Power door locks — Door lock circuit Dodge Cab & Chassis R2500
All systems — 50 systems
- Air conditioning 4
- Anti-lock brakes 4
- Anti-lock brakes 5.7l
- Anti-theft
- Body computer 4
- Body control modules
- Computer data lines 2
- Computer data lines 5.9l
- Computer data lines 5.9l diesel
- Computer data lines 8.0l
- Cruise control
- Cruise control 5.7l
- Cruise control 5.9l 24-valve diesel
- Cruise control 8.0l
- Defoggers 3
- Engine performance 5.2l 2
- Engine performance 5.7l
- Engine performance 5.9l 7
- Engine performance 5.9l diesel
- Engine performance 8.0l 2
- Exterior lights 3
- Ground distribution
- Headlights 7
- Horn
- Instrument cluster 3
- Interior lights 3
- Passive restraints 2
- Power distribution
- Power door locks 6
- Power mirrors 3
- Power seats 9
- Power top/sunroof
- Power windows 2
- Radio 10
- Shift interlock
- Starting/charging 2
- Starting/charging 5.2l 2
- Starting/charging 5.7l 2
- Starting/charging 5.9l 6
- Starting/charging 5.9l diesel 2
- Starting/charging 8.0l 2
- Supplemental restraints 2
- Transmission 4
- Transmission 5.2l 2
- Transmission 5.7l
- Transmission 5.9l 7
- Transmission 5.9l diesel
- Transmission 8.0l 2
- Warning systems 2
- Wiper/washer
Components on these wiring diagrams 2
Click a component to highlight it on every diagram it appears on.
