SPECIAL TOOLS
9320 - Remover/Installer, Ball Joint (Originally Shipped In Kit Number(s) 9329, 9515, 9516, 9516-CAN, 9517, 9517-CAN, 9518, 9519, 9540, 9541.) 9320-1 - Plate, Ball Joint Remover (Originally Shipped In Kit Number(s) 9329, 9515, 9516, 9516-CAN, 9517, 9517-CAN, 9518, 9519, 9540, 9541.) 9320-3 - Remover, Ball Joint (Originally Shipped In Kit Number(s) 9329, 9515, 9516, 9516-CAN, 9517, 9517-CAN, 9518, 9519, 9540, 9541.) 9320-4 - Installer Cup (Originally Shipped In Kit Number(s) 9329, 9515, 9516, 9516-CAN, 9517, 9517-CAN, 9518, 9519, 9540, 9541.) 9320-5 - Receiver Cup (Originally Shipped In Kit Number(s) 9329, 9515, 9516, 9516-CAN, 9517, 9517-CAN, 9518, 9519, 9540, 9541.) 9360 - Remover, Ball Joint (Originally Shipped In Kit Number(s) 9329, 9515, 9516, 9516-CAN, 9517, 9517-CAN, 9518, 9519, 9540, 9541.) 9362 - Wrench, Strut Nut (Originally Shipped In Kit Number(s) 9329, 9515, 9516, 9516-CAN, 9517, 9517-CAN, 9518, 9519, 9540, 9541.) C-4212F - Press, Ball Joint (Originally Shipped In Kit Number(s) 6745, 6880, 6881, MLR-C03.)
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Each side of the front suspension includes the following components
- Hub And Bearing
- Knuckle (3)
- Lower Control Arm (5)
- Shock Assembly (1)
- Stabilizer Bar and Link (7)
- Tension Strut (4)
- Upper Control Arm (2)
Scheme 56
The SRT front suspension is part of an Active Damping System (ADS). The ADS includes unique shock absorbers, an Active Damping Control Module (ADCM), and three accelerometers that work together to modify the ride of the suspension over varying road conditions.
The Active Damping System (ADS) front shock assembly (2) is similar to a conventional coil over shock with the addition of a shock solenoid assembly (1) mounted on the side of its body with a three wire harness connector attached to it. The ADS shock assembly is serviced the same as a conventional shock absorber, with the addition of disconnecting the ADS harness connector from behind the splash shield.
Scheme 57
The SRT front suspension is similar to the standard front suspension but some components have been modified for unique ride, handling, and steering performance. Service of all front suspension components remain the same as the standard components. When components differ, be sure to use only SRT components on SRT vehicles.
The front knuckle (8) for the SRT is different from the standard knuckle. Although similar in appearance, the knuckle has been modified to accept the larger tire and wheel assembly. Also, the mounting bosses for the disc brake caliper have been moved downward to allow for mounting of the Brembo four-piston disc brake caliper (2).
The front stabilizer bar diameter has been increased for the SRT. It is serviced in the same manner as the standard bar.
