Ignition Control System: Other Dodge Caravan IV

Ignition System 2 illustrations

SPARK PLUG CABLE RESISTANCE

CABLEMaximum Resistance
1, 2, 3, & 410.8K ohms

2.4L

CABLEMaximum Resistance
#122.5K ohms
#222.8K ohms
#319.3K ohms
#419.3K ohms
#513.6K ohms
#616.4K ohms

3.3/3.8L

SPARK PLUG

EngineSpark PlugGapThread Size
2.4LRE14MCC50.048 TO 0.05314 mm (1 in.) reach
EngineSpark PlugGapThread Size
3.3LRE14PLP50.048 TO 0.05314 mm (1 in.) reach
3.8LRE14PLP50.048 TO 0.05314 mm (1 in. ) reach

Scheme 15

Scheme 15: FIRING ORDER
Scheme 15: FIRING ORDER

Scheme 16

Scheme 16
Scheme 16
1 - Electrical Connector
