ENGINE COMPRESSION
Information is not available from manufacturer.
VALVE CLEARANCE
Valve clearance must be adjusted with engine temperature less than 140°F (60°C). For valve clearance adjusting procedure, see ADJUSTMENTS DIESEL article in the ENGINE PERFORMANCE section.
| Procedure | Cylinder Numbers | |
|---|---|---|
| Step 1 (2) | ||
| Exhaust Valves | 1, 3 & 5 | |
| Intake Valves | 1, 2 & 4 | |
| Step 2 (3) | ||
| Exhaust Valves | 2, 4 & 6 | |
| Intake Valves | 3, 5 & 6 | |
| (1) Adjust valves with engine temperature less than 140°F (60°C). (2) Adjust with timing pin engaged and No. 1 cylinder at TDC. (3) Engine rotated 360 degrees from TDC of No. 1 cylinder and reference marks aligned. | ||
| (1) | Adjust valves with engine temperature less than 140°F (60°C). |
| (2) | Adjust with timing pin engaged and No. 1 cylinder at TDC. |
| (3) | Engine rotated 360 degrees from TDC of No. 1 cylinder and reference marks aligned. |
VALVE ADJUSTING SEQUENCE (1)
| Application | In. (mm) |
|---|---|
| Exhaust Valves | .020 (.51) |
| Intake Valves | .010 (.25) |
| (1) Adjust valves with engine temperature less than 140°F (60°C). | |
| (1) | Adjust valves with engine temperature less than 140°F (60°C). |
VALVE CLEARANCE SPECIFICATIONS (1)
Firing Order. Scheme 7
FUEL INJECTOR
Fuel injector must have correct opening pressure. See FUEL INJECTOR OPENING PRESSURE table.
| Application | Psi (kg/cm 2 ) |
|---|---|
| Intercooled Models (1) | 3625 (255) |
| Non-Intercooled Models | 3550 (249) |
| (1) In mid-year, an intercooler was installed in front of radiator. | |
| (1) | In mid-year, an intercooler was installed in front of radiator. |
FUEL INJECTOR OPENING PRESSURE
FUEL INJECTION PUMP TIMING
See D - DIESEL ADJUSTMENTS article in the ENGINE PERFORMANCE section.
FUEL LIFT PUMP
For fuel lift pump testing procedure, see I - DIESEL SYS/COMP TESTS article in the ENGINE PERFORMANCE section.
| Application | Output |
|---|---|
| Pump Pressure | 3 psi Minimum (.2 kg/cm 2 ) |
| Volume Within 30 Seconds | .7 qts. (.6L) |
FUEL LIFT PUMP SPECIFICATIONS
LOW IDLE SPEED
For low idle speed adjusting procedure, see D - DIESEL ADJUSTMENTS article in the ENGINE PERFORMANCE section.
| Application | RPM |
|---|---|
| A/T | 700 |
| M/T | 750 |
| (1) Check low idle speed with A/C on. | |
| (1) | Check low idle speed with A/C on. |
LOW IDLE SPEED SPECIFICATIONS (1)
FULL THROTTLE SPEED
Check full throttle speed with A/C on. If engine will not meet full throttle speed and low-pressure fuel system and fuel injectors are operating correctly, fuel injection pump must be removed for service. See FULL THROTTLE SPEED SPECIFICATIONS table.
| Application | RPM |
|---|---|
| All Models | 2825-2925 |
| (1) Check with A/C on. | |
| (1) | Check with A/C on. |
FULL THROTTLE SPEED SPECIFICATIONS (1)
THROTTLE POSITION SENSOR (TPS)
Note. Throttle position sensor is only used on intercooled models with automatic transmissions.
For throttle position sensor adjusting procedure, see D - DIESEL ADJUSTMENTS article in the ENGINE PERFORMANCE section.
TURBOCHARGER
For turbocharger testing procedures, see I - DIESEL SYS/COMP TESTS article in the ENGINE PERFORMANCE section.
| Application | In. (mm) | |
|---|---|---|
| Shaft Clearances | ||
| End Play | (1) | |
| Radial Clearance | .012-.018 (.30-.46) | |
| Turbine Shaft Minimum O.D. | .432 (10.97) | |
| (1) On turbochargers with serial No. 840637 and earlier, end play should be .004-.006" (.10-.15 mm). On turbochargers with serial No. 840638 and later, end play should be .001-.003" (.03-.08 mm). | ||
| (1) | On turbochargers with serial No. 840637 and earlier, end play should be .004-.006" (.10-.15 mm). On turbochargers with serial No. 840638 and later, end play should be .001-.003" (.03-.08 mm). |
TURBOCHARGER SPECIFICATIONS
