INSTALLATION

Note. Make sure the remote start antenna is positioned the same way noted during the removal procedure.

1. Install the remote start antenna module (2), and screws (1) to instrument panel assembly. Tighten screws to 2.5 N.m (22 in. lbs.).
2. Install the glove box. Refer to «GLOVE BOX, INSTRUMENT PANEL, INSTALLATION»(ref-489285-S33385615132012072600000) .
3. Route the remote start coaxial cable (1) in the position noted during the removal procedure.
4. Install the remote start antenna coaxial cable to mounting clips, if equipped.
5. Connect remote start antenna coaxial cable connector (1) to wireless ignition node (WIN) (2).
6. Install WIN to instrument panel bracket. Refer to «RECEIVER, WIRELESS IGNITION NODE, INSTALLATION»(ref-489300-S42425742692012072600000) .

Scheme 15

The START/STOP button is located on the instrument panel, inserted into the Wireless Ignition Node (WIN) next to the steering column. The START/STOP button is the momentary push button used to change the vehicle's ignition states, instead of the conventional key and lock cylinder. The START/STOP button can be removed and the FOB with Integrated Key (FOBIK) can be used in its place, in a similar manner to a conventional key.

REMOVAL

Note. The START/STOP button should only be removed or installed with the ignition off.

Scheme 16

1. Insert a small screwdriver or trim tool under the chrome bezel ring (3) at the bottom of the button(2), and gently pry the button (2) loose.
2. Remove the button (2) from the receptacle on the instrument panel (1).

Note. The START/STOP button should only be removed or installed with the ignition off.

1. Position the START/STOP button (2) with the lettering in the horizontal position.
2. Insert the button into the receptacle on the instrument panel (1) and gently press on the chrome bezel ring (3) to seat the button in the receptacle.
