Wiring diagram: Air conditioning — Manual a/c circuit Dodge Caravan IV

Components on these wiring diagrams 61

Click a component to highlight it on every diagram it appears on.

• 2.4L, Late Build: 3.3L, 3.8L
• 5 Volts
• A/C Compr- Essor Clutch Relay
• A/C Heater Control
• A/C On A/C On Indicator
• A/C On Rear Wiper/ Washer Ind
• A/C Pressure Sensor
• A/C Switch
• Blower Motor Resistor
• Body Control Module Panel Lamps Driver
• Def- Rost Panel
• Defog On Rear Defog Ind
• Driver Blend
• Driver Blend Door Actuator
• Ect Signal
• Engine Coolant Temperature Sensor
• Evaporator Temperature Sensor Panel Lamps Driver
• F Blower
• Front Blower Motor
• Front Blower Motor Relay
• Front Control Module Front/ Rear Blower Relay
• Fuse 10
• Fuse 12
• Fuse 18
• Fuse 27
• Ground Hvac Control
• High Med Low On 4 6 7 8
• Ignition Output Pci Bus
• Integrated Power Module
• Left Temp Sensor
• Mode Door Actuator
• Mode Select
• Off 3 2 1 Low Med High
• On/Off Sense
• Optional
• Panel Lamps Driver
• Pass Blend Common
• Passen- Ger
• Passenger Blend Door Actuator
• Powertrain Control Module
• Radiator Fan 1
• Radiator Fan 2
• Radiator Fan Relay
• Radiator Rly A/C Clutch Rly Sensor Ground A/C Press Sens
• Rear A/C-Heater Unit
• Rear Blower Front Control Switch
• Rear Blower Motor Relay
• Rear Blower Rear Control Switch
• Rear Mode Common Rear Blend Rear Temp Rtn Rear Temp Sig
• Rear Window Defogger Switch
• Rear Wiper Washer Switch
• Recirc Door
• Recirculate
• Recirculate Mode Ind
• Recirculate Mode Switch
• Recirculation Door Actuator
• Right Temp Sensor
• S118
• Sensor
• Switch Sense
• Thermal Fuse
