Oil (6.4L Engine) | MOPAR® API Certified SAE Full Synthetic engine oil 0W-40, meeting the requirements of Chrysler Group LLC Material Standard MS-10725. | 1 Quart - 05037645AB | 7 Quarts | 6.6 Liters |
| Engine Oil Filter (3.6L Engines) | MOPAR® Engine Oil Filter | 68079 744AA | N/A | N/A |
| Engine Oil Filter (5.7L and 6.4L Engines) | MOPAR® Engine Oil Filter | 4884 899AB | N/A | N/A |
| Fuel (approximate) | ||||
| Fuel Selection (3.6L Engine) | 87 Octane Acceptable - 89 Octane Recommended | N/A | 19 Gallons | 72 Liters |
| Fuel Selection (5.7L Engine) | 87 Octane Acceptable - 89 Octane Recommended | N/A | 19 Gallons | 72 Liters |
| Fuel Selection (6.4L Engine) | 91 Octane Only or higher | N/A | 19 Gallons | 72 Liters |
| A/C Refrigerant System | ||||
| A/C Refrigerant System | R-134a | 82300101AB | 1.56 Pounds | 709 Grams |
| (1) ? System fill capacity includes heater and coolant recovery bottle filled to MAX level. | ||||
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. | ||||
| (1) | ? System fill capacity includes heater and coolant recovery bottle filled to MAX level. |
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
ENGINE
| Description | Type | Part Number | Gap | |
|---|---|---|---|---|
| U.S. | Metric | |||
| Spark Plugs (3.6L Engine) | Champion® | SP149125AD (RER8ZWYCB4) | 0.040 in | 1.00 mm |
| Spark Plugs (5.7L Engine) | NGK® Yttrium | 05149177AB (LZFR5C-11G) | 0.040 in | 1.00 mm |
| Spark Plugs (6.4L Engine) | NGK® Single Platinum | 05149212AC (LZTR6AP11EG) | 0.040 in | 1.00 mm |
SPARK PLUGS
| Description | Type | Part Number | Capacities | |
|---|---|---|---|---|
| U.S. | Metric | |||
| Automatic | ||||
| NAG 1 - Service Fill | MOPAR® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 5.3 Quarts | 5.0 Liters |
| 1 Gallon - 05013458AA | ||||
| ? NAG 1 - Overhaul Fill (1) | MOPAR® ATF+4 Automatic Transmission Fluid | 1 Quart - 05013457AA | 8.1 Quarts | 7.7 Liters |
| 1 Gallon - 05013458AA | ||||
| ? 8HP45 | MOPAR® ATF | 1 Quart - 68157995AA | 9.5 Quarts | 9.0 Liters |
| (1) ? Dry fill capacity. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. Refer to the appropriate service information for the correct procedures. For the 8HP45 see to the fluid checking standard procedure prior to checking or adding fluid to this transmission. Refer to FLUID AND FILTER, STANDARD PROCEDURE . | ||||
| CAUTION: A unique transmission fluid has been developed for the 8HP45 transmission. This fluid is NOT compatible with ATF+4 or any other current Chrysler transmission fluid. For specifics about this unique fluid see FLUIDS, LUBRICANTS AND GENUINE PARTS. Refer to CAPACITIES AND RECOMMENDED FLUIDS, SPECIFICATIONS . | ||||
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. | ||||
| (1) | ? Dry fill capacity. Depending on type and size of internal cooler, length and inside diameter of cooler lines, or use of an auxiliary cooler, these figures may vary. Refer to the appropriate service information for the correct procedures. |
| CAUTION |
|---|
| A unique transmission fluid has been developed for the 8HP45 transmission. This fluid is NOT compatible with ATF+4 or any other current Chrysler transmission fluid. For specifics about this unique fluid see FLUIDS, LUBRICANTS AND GENUINE PARTS. Refer to CAPACITIES AND RECOMMENDED FLUIDS, SPECIFICATIONS . |
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
TRANSMISSION
| Description | Type | Part Number | Capacities | |
|---|---|---|---|---|
| U.S. | Metric | |||
| BW 44-40 | MOPAR® Transfer Case Lubricant | 1 Quart - 68049954AA | 2.11 Pints | 1.0 Liters |
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. | ||||
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
TRANSFER CASE
| Description | Type | Part Number | Capacities | |
|---|---|---|---|---|
| U.S. | Metric | |||
| Axles (Front) | ||||
| 175mm FIA Front Axle | MOPAR® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05010320AA | 1.26 Pints | 0.6 Liters |
| Axles (Rear) | ||||
| 200mm RII Rear Axle | MOPAR® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469 | 1.2 Quarts | 1.1 Liters |
| 215mm RII Rear Axle | MOPAR® Synthetic Gear Lubricant SAE 75W-140 | 1 Quart - 04874469 | 1.3 Quarts | 1.2 Liters |
| ? 226mm RII Rear Axle (1) | MOPAR® Synthetic Gear Lubricant SAE 75W-90 | 1 Quart - 05010320AA | 1.4 Quarts | 1.3 Liters |
| Chassis Systems | ||||
| ?? Brake Master Cylinder (2) | MOPAR® Brake Fluid DOT 3, SAE J1703. | 12 oz. Bottle - 04318080AB | N/A | N/A |
| 32 oz. Bottle - 04318081AB | ||||
| ??? Power Steering Reservoir (Belt Driven Pump) (3) | MOPAR® Power Steering Fluid +4 | 1 Quart - 05013457AA | N/A | N/A |
| ???? Electro Hydraulic Power Steering (EHPS) (4) | Hydraulic Power Steering Fluid meeting MS-11655 | 1 Quart - 68088485AA or 05127381AB | N/A | N/A |
| (1) ? Limited-Slip Rear Axles require the addition of 118 ml (4 oz.) MOPAR® Limited Slip Additive. | ||||
| (2) ?? If MOPAR® Brake Fluid DOT 3 is not available, then MOPAR® Brake and Clutch Fluid DOT 4 (P/N 04549625AC), is acceptable. | ||||
| (3) ??? If MOPAR® Power Steering Fluid +4 is not available, then MOPAR® ATF +4 Automatic Transmission Fluid (P/N 05166226AA), is acceptable. | ||||
| (4) ???? CAUTION: There is an Electro Hydraulic Power Steering (EHPS) pump on Non-SRT vehicles which requires a different power steering fluid. Do not mix power steering fluid types. Damage may result to the power steering pump and system if any other fluid is used. The EHPS system uses fluid which meets material specification MS-11655 or equivalent. The mechanical power steering pump systems on SRT vehicles require the use of Power Steering Fluid +4, which meets material specification MS-9602 or equivalent. Do not overfill. | ||||
| CAUTION: Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. | ||||
| (1) | ? Limited-Slip Rear Axles require the addition of 118 ml (4 oz.) MOPAR® Limited Slip Additive. |
| (2) | ?? If MOPAR® Brake Fluid DOT 3 is not available, then MOPAR® Brake and Clutch Fluid DOT 4 (P/N 04549625AC), is acceptable. |
| (3) | ??? If MOPAR® Power Steering Fluid +4 is not available, then MOPAR® ATF +4 Automatic Transmission Fluid (P/N 05166226AA), is acceptable. |
| (4) | ???? |
| CAUTION |
|---|
| There is an Electro Hydraulic Power Steering (EHPS) pump on Non-SRT vehicles which requires a different power steering fluid. Do not mix power steering fluid types. Damage may result to the power steering pump and system if any other fluid is used. The EHPS system uses fluid which meets material specification MS-11655 or equivalent. The mechanical power steering pump systems on SRT vehicles require the use of Power Steering Fluid +4, which meets material specification MS-9602 or equivalent. Do not overfill. |
| CAUTION |
|---|
| Nominal refill capacities are shown. A variation may be observed from vehicle to vehicle due to manufacturing tolerance and refill procedure. |
CHASSIS
Scheme 1
The Integrated Power Module (IPM) is located in the engine compartment. This module contains fuses and relays.
| CAUTION | When installing the Power Distribution Center cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Power Distribution Center, and possibly result in an electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
| CAVITY | CARTRIDGE FUSE | MINI-FUSE | DESCRIPTION |
|---|---|---|---|
| 1 | Fuse - Spare | ||
| 2 | 40 Amp Green | Radiator Fan #1 | |
| 3 | 50 Amp Red | Power Steering #1 | |
| 4 | 30 Amp Pink | Starter | |
| 5 | 40 Amp Green | Anti-Lock Brakes | |
| 6 | Fuse - Spare | ||
| 7 | Fuse - Spare | ||
| 8 | Fuse - Spare | ||
| 9 | 20 Amp Yellow | All-Wheel Drive Module - If Equipped | |
| 10 | 10 Amp Red | Security | |
| 11 | 20 Amp Yellow | Horns | |
| 12 | 10 Amp Red | Air Conditioning Clutch | |
| 13 | Fuse - Spare | ||
| 14 | 25 Amp Natural | Anti-Lock Brakes | |
| 15 | 25 Amp Natural | Transmission | |
| 16 | Fuse - Spare | ||
| 18 | 50 Amp Red | Radiator Fan #2 | |
| 19 | 50 Amp Red | Power Steering #2 | |
| 20 | 30 Amp Pink | Wiper Motor | |
| 21 | 30 Amp Pink | Headlamp Washers | |
| 22 | Fuse - Spare | ||
| 23 | Fuse - Spare | ||
| 24 | Fuse - Spare | ||
| 28 | 25 Amp Natural | Fuel Pump | |
| 29 | 15 Amp Blue | Transmission/Shifter | |
| 30 | Fuse - Spare | ||
| 31 | 25 Amp Natural | Engine Module | |
| 32 | Fuse - Spare | ||
| 33 | Fuse - Spare | ||
| 34 | 25 Amp Natural | Powertrain #1 | |
| 35 | 25 Amp Natural | Powertrain #2 | |
| 36 | 10 Amp Red | Anti-Lock Brake Module | |
| 37 | 10 Amp Red | Engine Controller/Rad Fan Relays | |
| 38 | 10 Amp Red | Airbag Module | |
| 39 | 10 Amp Red | Power Steering Module/AC Clutch Relay | |
| 48 | 10 Amp Red | AWD Module/Front Axle Disconnect | |
| 49 | Fuse - Spare | ||
| 50 | Fuse - Spare | ||
| 51 | 20 Amp Yellow | Vacuum Pump | |
| 52 | Fuse - Spare | ||
| 53 | Fuse - Spare | ||
| RELAYS | |||
| CAVITY | DESCRIPTION | ||
| 25 | Vacuum Pump | ||
| 26 | Spare | ||
| 27 | Starter | ||
| 40 | Spare/Front Axle Disconnect | ||
| 41 | Horns | ||
| 42 | Front Wiper #1 | ||
| 43 | A/C Clutch | ||
| 44 | Transmission | ||
| 45 | Front Wiper #2 | ||
| 46 | Spare | ||
| 47 | Radiator Fan #1 | ||
| 54 | Fuel Pump | ||
| 55 | Spare | ||
| 56 | Spare | ||
| 57 | Radiator Fan #2 | ||
| 58 | Radiator Fan #3 | ||
| 59 | Ignition Run/Start | ||
| 60 | Headlamp Washers | ||
| 61 | Spare | ||
| 62 | Spare | ||
| 63 | Automatic Shut Down (ASD) Relay #1 | ||
| 64 | Spare | ||
| 65 | Spare | ||
Scheme 2
There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays.
| CAUTION | When installing the Power Distribution Center cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Power Distribution Center, and possibly result in an electrical system failure. When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
| Cavity | Cartridge Fuse | Mini-Fuse | Description |
|---|---|---|---|
| 2 | 60 Amp Yellow | Front PDC Feed #1 | |
| 3 | Fuse - Spare | ||
| 4 | 60 Amp Yellow | Front PDC Feed #2 | |
| 5 | 30 Amp Pink | Sunroof | |
| 6 | 40 Amp Green | Exterior Lighting #1 | |
| 7 | 40 Amp Green | Exterior Lighting #2 | |
| 8 | 30 Amp Pink | Interior Lighting/Washer Pump | |
| 9 | 30 Amp Pink | Power Locks | |
| 10 | 30 Amp Pink | Driver Door | |
| 11 | 30 Amp Pink | Passenger Door | |
| 12 | 20 Amp Yellow | Cigar Lighters, Instrument Panel & Power Outlet Console Rear | |
| 15 | 40 Amp Green | HVAC Blower | |
| 16 | Fuse - Spare | ||
| 17 | Fuse - Spare | ||
| 18 | Fuse - Spare | ||
| 19 | Fuse - Spare | ||
| 20 | Fuse - Spare | ||
| 21 | Fuse - Spare | ||
| 22 | Fuse - Spare | ||
| 23 | 10 Amp Red | Fuel Door/Diagnostic Port | |
| 24 | 15 Amp Blue | Radio Screen | |
| 25 | 10 Amp Red | Tire Pressure Monitor | |
| 26 | Fuse - Spare | ||
| 27 | 25 Amp Natural | Amplifier | |
| 31 | 25 Amp Natural | Power Seats | |
| 32 | 15 Amp Blue | HVAC Module/Cluster | |
| 33 | 15 Amp Blue | Ignition Switch/Wireless Module | |
| 34 | 10 Amp Red | Steering Column Module/Clock | |
| 35 | 10 Amp Red | Battery Sensor | |
| 36 | Fuse - Spare | ||
| 37 | 15 Amp Blue | Radio | |
| 38 | 20 Amp Yellow | Power Outlet Inside Arm Rest | |
| 40 | Fuse - Spare | ||
| 41 | Fuse - Spare | ||
| 42 | 30 Amp Pink | Rear Defrost | |
| 43 | 25 Amp Natural | Rear Heated Seats/Steering Wheel | |
| 44 | 10 Amp Red | Park Assist/Blind Spot/Camera | |
| 45 | 15 Amp Blue | Cluster/Rearview Mirror/Compass | |
| 46 | 10 Amp Red | Adaptive Cruise Control | |
| 47 | 10 Amp Red | Adaptive Front Lighting | |
| 48 | 20 Amp Yellow | Active Suspension | |
| 49 | Fuse - Spare | ||
| 50 | Fuse - Spare | ||
| 51 | 20 Amp Yellow | Front Heated Seats | |
| 52 | 10 Amp Red | Heated Cupholders/Rear Heated Seat Switches | |
| 53 | 10 Amp Red | HVAC Module/In Car Temperature Sensor | |
| 54 | Fuse - Spare | ||
| 55 | Fuse - Spare | ||
| 56 | Fuse - Spare | ||
| 57 | Fuse - Spare | ||
| 58 | 10 Amp Red | Airbag Module | |
| 59 | Fuse - Spare | ||
| 60 | Fuse - Spare | ||
| 61 | Fuse - Spare | ||
| 62 | Fuse - Spare | ||
| 63 | Fuse - Spare | ||
| 64 | 25 Amp Natural | Rear Windows | |
| 65 | 10 Amp Red | Airbag Module | |
| 66 | Fuse - Spare | ||
| 67 | 15 Amp Blue | Run Sense | |
| 68 | 15 Amp Blue | Illumination/Rear Sunshade | |
| 69 | Fuse - Spare | ||
| 70 | Fuse - Spare | ||
| RELAYS | |||
| CAVITY | DESCRIPTION | ||
| 1 | Ignition Run | ||
| 13 | Spare | ||
| 14 | Spare | ||
| 28 | Rear Defrost | ||
| 29 | Rear Windows/Run Sense/Rear Sunshade | ||
| 30 | Cigar Lighters | ||
| 39 | Spare | ||
| 71 | Hvac Blower | ||
| 72 | Spare | ||
Scheme 3
| 1 - DRIVE ON HOIST |
|---|
| 2 - FLOOR JACK, VEHICLE EMERGENCY JACK |
| 3 - FRAME CONTACT LIFT (SINGLE POST) |
| 3 - CHASSIS LIFT (DUAL LIFT) |
| 3 - OUTBOARD LIFT (DUAL LIFT) |
| 3 - FLOOR JACK |
Refer to Owner's Manual provided with vehicle for proper emergency jacking procedures.
| WARNING | The hoisting and jack lifting points provided are for a complete vehicle. When the engine or rear suspension is removed from a vehicle, the center of gravity is altered making some hoisting conditions unstable. Properly support or secure vehicle to hoisting device when these conditions exist. Failure to follow these instructions may result in serious or fatal injury. |
| CAUTION | Do not position hoisting device on any suspension component, including the front or rear suspension crossmembers. Do not hoist on the front and rear bumpers, the lower radiator crossmember, or the front engine mount. Do not attempt to raise one entire side of the vehicle by placing a floor jack midway between the front and rear wheels. This practice may result in permanent damage to the body. |
When properly positioned, a floor jack can be used to lift the vehicle and support the raised vehicle with jack stands.
A floor jack or any lifting device must never be used on any part of the underbody other than the described areas.
OIL CHANGE INDICATOR- RESET
The vehicle is equipped with an engine oil change indicator system. The "Oil Change Required" message flashes in the EVIC display for approximately ten seconds after a single chime has sounded, to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate depending upon your personal driving style.
Unless reset, this message continues to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the Menu button. To reset the oil change indicator system (after performing the scheduled maintenance) perform the following procedure
- Turn the ignition switch to the "ON" position. Do not start the engine.
- Fully press the accelerator pedal slowly three times within ten seconds.
- Turn the ignition switch to the "LOCK" position.
Note. If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary, repeat this procedure.
REQUIRED MAINTENANCE INTERVALS
Refer to the Maintenance Schedules on the following pages for the required maintenance intervals.
| Perform Maintenance Every | Maintenance Items | ||
|---|---|---|---|
| (Where time and mileage are listed, follow the interval that occurs first.) | |||
| Miles | Kilometers | Months | |
| 8000 | 13000 | 6 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 8, 000 miles (13 000 km). |
| 16000 | 26000 | 12 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 16, 000 miles (26 000 km). If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Replace the air conditioning filter. Inspect the brake linings, replace if necessary. Inspect exhaust system. Perform the first inspection at 16, 000 miles (26 000 km) or 12 months. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 24000 | 39000 | 18 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 24, 000 miles (39 000 km). Inspect the CV joints. Inspect exhaust system. Inspect the rear axle fluid. Inspect the front axle fluid - All Wheel Drive (AWD). |
| 32000 | 52000 | 24 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 32, 000 miles (52 000 km). Replace the engine air cleaner filter. Replace the air conditioning filter. Replace the spark plugs (5.7L Engine). Adjust parking brake on vehicles equipped with four-wheel disc brakes. Inspect the brake linings, replace if necessary. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Inspect the transfer case fluid - All Wheel Drive (AWD). |
| 40000 | 65000 | 30 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 40, 000 miles (65 000 km). |
| 48000 | 78000 | 36 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 48, 000 miles (78 000 km). If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Replace the air conditioning filter. Inspect the brake linings, replace if necessary. Inspect the CV joints. Inspect exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Change the rear axle fluid and on models equipped with All Wheel Drive (AWD) change the front axle fluid if using your vehicle for any of the following: police, taxi, fleet, off-road, or frequent trailer towing. |
| 56000 | 91000 | 42 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 56, 000 miles (91 000 km). |
| 64000 | 104000 | 48 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 64, 000 miles (104 000 km). Replace the engine air cleaner filter. Replace the air conditioning filter. Inspect the brake linings; replace if necessary. Replace the spark plugs (5.7L Engine). Adjust parking brake on vehicles equipped with four-wheel disc brakes. Change the automatic transmission fluid and filter if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing (five-speed transmission only). Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Change the transfer case fluid if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing - All Wheel Drive (AWD). |
| 72000 | 117000 | 54 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 72, 000 miles (117 000 km). Inspect the CV joints. Inspect exhaust system. Inspect the rear axle fluid. Inspect the front axle fluid - All Wheel Drive (AWD). |
| 80000 | 130000 | 60 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 80, 000 miles (130 000 km). If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Replace the air conditioning filter. Flush and replace the engine coolant if not done at 104, 000 miles (169 000 km). Inspect the brake linings, replace if necessary. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 88000 | 143000 | 66 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 88, 000 miles (143 000 km). |
| 96000 | 156000 | 72 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 96, 000 miles (156 000 km). Replace the engine air cleaner filter. Replace the air conditioning filter. Replace the spark plugs (3.6L Engine). Replace the spark plugs (5.7L Engine). Inspect and replace PCV valve if necessary. Adjust parking brake on vehicles equipped with four-wheel disc brakes. Inspect the brake linings, replace if necessary. Inspect the CV joints. Inspect exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Change the rear axle fluid and on models equipped with All Wheel Drive (AWD) change the front axle fluid if using your vehicle for any of the following: police, taxi, fleet, off-road, or frequent trailer towing. Inspect the transfer case fluid - All Wheel Drive (AWD). |
| 104000 | 169000 | 78 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 104, 000 miles (169 000 km). Replace the spark plugs (5.7L Engine - Police Car Only). Flush and replace engine coolant at 104, 000 miles (169, 00 km) or 60 months (whichever occurs first). |
| 112000 | 182000 | 84 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 112, 000 miles (182 000 km). If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Replace the air conditioning filter. Inspect the brake linings, replace if necessary. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 120000 | 195000 | 90 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 120, 000 miles (195 000 km). Inspect the CV joints. Inspect exhaust system. Change the automatic transmission fluid and filter (five-speed transmission only). Replace the accessory drive belt(s). Inspect the rear axle fluid. Inspect the front axle fluid - All Wheel Drive (AWD). |
| 128000 | 208000 | 96 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 128, 000 miles (208 000 km). Replace the engine air cleaner filter. Replace the air conditioning filter. Replace the spark plugs (5.7L Engine). Adjust parking brake on vehicles equipped with four-wheel disc brakes. Inspect the brake linings, replace if necessary. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Change the transfer case fluid if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing - All Wheel Drive (AWD). |
| 136000 | 221000 | 102 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 136, 000 miles (221 000 km). |
| 144000 | 234000 | 108 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 144, 000 miles (234 000 km). If using your vehicle for any of the following: Dusty or off-road conditions. Inspect the engine air cleaner filter; replace if necessary. Replace the air conditioning filter. Inspect the brake linings, replace if necessary. Inspect the CV joints. Inspect exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Change the rear axle fluid and on models equipped with All Wheel Drive (AWD) change the front axle fluid if using your vehicle for any of the following: police, taxi, fleet, off-road, or frequent trailer towing. |
| 152000 | 247000 | 114 | Change the engine oil and engine oil filter. Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 152, 000 miles (247 000 km). |
| WARNING | You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic. Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and performance. This could cause an accident Failure to follow these instructions may result in possible serious or fatal injury. |
The vehicle is equipped with an engine oil change indicator system. The "Oil Change Required" message flashes in the EVIC display for approximately ten seconds after a single chime has sounded, to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate depending upon your personal driving style.
Unless reset, this message continues to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the Menu button. To reset the oil change indicator system (after performing the scheduled maintenance) perform the following procedure
- Turn the ignition switch to the "ON" position. Do not start the engine.
- Fully press the accelerator pedal slowly three times within ten seconds.
- Turn the ignition switch to the "LOCK" position.
Note. If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary, repeat this procedure.
| Perform Maintenance Every | Maintenance Items | ||
|---|---|---|---|
| (Where time and mileage are listed, follow the interval that occurs first.) | |||
| Miles | Kilometers | Months | |
| 6000 | 10000 | 6 | Change the engine oil and engine oil filter. Rotate tires. |
| 12000 | 20000 | 12 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the CV joints. Perform the first inspection at 12, 000 miles (20 000 km) or 12 months. Inspect the exhaust system. Perform the first inspection at 12, 000 miles (20 000 km) or 12 months. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 18000 | 30000 | 18 | Change the engine oil and engine oil filter. Rotate tires. Inspect the rear axle fluid. |
| 24000 | 40000 | 24 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the CV joints. Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 30000 | 50000 | 30 | Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Adjust parking brake on vehicles equipped with four-wheel disc brakes. |
| 36000 | 60000 | 36 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the CV joints. Inspect the exhaust system. Inspect the rear axle fluid. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 42000 | 70000 | 42 | Change the engine oil and engine oil filter. Rotate tires. |
| 48000 | 80000 | 48 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the CV joints. Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Change the rear axle fluid if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing. |
| 54000 | 90000 | 54 | Change the engine oil and engine oil filter. Rotate tires. Inspect the rear axle fluid. |
| 60000 | 100000 | 60 | Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Adjust parking brake on vehicles equipped with four-wheel disc brakes. Inspect the CV joints. Inspect the exhaust system. Change the automatic transmission fluid and filter if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing. Flush and replace the engine coolant at 60 months if not done at 102, 000 miles (170 000 km). Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 66000 | 110000 | 66 | Change the engine oil and engine oil filter. Rotate tires. |
| 72000 | 120000 | 72 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the rear axle fluid. Inspect the CV joints. Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 78000 | 130000 | 78 | Change the engine oil and engine oil filter. Rotate tires. |
| 84000 | 140000 | 84 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the CV joints. Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 90000 | 150000 | 90 | Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Inspect and replace the PCV Valve if necessary. Inspect the rear axle fluid. Adjust parking brake on vehicles equipped with four-wheel disc brakes. |
| 96000 | 160000 | 96 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the spark plugs. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the CV joints. Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Change the rear axle fluid if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing. |
| 102000 | 170000 | 102 | Change the engine oil and engine oil filter. Rotate tires. Flush and replace the engine coolant if not done at 60 months. |
| 108000 | 180000 | 108 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the CV joints. Inspect the exhaust system. Inspect the rear axle fluid. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 114000 | 190000 | 114 | Change the engine oil and engine oil filter. Rotate tires. |
| 120000 | 200000 | 120 | Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Adjust parking brake on vehicles equipped with four-wheel disc brakes. Inspect the CV joints. Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Change the automatic transmission fluid and filter. |
| 126000 | 210000 | 126 | Change the engine oil and engine oil filter. Rotate tires. Inspect the rear axle fluid. |
| 132000 | 220000 | 132 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the CV joints. Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. |
| 138000 | 230000 | 138 | Change the engine oil and engine oil filter. Rotate tires. |
| 144000 | 240000 | 144 | Change the engine oil and engine oil filter. Rotate tires. If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. Replace the air conditioning filter. Inspect the brake linings, and replace if necessary. Inspect the CV joints. Inspect the exhaust system. Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Change the rear axle fluid if using your vehicle for any of the following: police, taxi, fleet, or frequent trailer towing. |
| 150000 | 250000 | 150 | Change the engine oil and engine oil filter. Rotate tires. Replace the engine air cleaner filter. Adjust parking brake on vehicles equipped with four-wheel disc brakes. |
| WARNING | You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic. Failure to properly inspect and maintain your vehicle could result in a component malfunction and effect vehicle handling and performance. This could cause an accident Failure to follow these instructions may result in possible serious or fatal injury. |
