SPECIFICATIONS - TORQUE

DESCRIPTION	N.m	Ft. Lbs.	In. Lbs.
Balance Shaft Carrier to Block-Bolts	54	40
Balance Shaft Gear Cover-Double Ended Fastener	12		105
Balance Shaft Sprocket-Bolt	28		250
Balance Shaft Chain Tensioner-Bolts	12		105
Balance Shaft Carrier Cover-Bolts	12		105
Camshaft Sprocket-Bolt	101	75
Connecting Rod Cap-Bolts	27 +1/4 turn	20 +1/4 turn
Crankshaft Main Bearing Cap/Bedplate
M8 Bolts	28		250
M11 Bolts	41 +1/4 Turn	30 +1/4 Turn
Crankshaft Damper	136	100
Cylinder Head-Bolts	(Refer to ENGINE/CYLINDER HEAD - INSTALLATION)
Cylinder Head Cover-Bolts	12		105
Flex Plate to Crankshaft	95	70
Engine Mount Bracket Right-Bolts	61	45
Engine Mounting-Bolts	(Refer to ENGINE MOUNTING )
Exhaust Manifold to Cylinder Head-Bolts	19		170
Exhaust Manifold Heat Shield-Bolts	12		105
Intake Manifold - Lower -Bolts	28		250
Intake Manifold - Upper-Bolts	28		250
Oil Filter	12		105
Oil Pan-Bolts	12		105
Oil Pan Drain-Plug	28	20
Oil Pressure Switch	21		190
Oil Pump to Block-Bolts	28	20
Oil Pump Cover Plate-Bolts	12		105
Oil Pump Pick-up Tube-Bolt	28	20
Oil Pump Relief Valve-Cap	41	30
Spark Plugs	18	13
Structural Collar	(Refer to ENGINE/ENGINE BLOCK/STRUCTURAL COVER - INSTALLATION)
Timing Belt Covers
Front Covers to Rear Cover-Bolts	6		50
Rear Cover-M6 Bolts	12		105
M8 Bolts	28		250
Timing Belt Idler Pulley	61	45
Timing Belt Tensioner Lock Bolt	25		220
Timing Belt Tensioner Assembly-Bolts	61	45
