Power Distribution: Removal & Installation Dodge Avenger II facelift

Body Electrical 2 illustrations ~318 words

REMOVAL

Note. When removing or installing the IOD fuse, it is important that the ignition switch be in the Off position. Failure to place the ignition switch in the Off position can cause the radio display to become scrambled when the IOD fuse is installed. Removing and installing the IOD fuse again with the ignition switch in the Off position will usually correct the scrambled radio display condition.

  1. Turn the ignition switch to the Off position.
  2. Remove the cover from the Totally Integrated Power Module (TIPM).
  3. Pull on IOD fuse holder until it reaches the 1st detent.

INSTALLATION

  1. Push on IOD fuse until completely seated.
  2. Install the cover to the Totally Integrated Power Module (TIPM).
WARNINGON VEHICLES EQUIPPED WITH AIRBAGS, REFER TO WARNING BEFORE ATTEMPTING ANY STEERING WHEEL, STEERING COLUMN, OR INSTRUMENT PANEL COMPONENT DIAGNOSIS OR SERVICE. FAILURE TO TAKE THE PROPER PRECAUTIONS COULD RESULT IN ACCIDENTAL AIRBAG DEPLOYMENT AND POSSIBLE PERSONAL INJURY.
  1. Disconnect and isolate the battery negative remote cable from the remote terminal on the left shock tower.
  2. Depress the mounting clips to disengage and remove the Junction Block (JB) housing from its mounting bracket.
  3. Disconnect the electrical connectors.
  4. Remove the JB.
  1. Connect the electrical connectors to Junction Block.
  2. Install the Junction Block.
  3. Connect the battery negative cable.

Scheme 6

Scheme 6: REMOVAL
Scheme 6: REMOVAL

Scheme 7

Scheme 7
Scheme 7
  1. Disconnect and isolate the battery negative cable.
  2. Look inside and note position of the retaining bosses (2).
  3. Insert Remover, Power Outlet (special tool #10246, Remover, Power Outlet) (1) into the retaining bosses (2) of the power outlet.
  4. Pull out the base through the mounting ring by gently rocking the tool.
  5. Disconnect the harness (1) from the power outlet (2).
  6. Set the base aside and remove the base mount ring.
  1. Connect the wire connector (1) to the power outlet receptacle (2).
  2. Install the power outlet mount into the panel.
  3. Align the splines on the outside of the power outlet receptacle base connector receptacle with the grooves on the inside of the mount.
  4. Press firmly on the power outlet receptacle base until the retaining bosses of the mount are fully engaged in their receptacles.
  5. Connect the battery negative cable.
