Wireless Control Module (Wcm) - Electrical Diagnostics: Diagnosis Dodge Avenger II рестайлинг

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

DIAGNOSTIC TEST

1. TEST FOR INTERMITTENT CONDITION Put the key in the ignition and turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this code as active? Yes Replace the RKE transmitter and program in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore cause the RKE system to be inoperative. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Put the key in the ignition and turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this code as active? Yes Replace the RKE transmitter and program in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore cause the RKE system to be inoperative. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Put the key in the ignition and turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this code as active? Yes Replace the RKE transmitter and program in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore cause the RKE system to be inoperative. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Put the key in the ignition and turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this code as active? Yes Replace the RKE transmitter and program in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore cause the RKE system to be inoperative. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Put the key in the ignition and turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this code as active? Yes Replace the RKE transmitter and program in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore cause the RKE system to be inoperative. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Put the key in the ignition and turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this code as active? Yes Replace the RKE transmitter and program in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore cause the RKE system to be inoperative. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Put the key in the ignition and turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this code as active? Yes Replace the RKE transmitter and program in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore cause the RKE system to be inoperative. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Put the key in the ignition and turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this code as active? Yes Replace the RKE transmitter and program in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Inform the owner of the most probable cause for this code to set and therefore cause the RKE system to be inoperative. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the RKE transmitter battery and retry the system. If the DTC returns, replace and program the RKE transmitter in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the RKE transmitter battery and retry the system. If the DTC returns, replace and program the RKE transmitter in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the RKE transmitter battery and retry the system. If the DTC returns, replace and program the RKE transmitter in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the RKE transmitter battery and retry the system. If the DTC returns, replace and program the RKE transmitter in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the RKE transmitter battery and retry the system. If the DTC returns, replace and program the RKE transmitter in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the RKE transmitter battery and retry the system. If the DTC returns, replace and program the RKE transmitter in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the RKE transmitter battery and retry the system. If the DTC returns, replace and program the RKE transmitter in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Operate the RKE transmitter in all positions several times. With the scan tool, read DTCs. Does the scan tool display this DTC as active? Yes Replace the RKE transmitter battery and retry the system. If the DTC returns, replace and program the RKE transmitter in accordance with Service Information. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST. No The conditions that caused this code to set are not present at this time. Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs Turn the ignition off. Operate the RKE transmitter in all positions several times. Turn the ignition on. With the scan tool, read DTCs. Are there any door lock related trouble codes present or is the RKE inoperative? Yes Refer to «DIAGNOSTIC CODE INDEX»(ref-485546-S00158710032012071300000) and perform the appropriate diagnostic procedure. No The conditions that caused this code to set are not present at this time. This DTC is set when the vehicle is parked in a location that is affected by external environmental conditions. Suggest to the customer that they park in a slightly different location from where the RKE was inoperable.

1. PROGRAM ALL OF THE IGNITION KEYS Turn the ignition on. With the scan tool, attempt to program the key(s) into the WCM/SKREEM. Was the programming of the key(s) successful? Yes Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Replace the ignition key and attempt to program it into the WCM/SKREEM. If the DTC resets, replace and program the Wireless Control Module (WCM/SKREEM) in accordance with the Service Information. NOTE: If this vehicle is equipped with a Steering Column Lock Module, it must be replaced along with the WCM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT NOTE: An external Radio-Frequency Identification (RFID) key (and/or pass/radio key), such as one used to gain access to a 24 hour gym, can cause this DTC to set and create a no start condition. Inspect the customer's key chain for any type of RFID key. If one is not found, question the customer to see if a spare key chain has this RFID key on it or if it was removed from the original key chain before the vehicle was released for service. If a RFID key is present, remove the ignition key from the vehicle and remove the RFID key from the key chain. For GPEC equipped vehicles, disconnect the battery and wait a minimum of 5 minutes, reconnect and attempt to start the vehicle. For NGC equipped vehicles, turn the ignition on a minimum for one hour, and then attempt to start the vehicle. If the vehicle does not start, continue with the diagnostic test. NOTE: Verify the key being used is the proper key for this vehicle and a blank key. If the key being programmed is not blank (one that has been programmed for another vehicle) this fault will set. With the scan tool, read and record the WCM DTCs. With the scan tool, erase the WCM DTCs. NOTE: Perform the following test several times to make sure the DTC is current. Turn the ignition off. Wait 10 seconds. Turn the ignition on. With the scan tool, read the WCM DTCs. Does the scan tool display the DTC that was previously erased? Yes Go To 2 . No Go To 6 .
2. CHECKING FOR MULTIPLE KEYS Are there multiple vehicle ignition keys available? Yes Go To 3 . No Go To 4 .
3. MULTIPLE KEY OPERATION NOTE: Perform the following steps using one of the vehicle ignition keys. When finished, repeat the procedure using each of the other vehicle keys, one at a time. With the scan tool, erase the WCM DTCs. Turn the ignition off. Wait 10 seconds. Turn the ignition on. With the scan tool, read the WCM DTCs. Is the DTC present for all ignition keys? Yes Replace and program the Wireless Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Replace the ignition key(s) that cause the SKIM DTC. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
4. REPROGRAM KEY With the scan tool, attempt to reprogram the ignition key to the WCM. With the scan tool, erase the WCM DTCs. Wait 10 seconds. Turn the ignition on. With the scan tool, read the WCM DTCs. Does the DTC set again? Yes Go To 5 . No Test complete.
5. PROGRAM NEW IGNITION KEY Replace the ignition key with a new key. With the scan tool, program the new ignition key to the WCM. With the scan tool, erase the WCM DTCs. Turn the ignition off. Wait 10 seconds. Turn the ignition on. With the scan tool, read the WCM DTCs. Does the DTC set again? Yes Replace and program the Sentry Key Remote Entry Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Test complete.
6. INTERMITTENT WIRING HARNESS PROBLEM Turn the ignition off. NOTE: Check the following items: Visually inspect the related wiring harness. Look for any chafed, pierced, pinched, or partially broken wires. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals. Perform any Technical Service Bulletins (TSB) that may apply. Were any problems found? Yes Repair wiring harness/connectors as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Test Complete.

1. REPROGRAM ALL IGNITION KEYS NOTE: This procedure will clear all the key information from the WCM/SKREEM. It is important to obtain all of the customer's ignition keys so they may be reprogrammed into the module. NOTE: If the total number of keys already programmed is equal to Eight and another Key is trying to be programmed, this fault is valid. Explain to the customer no more Keys are allowed to be programmed. Turn the ignition on. With the scan tool, clear all the key information in the WCM/SKREEM. Program the all of the customer keys into the WCM/SKREEM (maximum eight). Did the "Maximum Number of Keys Programmed" display again? Yes Replace and program the Sentry Key Remote Entry Module (WCM/SKREEM) in accordance with the Service Information. NOTE: If this vehicle is equipped with a Steering Column Lock Module it must be replaced along with the WCM/SKREEM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Programming of the keys was successful. Test complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.

1. VERIFY THAT THE DTC IS ACTIVE Turn the ignition on. NOTE: Before continuing, review and check for the following: Review the repair history of the vehicle. Ensure that the vehicle has the correct PCM and WCM/SKREEM installed by verifying the part numbers. With the scan tool, ensure that the PCM and WCM/SKREEM are programmed correctly. Compare the PCM VIN to the WCM/SKREEM VIN and ensure the two VINs match. With the scan tool, clear DTCs. Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. With the scan tool, read DTCs. Does the DTC reset? Yes Replace and program the Wireless Control Module (WCM)/Sentry Key Remote Entry Module (SKREEM) in accordance with the Service Information. NOTE: If this vehicle is equipped with a Steering Column Lock Module, it must be replaced along with the WCM/SKREEM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No The DTC is not active at this time. Test complete.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT NOTE: An external Radio-Frequency Identification (RFID) key (and/or pass/radio key), such as one used to gain access to a 24 hour gym, can cause this DTC to set and create a no start condition. Inspect the customer's key chain for any type of RFID key. If one is not found, question the customer to see if a spare key chain has this RFID key on it or if it was removed from the original key chain before the vehicle was released for service. If a RFID key is present, remove the ignition key from the vehicle and remove the RFID key from the key chain. For GPEC equipped vehicles, disconnect the battery and wait a minimum of 5 minutes, reconnect and attempt to start the vehicle. For NGC equipped vehicles, turn the ignition on a minimum for one hour, and then attempt to start the vehicle. If the vehicle does not start, continue with the diagnostic test. With the scan tool, erase the WCM DTCs. Turn the ignition off. Wait 10 seconds. Turn the ignition on and wait two minutes. With the scan tool, read the WCM DTCs. Does the scan tool display the DTC that was previously erased? Yes Go To 2 . No Go To 4 .
2. VERIFYING THE PCM VIN Turn the ignition on. With the scan tool, select Engine system from the main menu. Display and record the Vehicle Identification Number. NOTE: Make sure that a VIN has been programmed into the PCM. If a VIN is not displayed, attempt to program the PCM with the correct VIN before continuing. Does the VIN recorded from the PCM match the VIN of the vehicle? Yes Go To 3 . No Using the scan tool perform the PCM Replace procedure to update the VIN in the PCM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
3. REPLACE WCM AND CHECK DTCS Turn the ignition off. Replace and program the Wireless Control Module in accordance with the Service Information. Turn the ignition on. With the scan tool, display and clear all PCM and WCM DTCs. Perform five ignition key cycles leaving the ignition key on for 90 seconds per cycle. With the scan tool, check for WCM DTCs. Does the scan tool display the same DTC? Yes Replace and program the Powertrain Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No The repair is complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
4. INTERMITTENT Turn the ignition off. NOTE: Check for the following conditions: Visually inspect the related wiring harness. Look for any chafed, pierced, pinched, or partially broken wires. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals. Perform any Technical Service Bulletins (TSB) that may apply. Were any problems found? Yes Repair wiring harness/connectors as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Test Complete.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT With the scan tool, erase the WCM DTCs. Turn the ignition off. Wait 10 seconds. Turn the ignition on and wait 2 minutes. With the scan tool, read the WCM DTCs. Does the scan tool display the DTC that was previously erased? Yes Go To 2 . No Go To 4 .
2. VERIFYING THE PCM VIN Turn the ignition on. With the scan tool, select Engine system from the main menu. Display and record the Vehicle Identification Number. NOTE: Ensure that a VIN has been programmed into the PCM. If a VIN is not displayed, attempt to program the PCM with the correct VIN before continuing. Does the VIN recorded from the PCM match the VIN of the vehicle? Yes Go To 3 . No Using the scan tool perform the PCM Replace procedure to update the VIN in the PCM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
3. REPLACE WCM AND CHECK DTCS Turn the ignition off. Replace and program the Sentry Key Remote Entry Module in accordance with the Service Information. Turn the ignition on. With the scan tool, display and clear all PCM and WCM DTCs. Perform 5 ignition key cycles leaving the ignition key on for 90 seconds per cycle. With the scan tool, check for WCM DTCs. Does the scan tool display the same DTC? Yes Using the scan tool perform the PCM Replace procedure to update the VIN in the PCM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No The repair is complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
4. INTERMITTENT Turn the ignition off. NOTE: Check for the following conditions: Visually inspect the related wiring harness. Look for any chafed, pierced, pinched, or partially broken wires. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals. Refer to any Technical Service Bulletins (TSB) that may apply. Were any problems found? Yes Repair wiring harness/connectors as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Test Complete.

Scheme 24

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. STEERING COLUMN LOCK MODULE With the scan tool, record and erase the WCM DTCs. Remove and insert the key from the ignition switch several times then leave the key in the run position. With the scan tool, read the DTCs. Does the scan tool display: B1A6B STEERING COLUMN LOCK MODULE NOT INITIALIZED? Yes Go To 2 . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension.
2. INITIALIZE STEERING COLUMN LOCK MODULE With the scan tool, erase the DTCs in the WCM. With the scan tool, perform the Steering Wheel Lock Module (ELV) Replaced routine. Turn the Ignition off, wait 15 seconds then turn the ignition back on. Remove and insert the key from the ignition switch several times then leave the key in the run position. With the scan tool, read the DTCs. Does the scan tool display: B1A6B STEERING COLUMN LOCK MODULE NOT INITIALIZED? Yes Replace the Steering Column Lock Module in accordance with the service information. The Wireless Control Module (WCM) must also be replaced along with the Steering Column Lock Module (ELV). When replacing the WCM and the Steering Column Lock Module (ELV), the WCM MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed. . Replace and program the Wireless Control Module (WCM) (SKREEM). Refer to «MODULE, SENTRY KEY IMMOBILIZER (SKREEM), REMOVAL»(ref-485511-S41522662122012071300000) . Replace and program the Steering Column Lock Module (ELV). Refer to «MODULE, SHAFT LOCK, REMOVAL»(ref-485511-S02649253802012071300000) . Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WIRELESS CONTROL MODULE (WCM) VERIFICATION Test. No Test complete Refer to «STANDARD PROCEDURE»(ref-485529-S24369246162012071300000) and perform the BODY VERIFICATION TEST.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT NOTE: Diagnose any related Powertrain DTCs before continuing. With a scan tool, read and record DTCs. Using the scan tool, clear DTCs. Perform five ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. Using the scan tool, read DTCs. Does the DTC reset? Yes Go To 3 . No Go To 2 .
2. INTERMITTENT CONDITION NOTE: Check for any of the follow conditions: Poor wire to terminal connection Corroded terminals Backed out or loose terminals Broken wire internal to the insulation Dirty (partial) module ground With the ignition on, wiggle the related wires. Using a scan tool, read DTCs. Does the DTC reset? Yes Repair the wiring as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No DTC is not active at this time. Test complete.
3. FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT OPENED NOTE: Check the related fuses to the Fused Ignition Switch Output (Run-Start) circuit. If the fuse is found to be open, repair the circuit for a shorted condition. Turn the ignition off. Disconnect the WCM harness connector. Turn the ignition on. Using a 12-volt test light connected to ground, probe the Fused Ignition Switch Output (Run-Start) circuit in the WCM harness connector. Does the test light illuminate brightly? Yes Go To 4 . No Repair the Fused Ignition Switch Output (Run-Start) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
4. WCM NOTE: A dirty (partial) ground can cause abnormal conditions within a system. Make sure the module has a good ground before continuing. Turn the ignition off. Reconnect the WCM connector Back probe the Fused Ignition Switch Output (Run-Start) circuit. Start the engine. Using the scan tool, view battery voltage under Data Display in the Engine category. Compare the voltage on the scan tool to the voltage reading on the Voltmeter. Is the voltage on the scan tool equal to the Voltmeter reading +/- 0.5-volt? Yes Replace and program the Wireless Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Repair the Fused Ignition Switch Output (Run-Start) circuit for high resistance. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT NOTE: Diagnose any related Powertrain DTCs before continuing. With a scan tool, read and record DTCs. Using the scan tool, clear DTCs. Perform five ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. Using the scan tool, read DTCs. Does the DTC reset? Yes Go To 3 . No Go To 2 .
2. INTERMITTENT CONDITION NOTE: Check for any of the follow conditions: Poor wire to terminal connection Corroded terminals Backed out or loose terminals Broken wire internal to the insulation Dirty (partial) module ground With the ignition on, wiggle the related wires. Using a scan tool, read DTCs. Does the DTC reset? Yes Repair the wiring as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No DTC is not active at this time. Test complete.
3. FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT SHORTED TO BATTERY VOLTAGE NOTE: A dirty (partial) ground can cause abnormal conditions within a system. Make sure the module has a good ground before continuing. Turn the ignition off. Disconnect the WCM harness connector. Using a 12-volt test light connected to ground, probe the Fused Ignition Switch Output (Run-Start) circuit in the WCM harness connector. Does the test light illuminate brightly? Yes Repair the Fused Ignition Switch Output (Run-Start) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Replace and program the Wireless Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT NOTE: Diagnose any related Powertrain DTCs before continuing. With a scan tool, read and record DTCs. With the scan tool, clear DTCs. Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. Using the scan tool, read DTCs. Does the DTC reset? Yes Go To 3 . No Go To 2 .
2. INTERMITTENT CONDITION NOTE: Check for any of the follow conditions: Poor wire to terminal connection Corroded terminals Backed out or loose terminals Broken wire internal to the insulation Dirty (partial) module ground With the ignition on, wiggle the related wires. Using a scan tool, read DTCs. Does the DTC reset? Yes Repair the wiring as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No DTC is not active at this time. Test complete.
3. FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT OPEN NOTE: Check the related fuses to the Fused Ignition Switch Output (Run-Start) circuit. If the fuse is found to be open repair the circuit for a shorted condition. Turn the ignition off. Disconnect the WCM harness connector. Turn the ignition on. Using a 12 volt test light connected to ground, probe the Fused Ignition Switch Output (Run-Start) circuit in the WCM harness connector. Does the test light illuminate brightly? Yes Go To 4 . No Repair the Fused Ignition Switch Output (Run-Start) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
4. FUSED (B+) CIRCUIT OPEN Turn the ignition off. Using a 12 volt test light connected to ground, probe the Fused (B+) circuit in the WCM harness connector. Does the test light illuminate brightly? Yes Go To 5 . No Repair the Fused (B+) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
5. WCM NOTE: Repeat the below procedure for both the Fused Ignition Switch Output (Run-Start) circuit and the Fused (B+) circuit. NOTE: A dirty (partial) ground can cause abnormal conditions within a system. Ensure the module has a good ground before continuing. Turn the ignition off. Reconnect the WCM connector. Back probe the Fused Ignition Switch Output (Run-Start) circuit and then the Fused (B+) circuit. Start the engine. Using the scan tool, view battery voltage under Data Display in the Engine category. Compare the voltage on the scan tool to the voltage reading on the voltmeter. Is the voltage on the scan tool equal to the voltmeter reading +/-.5 volt? Yes Replace and program the Wireless Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Repair the circuit(s) that indicated the incorrect voltage. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT NOTE: Diagnose any related Powertrain DTCs before continuing. With a scan tool, read and record DTCs. With the scan tool, clear DTCs. Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. Using the scan tool, read DTCs. Does the DTC reset? Yes Go To 3 . No Go To 2 .
2. INTERMITTENT CONDITION NOTE: Check for any of the follow conditions: Poor wire to terminal connection Corroded terminals Backed out or loose terminals Broken wire internal to the insulation Dirty (partial) module ground With the ignition on, wiggle the related wires. Using a scan tool, read DTCs. Does the DTC reset? Yes Repair the wiring as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No DTC is not active at this time. Test complete.
3. FUSED IGNITION SWITCH OUTPUT (RUN-START) CIRCUIT SHORTED TO BATTERY VOLTAGE NOTE: A dirty (partial) ground can cause abnormal conditions within a system. Ensure the module has a good ground before continuing. Turn the ignition off. Disconnect the WCM harness connector. Using a 12 volt test light connected to ground, probe the Fused Ignition Switch Output (Run-Start) circuit in the WCM harness connector. Does the test light illuminate brightly? Yes Repair the Fused Ignition Switch Output (Run-Start) circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Replace and reprogram the Wireless Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT NOTE: Diagnose any related Powertrain DTCs before continuing. With a scan tool, read and record DTCs. With the scan tool, clear DTCs. Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. Using the scan tool, select View DTCs. Does the DTC reset? Yes Go To 3 . No Go To 2 .
2. INTERMITTENT CONDITION NOTE: Check for any of the follow conditions: Poor wire to terminal connection Corroded terminals Backed out or loose terminals Broken wire internal to the insulation Dirty (partial) module ground With the ignition on, wiggle the related wires. Using a scan tool, View DTCs. Does the DTC reset? Yes Repair the wiring as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No DTC is not active at this time. Test complete.
3. FUSED (B+) CIRCUIT OPEN NOTE: Check the related fuses to the Fused (B+) circuit. If the fuse is found to be open repair the circuit for a shorted condition. Turn the ignition off. Disconnect the SKREEM harness connector. Turn the ignition on. Using a 12 volt test light connected to ground, probe the Fused (B+) circuit in the SKREEM harness connector. Does the test light illuminate brightly? Yes Go To 4 . No Repair the Fused (B+) circuit for an open. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
4. SKREEM NOTE: A dirty (partial) ground can cause abnormal conditions within a system. Ensure the module has a good ground before continuing. Turn the ignition off. Reconnect the SKREEM connector Back probe the Fused (B+) circuit. Start the engine. Using the scan tool, view battery voltage under Data Display in the Engine category. Compare the voltage on the scan tool to the voltage reading on the voltmeter. Is the voltage on the scan tool equal to the voltmeter reading +/-.5 volt? Yes Replace and program the Wireless Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Repair the Fused (B+) circuit for high resistances. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT CAUTION: Diagnose and repair all Powertrain DTCs before continuing. Turn the ignition on. With the scan tool, record and erase the WCM DTCs. Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. Using the scan tool, read the WCM DTCs. Does the DTC reset? Yes Replace and reprogram the Wireless Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No The DTC is not active at this time. Test complete.

1. VERIFY THAT THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE Turn the ignition on. NOTE: Before continuing, review and check for the following: Review the repair history of the vehicle. Ensure that the vehicle has the correct PCM and WCM/SKREEM installed by verifying the part numbers. With the scan tool, ensure that the PCM and WCM/SKREEM are programmed correctly. Compare the PCM VIN to the WCM/SKREEM VIN and ensure the two VINs match. With the scan tool, clear DTCs. Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. With the scan tool, select View DTCs. Does the DTC reset? Yes Replace and program the Wireless Control Module/Sentry Key Remote Entry Module in accordance with the Service Information. NOTE: If this vehicle is equipped with a Steering Column Lock Module, it must be replaced along with the WCM/SKREEM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No The DTC is not active at this time. Test complete.

1. DETERMINING IF DIAGNOSTIC TROUBLE CODE (DTC) IS CURRENT With the scan tool, erase the WCM DTCs. Turn the ignition off. Wait 10 seconds. Turn the ignition on and wait 2 minutes. With the scan tool, read the WCM DTCs. Does the scan tool display the DTC that was previously erased? Yes Go To 2 . No Go To 4 .
2. VERIFYING THE PCM VIN Turn the ignition on. With the scan tool, select Engine system from the main menu. Display and record the Vehicle Identification Number. NOTE: Ensure that a VIN has been programmed into the PCM. If a VIN is not displayed, attempt to program the PCM with the correct VIN before continuing. Does the VIN recorded from the PCM match the VIN of the vehicle? Yes Go To 3 . No Replace and program the Wireless Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
3. REPLACE WCM AND CHECK DTC'S Turn the ignition off. Replace and program the Sentry Key Remote Entry Module in accordance with the Service Information. Turn the ignition on. With the scan tool, display and clear all PCM and WCM DTCs. Perform 5 ignition key cycles leaving the ignition key on for 90 seconds per cycle. With the scan tool, check for WCM DTCs. Does the scan tool display the same DTC? Yes Replace and program the Powertrain Control Module in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No The repair is complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
4. INTERMITTENT Turn the ignition off. NOTE: Check for the following conditions: Visually inspect the related wiring harness. Look for any chafed, pierced, pinched, or partially broken wires. Visually inspect the related wiring harness connectors. Look for broken, bent, pushed out, or corroded terminals. Refer to any Technical Service Bulletins (TSB) that may apply. Were any problems found? Yes Repair wiring harness/connectors as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No Test Complete.

1. VERIFY THAT THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE Turn the ignition on. NOTE: Before continuing, review and check for the following: Review the repair history of the vehicle. Ensure that the vehicle has the correct PCM and WCM/SKREEM installed by verifying the part numbers. With the scan tool, ensure that the PCM and WCM/SKREEM are programmed correctly. Compare the PCM VIN to the WCM/SKREEM VIN and ensure the two VINs match. With the scan tool, clear DTCs. Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. With the scan tool, read DTCs. Does the DTC reset? Yes Replace and program the Wireless Control Module (WCM)/Sentry Key Remote Entry Module (SKREEM) in accordance with the Service Information. NOTE: If this vehicle is equipped with a Steering Column Lock Module, it must be replaced along with the WCM/SKREEM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No The DTC is not active at this time. Test complete.

1. VERIFY THAT THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE Turn the ignition on. NOTE: Before continuing, review and check for the following: Review the repair history of the vehicle. Ensure that the vehicle has the correct PCM and WCM/SKREEM installed by verifying the part numbers. With the scan tool, ensure that the PCM and WCM/SKREEM are programmed correctly. Compare the PCM VIN to the WCM/SKREEM VIN and ensure the two VINs match. With the scan tool, clear DTCs. Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. With the scan tool, read DTCs. Does the DTC reset? Yes Replace and program the Wireless Control Module (WCM)/Sentry Key Remote Entry Module (SKREEM) in accordance with the Service Information. NOTE: If this vehicle is equipped with a Steering Column Lock Module, it must be replaced along with the WCM/SKREEM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No The DTC is not active at this time. Test complete.

1. VERIFY THAT THE DTC IS ACTIVE Turn the ignition on. NOTE: Before continuing, review and check for the following: Review the repair history of the vehicle. Ensure that the vehicle has the correct PCM and WCM/SKREEM installed by verifying the part numbers. With the scan tool, ensure that the PCM and WCM/SKREEM are programmed correctly. Compare the PCM VIN to the WCM/SKREEM VIN and ensure the two VINs match. With the scan tool, clear DTCs. Perform 5 ignition cycles, leaving the ignition switch on for a minimum of 90 seconds per cycle. With the scan tool, read DTCs. Does the DTC reset? Yes Replace and program the Wireless Control Module (WCM)/Sentry Key Remote Entry Module (SKREEM) in accordance with the Service Information. NOTE: If this vehicle is equipped with a Steering Column Lock Module, it must be replaced along with the WCM/SKREEM. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. No The DTC is not active at this time. Test complete.

Scheme 25

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article

1. DTC STATUS NOTE: If the incorrect Placard Values were programmed into the WCM, a DTC could be set. Before continuing with any TPM diagnostic test, using the scan tool, check that the correct Placard Values have been programmed in to the module. NOTE: If the following conditions are present: Low Tire Pressure DTC Tire Pressure Monitoring (TPM) Sensor Internal DTC Spare Tire is not equipped with a Tire Pressure Monitoring (TPM) Sensor Spare Tire is currently on the vehicle Repair the tire and place it back on the vehicle. Test drive the vehicle. If the DTCs reset continue with the diagnostic procedure. Ignition on, engine not running. With the scan tool, read DTCs. Is the DTC status at this time? Yes Go To 2 . No Go To 5 .
2. LOW TIRE PRESSURE NOTE: The DTC can be caused by many different factors and might not be a sensor/transmitter or a WCM) fault. Interference from other elements will over power the sensor/transmitter RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. NOTE: Seasonal temperature changes will affect tire pressure, and may have caused the tire pressure to fall below the low pressure warning threshold. Tire pressure should always be set based on cold inflation tire pressure (placard). This is defined as the tire pressure after a vehicle has not been driven for more then 3 hours, and in outside ambient temperatures. Correct all tire pressure to the recommended specifications and wait 2 minutes. With the scan tool, clear DTCs in the Wireless Control Module (WCM). Test Drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 15 m.p.h. (24 km/h). Use a TPM-RKE Analyzer 9936 to scan each tire pressure sensor, and make sure the Sensor IDs matches what is programmed into the WCM. The Sensor Identifications are located under "Data Display" for the "WCM Wireless Control Module". If the sensor IDs does not match, following the programming steps outlined in the diagnostic scan tool for "Program Tire Sensor ID w/TPM Tool" under "Miscellaneous Functions" for the "WCM/Wireless Control Module" menu item. With the scan tool, read DTCs. NOTE: When scanning a sensor with a TPM-RKE Analyzer 9936, replace the TPM sensor if the results show a "Damaged Accel", "Damaged Temp", or "Damaged Press". Does the DTC reset or is the status Active for this DTC? Yes Go To 3 . No Test Complete.
3. TIRE PRESSURE MONITORING (TPM) SENSOR NOTE: Before continuing, ensure the tire is free from any leaks or damage that would cause a low tire pressure condition. If a problem is found, repair as necessary and retest. With the scan tool, go under "Data Display" for the "WCM Wireless Control Module" and find the compensated tire pressure values. Located underneath each Sensor Identification locations. If any compensated tire pressure values are equal or lower then the Tire Low Pressure Threshold. The corresponding TPM sensor needs to be located and replaced. NOTE: The following tests are used to locate the Tire Pressure Monitoring (TPM) Sensor/Transmitter that is setting the low pressure fault. If the tires have been rotated, the Tire Pressure Monitoring (TPM) Sensor/Transmitter are no longer in sequence from the factory. Faults are linked to the sensor/transmitter IDs. You MUST locate the correct Tire Pressure Monitoring (TPM) Sensor/Transmitter that set the fault before continuing. Use one or more of the following methods below. METHOD 1: Use a TPM-RKE Analyzer 9936 to scan each tire pressure sensor. If a suspected sensor has been located, lower the tire pressure to 20 PSI, wait for two minutes, and check the scan tool for changes to any compensated tire pressure values. If there was a pressure change to any compensated tire pressure values, check to make sure that the TPM-RKE Analyzer is set correctly, and repeat the process on each wheel on the vehicle until the faulty Sensor/Transmitter has been identified. NOTE: When scanning a sensor with a TPM-RKE Analyzer 9936, replace the TPM sensor if the results show a "Damaged Accel", "Damaged Temp", or "Damaged Press". METHOD 2: Starting with the left front wheel, deflate the tire to 20 PSI, wait two minutes, and check the scan tool for changes to any compensated tire pressure values. If there was a pressure change to any compensated tire pressure value, repeat this process on each wheel on the vehicle until the faulty Sensor/Transmitter has been identified. Has the malfunctioning/faulty TPM sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 4 .
4. WIRELESS CONTROL MODULE (WCM) Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST. With the scan tool, read DTCs. Drive the vehicle for a minimum of 10 minutes while maintaining a continuous speed above 24 km/h (15 mph). During this time the system will learn the sensor IDs. Are there any DTCs present? Yes Repair not complete, refer to «DIAGNOSTIC CODE INDEX»(ref-485546-S00158710032012071300000) and perform the appropriate diagnostic procedure. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Repair is complete.
5. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions necessary to set this DTC are not present at this time. Perform any Technical Service Bulletins that may apply to this condition. With the scan tool, erase DTCs in the Wireless Control Module (WCM). Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). With the scan tool, read DTCs. Does the DTC reset or is the status Active for this DTC? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Test complete.

1. DTC STATUS IS ACTIVE NOTE: Before beginning diagnostic procedure, verify that the tire pressures are correct. NOTE: This DTC can be caused by many different factors and might not be a TPM Sensor or a WCM fault. Interference from other elements will over power the sensor RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. Ignition on, engine not running. With the scan tool, record and erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM Sensor data and allow for the system to update. With the scan tool, read DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 11 .
2. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT ACTIVE Ignition on, engine not running. With the scan tool, select Data Display for the WCM and locate the following: Tire 1 Pressure Sensor HW Fault Tire 1 Pressure Sensors Missing ID Tire 1 Temperature Sensor HW Fault Tire 1 Temperature Sensor SW O/U Tire 1 Acceleration Sensor HW Fault Tire 1 Loss of Signal from Pressure Sensor Do any of the above faults read "Set"? Yes Go To 3 . No Go To 10 .
3. TPM-RKE ANALYZER 9936 Is there a TPM-RKE Analyzer available? Yes Go To 4 . No Go To 10 .
4. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL DTC NOTE: This fault can be set if the incorrect or no TPM Sensor is installed on the vehicle. If the spare tire is currently installed on the vehicle, and it is not equipped with a TPM Sensor, this DTC can be set. Replace the spare with a TPM Sensor equipped wheel and tire assembly. Test drive the vehicle. If the DTC resets, continue with the diagnostic procedure. Perform a visual inspection to verify that all road wheels are equipped with TPM Sensors. With the TPM-RKE Analyzer 9936 verify the correct TPM Sensors are on the vehicle. Are the correct TPM Sensors installed on the vehicle? Yes Go To 5 . No Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
5. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: If the tires have been rotated, the TPM Sensor is no longer in sequence from the factory. Faults are linked to the TPM Sensor IDs. You MUST locate the correct TPM Sensor that set the fault before continuing. Use the following method below at every tire location. NOTE: If you receive no response from any of the tire pressure sensors, verify that the TPM-RKE Analyzer 9936 is set correctly, and repeat the process on each non-responsive wheel. With the TPM-RKE Analyzer 9936, scan each TPM Sensor for a response and store in the proper location of the TPM-RKE Analyzer 9936. Were the TPM Sensor IDs able to be stored in the proper locations? Yes Go To 7 . No Go To 6 .
6. TIRE PRESSURE MONITORING (TPM) SENSOR NON-RESPONSIVE With the TPM-RKE Analyzer 9936, check to see if the any of the TPM Sensors do not respond after repeated attempts or display the following: "Damaged Accel" "Damaged Press" "Damaged Temp" Are any of the TPM Sensors not responding or displaying the information listed above? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 7 .
7. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID NOTE: If the TPM Sensor IDs do not match, it may be necessary to move the vehicle to a location away from other TPM Sensors and repeat this step. With the TPM-RKE Analyzer 9936, verify the Sensor IDs match what is programmed in the WCM. With the scan tool, select Data Display for the WCM. Do the TPM Sensor IDs match what is stored in the WCM Yes Go To 8 . No With the scan tool, perform the appropriate procedure for uploading the correct IDs in the (WCM). Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
8. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - REMOTE START ANTENNA If the vehicle is equipped with factory installed remote start feature, check to make sure the antenna connector is properly connected to the WCM. Is the Remote Start Antenna properly connected to the WCM? Yes Go To 9 . No Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
9. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - INTERFERENCE FROM EXTERNAL COMPONENTS NOTE: The DTC can be caused by many different factors and might not be a sensor or a WCM fault. Interference from other elements will over power the sensor RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. NOTE: A system fault can occur by many scenarios, including the following: Signal interference due to electronic devices or driving next to facilities emitting the same Radio Frequencies as the TPM sensors. Installing aftermarket window tinting that affects radio wave signals. Accumulation of snow or ice around the wheels or wheel housings. Using tire chains on the vehicle. Using wheels/tires not equipped with TPM Sensors. Loss of communication with the TPM Transponders or TPM Sensors. Attempt to isolate the external component responsible for the RF interference. Has an interfering external component been isolated? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
10. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: Some vehicles will not receive TPM Sensor data when the vehicle is stationary. The vehicle may need to be driven at speeds greater than 24 km/h (15 mph) for about a minute in order to receive TPM Sensor data. Starting with the left front wheel, deflate the tire to 20 PSI, wait Two minutes, and check the scan tool for changes to any compensated tire pressure values Look for a tire location whose sensor ID that is not responding. Repeat this test on each wheel on the vehicle until the sensor in question has been identified Has the Tire Pressure Monitoring (TPM) Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
11. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring harness and connectors. Perform any Technical Service Bulletins that may apply to this condition. With the scan tool, erase DTCs. Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). Does the DTC reset or is the status Active for this DTC? Yes Return to the beginning of this test and perform the appropriate diagnostic procedure as necessary. No Test Complete.

1. DTC STATUS IS ACTIVE NOTE: Before beginning diagnostic procedure, verify that the tire pressures are correct. NOTE: This DTC can be caused by many different factors and might not be a TPM Sensor or a WCM fault. Interference from other elements will over power the sensor RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. Ignition on, engine not running. With the scan tool, record and erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM Sensor data and allow for the system to update. With the scan tool, select View DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 11 .
2. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT ACTIVE Ignition on, engine not running. With the scan tool, select Data Display for the WCM and locate the following: Tire 2 Pressure Sensor HW Fault Tire 2 Pressure Sensors Missing ID Tire 2 Temperature Sensor HW Fault Tire 2 Temperature Sensor SW O/U Tire 2 Acceleration Sensor HW Fault Tire 2 Loss of Signal from Pressure Sensor Do any of the above faults read "Set"? Yes Go To 3 . No Go To 10 .
3. TPM-RKE ANALYZER 9936 Is there a TPM-RKE Analyzer 9936 available? Yes Go To 4 . No Go To 10 .
4. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL DTC NOTE: This fault can be set if the incorrect or no TPM Sensor is installed on the vehicle. If the spare tire is currently installed on the vehicle, and it is not equipped with a TPM Sensor, this DTC can be set. Replace the spare with a TPM Sensor equipped wheel and tire assembly. Test drive the vehicle. If the DTC resets, continue with the diagnostic procedure. Perform a visual inspection to verify that all road wheels are equipped with TPM Sensors. With the TPM-RKE Analyzer 9936 verify the correct TPM Sensors are on the vehicle. Are the correct TPM Sensors installed on the vehicle? Yes Go To 5 . No Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
5. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: If the tires have been rotated, the TPM Sensor is no longer in sequence from the factory. Faults are linked to the TPM Sensor IDs. You MUST locate the correct TPM Sensor that set the fault before continuing. Use the following method below at every tire location. NOTE: If you receive no response from any of the tire pressure sensors, verify that the TPM-RKE Analyzer 9936 is set correctly, and repeat the process on each non-responsive wheel. With the TPM-RKE Analyzer 9936, scan each TPM Sensor for a response and store in the proper location of the TPM-RKE Analyzer 9936. Were the TPM Sensor IDs able to be stored in the proper locations? Yes Go To 7 . No Go To 6 .
6. TIRE PRESSURE MONITORING (TPM) SENSOR NON-RESPONSIVE With the TPM-RKE Analyzer 9936, check to see if the any of the TPM Sensors do not respond after repeated attempts or display the following: "Damaged Accel" "Damaged Press" "Damaged Temp" Are any of the TPM Sensors not responding or displaying the information listed above? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 7 .
7. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID NOTE: If the TPM Sensor IDs do not match, it may be necessary to move the vehicle to a location away from other TPM Sensors and repeat this step. With the TPM-RKE Analyzer 9936, verify the Sensor IDs match what is programmed in the WCM. With the scan tool, select Data Display for the WCM. Do the TPM Sensor IDs match what is stored in the WCM Yes Go To 8 . No With the scan tool, perform the appropriate procedure for uploading the correct IDs in the (WCM). Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
8. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - REMOTE START ANTENNA If the vehicle is equipped with factory installed remote start feature, check to make sure the antenna connector is properly connected to the WCM. Is the Remote Start Antenna properly connected to the WCM? Yes Go To 9 . No Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
9. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - INTERFERENCE FROM EXTERNAL COMPONENTS NOTE: The DTC can be caused by many different factors and might not be a sensor or a WCM fault. Interference from other elements will over power the sensor RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. NOTE: A system fault can occur by many scenarios, including the following: Signal interference due to electronic devices or driving next to facilities emitting the same Radio Frequencies as the TPM sensors. Installing aftermarket window tinting that affects radio wave signals. Accumulation of snow or ice around the wheels or wheel housings. Using tire chains on the vehicle. Using wheels/tires not equipped with TPM Sensors. Loss of communication with the TPM Transponders or TPM Sensors. Attempt to isolate the external component responsible for the RF interference. Has an interfering external component been isolated? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
10. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: Some vehicles will not receive TPM Sensor data when the vehicle is stationary. The vehicle may need to be driven at speeds greater than 24 km/h (15 mph) for about a minute in order to receive TPM Sensor data. Starting with the left front wheel, deflate the tire to 20 PSI, wait Two minutes, and check the scan tool for changes to any compensated tire pressure values Look for a tire location whose sensor ID that is not responding. Repeat this test on each wheel on the vehicle until the sensor in question has been identified Has the Tire Pressure Monitoring (TPM) Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
11. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring harness and connectors. Perform any Technical Service Bulletins that may apply to this condition. With the scan tool, erase DTCs. Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). Does the DTC reset or is the status Active for this DTC? Yes Return to the beginning of this test and perform the appropriate diagnostic procedure as necessary. No Test Complete.

1. DTC STATUS IS ACTIVE NOTE: Before beginning diagnostic procedure, verify that the tire pressures are correct. NOTE: This DTC can be caused by many different factors and might not be a TPM Sensor or a WCM fault. Interference from other elements will over power the sensor RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. Ignition on, engine not running. With the scan tool, record and erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM Sensor data and allow for the system to update. With the scan tool, select View DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 11 .
2. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT ACTIVE Ignition on, engine not running. With the scan tool, select Data Display for the WCM and locate the following: Tire 3 Pressure Sensor HW Fault Tire 3 Pressure Sensors Missing ID Tire 3 Temperature Sensor HW Fault Tire 3 Temperature Sensor SW O/U Tire 3 Acceleration Sensor HW Fault Tire 3 Loss of Signal from Pressure Sensor Do any of the above faults read "Set"? Yes Go To 3 . No Go To 10 .
3. TPM-RKE ANALYZER 9936 Is there a TPM-RKE Analyzer 9936 available? Yes Go To 4 . No Go To 10 .
4. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL DTC NOTE: This fault can be set if the incorrect or no TPM Sensor is installed on the vehicle. If the spare tire is currently installed on the vehicle, and it is not equipped with a TPM Sensor, this DTC can be set. Replace the spare with a TPM Sensor equipped wheel and tire assembly. Test drive the vehicle. If the DTC resets, continue with the diagnostic procedure. Perform a visual inspection to verify that all road wheels are equipped with TPM Sensors. With the TPM-RKE Analyzer 9936 verify the correct TPM Sensors are on the vehicle. Are the correct TPM Sensors installed on the vehicle? Yes Go To 5 . No Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
5. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: If the tires have been rotated, the TPM Sensor is no longer in sequence from the factory. Faults are linked to the TPM Sensor IDs. You MUST locate the correct TPM Sensor that set the fault before continuing. Use the following method below at every tire location. NOTE: If you receive no response from any of the TPM Sensors, verify that the TPM-RKE Analyzer 9936 is set correctly, and repeat the process on each non-responsive wheel. With the TPM-RKE Analyzer 9936, scan each TPM Sensor for a response and store in the proper location of the TPM-RKE Analyzer 9936. Were the TPM Sensor IDs able to be stored in the proper locations? Yes Go To 7 . No Go To 6 .
6. TIRE PRESSURE MONITORING (TPM) SENSOR NON-RESPONSIVE With the TPM-RKE Analyzer 9936, check to see if the any of the TPM Sensors do not respond after repeated attempts or display the following: "Damaged Accel" "Damaged Press" "Damaged Temp" Are any of the TPM Sensors not responding or displaying the information listed above? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 7 .
7. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID NOTE: If the TPM Sensor IDs do not match, it may be necessary to move the vehicle to a location away from other TPM Sensors and repeat this step. With the TPM-RKE Analyzer 9936, verify the Sensor IDs match what is programmed in the WCM. With the scan tool, select Data Display for the WCM. Do the TPM Sensor IDs match what is stored in the WCM Yes Go To 8 . No With the scan tool, perform the appropriate procedure for uploading the correct IDs in the (WCM). Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
8. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - REMOTE START ANTENNA If the vehicle is equipped with factory installed remote start feature, check to make sure the antenna connector is properly connected to the WCM. Is the Remote Start Antenna properly connected to the WCM? Yes Go To 9 . No Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
9. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - INTERFERENCE FROM EXTERNAL COMPONENTS NOTE: The DTC can be caused by many different factors and might not be a sensor or a WCM fault. Interference from other elements will over power the sensor RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. NOTE: A system fault can occur by many scenarios, including the following: Signal interference due to electronic devices or driving next to facilities emitting the same Radio Frequencies as the TPM sensors. Installing aftermarket window tinting that affects radio wave signals. Accumulation of snow or ice around the wheels or wheel housings. Using tire chains on the vehicle. Using wheels/tires not equipped with TPM Sensors. Loss of communication with the TPM Transponders or TPM Sensors. Attempt to isolate the external component responsible for the RF interference. Has an interfering external component been isolated? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
10. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: Some vehicles will not receive TPM Sensor data when the vehicle is stationary. The vehicle may need to be driven at speeds greater than 24 km/h (15 mph) for about a minute in order to receive TPM Sensor data. Starting with the left front wheel, deflate the tire to 20 PSI, wait Two minutes, and check the scan tool for changes to any compensated tire pressure values Look for a tire location whose sensor ID that is not responding. Repeat this test on each wheel on the vehicle until the sensor in question has been identified Has the Tire Pressure Monitoring (TPM) Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
11. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring harness and connectors. Perform any Technical Service Bulletins that may apply to this condition. With the scan tool, erase DTCs. Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). Does the DTC reset or is the status Active for this DTC? Yes Return to the beginning of this test and perform the appropriate diagnostic procedure as necessary. No Test Complete.

1. DTC STATUS IS ACTIVE NOTE: Before beginning diagnostic procedure, verify that the tire pressures are correct. NOTE: This DTC can be caused by many different factors and might not be a TPM Sensor or a WCM fault. Interference from other elements will over power the sensor RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. Ignition on, engine not running. With the scan tool, record and erase DTCs. Test drive the vehicle at a speed greater than 24 km/h (15 mph) for a minimum of 10 minutes in order to receive TPM Sensor data and allow for the system to update. With the scan tool, select View DTCs. Is the DTC status Active at this time? Yes Go To 2 . No Go To 11 .
2. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT ACTIVE Ignition on, engine not running. With the scan tool, select Data Display for the WCM and locate the following: Tire 4 Pressure Sensor HW Fault Tire 4 Pressure Sensors Missing ID Tire 4 Temperature Sensor HW Fault Tire 4 Temperature Sensor SW O/U Tire 4 Acceleration Sensor HW Fault Tire 4 Loss of Signal from Pressure Sensor Do any of the above faults read "Set"? Yes Go To 3 . No Go To 10 .
3. TPM-RKE ANALYZER 9936 Is there a TPM-RKE Analyzer 9936 available? Yes Go To 4 . No Go To 10 .
4. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL DTC NOTE: This fault can be set if the incorrect or no TPM Sensor is installed on the vehicle. If the spare tire is currently installed on the vehicle, and it is not equipped with a TPM Sensor, this DTC can be set. Replace the spare with a TPM Sensor equipped wheel and tire assembly. Test drive the vehicle. If the DTC resets, continue with the diagnostic procedure. Perform a visual inspection to verify that all road wheels are equipped with TPM Sensors. With the TPM-RKE Analyzer 9936 verify the correct TPM Sensors are on the vehicle. Are the correct TPM Sensors installed on the vehicle? Yes Go To 5 . No Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
5. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: If the tires have been rotated, the TPM Sensor is no longer in sequence from the factory. Faults are linked to the TPM Sensor IDs. You MUST locate the correct TPM Sensor that set the fault before continuing. Use the following method below at every tire location. NOTE: If you receive no response from any of the tire pressure sensors, verify that the TPM-RKE Analyzer 9936 is set correctly, and repeat the process on each non-responsive wheel. With the TPM-RKE Analyzer 9936, scan each TPM Sensor for a response and store in the proper location of the TPM-RKE Analyzer 9936. Were the TPM Sensor IDs able to be stored in the proper locations? Yes Go To 7 . No Go To 6 .
6. TIRE PRESSURE MONITORING (TPM) SENSOR NON-RESPONSIVE With the TPM-RKE Analyzer 9936, check to see if the any of the TPM Sensors do not respond after repeated attempts or display the following: "Damaged Accel" "Damaged Press" "Damaged Temp" Are any of the TPM Sensors not responding or displaying the information listed above? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 7 .
7. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - MISMATCHED ID NOTE: If the TPM Sensor IDs do not match, it may be necessary to move the vehicle to a location away from other TPM Sensors and repeat this step. With the TPM-RKE Analyzer 9936, verify the Sensor IDs match what is programmed in the WCM. With the scan tool, select Data Display for the WCM. Do the TPM Sensor IDs match what is stored in the WCM Yes Go To 8 . No With the scan tool, perform the appropriate procedure for uploading the correct IDs in the (WCM). Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
8. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - REMOTE START ANTENNA If the vehicle is equipped with factory installed remote start feature, check to make sure the antenna connector is properly connected to the WCM. Is the Remote Start Antenna properly connected to the WCM? Yes Go To 9 . No Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
9. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT - INTERFERENCE FROM EXTERNAL COMPONENTS NOTE: The DTC can be caused by many different factors and might not be a sensor or a WCM fault. Interference from other elements will over power the sensor RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. NOTE: A system fault can occur by many scenarios, including the following: Signal interference due to electronic devices or driving next to facilities emitting the same Radio Frequencies as the TPM sensors. Installing aftermarket window tinting that affects radio wave signals. Accumulation of snow or ice around the wheels or wheel housings. Using tire chains on the vehicle. Using wheels/tires not equipped with TPM Sensors. Loss of communication with the TPM Transponders or TPM Sensors. Attempt to isolate the external component responsible for the RF interference. Has an interfering external component been isolated? Yes Repair as necessary. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
10. TIRE PRESSURE MONITORING (TPM) SENSOR INTERNAL FAULT SET NOTE: Some vehicles will not receive TPM Sensor data when the vehicle is stationary. The vehicle may need to be driven at speeds greater than 24 km/h (15 mph) for about a minute in order to receive TPM Sensor data. Starting with the left front wheel, deflate the tire to 20 PSI, wait Two minutes, and check the scan tool for changes to any compensated tire pressure values Look for a tire location whose sensor ID that is not responding. Repeat this test on each wheel on the vehicle until the sensor in question has been identified Has the Tire Pressure Monitoring (TPM) Sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the WCM VERIFICATION TEST.
11. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring harness and connectors. Perform any Technical Service Bulletins that may apply to this condition. With the scan tool, erase DTCs. Test drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 24 km/h (15 mph). Does the DTC reset or is the status Active for this DTC? Yes Return to the beginning of this test and perform the appropriate diagnostic procedure as necessary. No Test Complete.

Scheme 26

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article

1. DTC STATUS IS ACTIVE Ignition on, engine not running. With the scan tool, select View DTCs in the Wireless Control Module (WCM). Is the DTC status Active at this time? Yes Go To 2 . No Go To 4 .
2. TIRE PRESSURE TRIGGER MODULE Turn the ignition off. Replace the appropriate Tire Pressure Trigger Module in accordance with the Service Information. With the scan tool, clear DTCs in the Wireless Control Module (WCM). Test Drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 15 mph (24 km/h). With the scan tool, select View DTCs in the Wireless Control Module (WCM). Does the DTC reset or is the status Active for this DTC? Yes Go To 3 . No Test Complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
3. WIRELESS CONTROL MODULE (WCM) View repair. Repair Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
4. INTERMITTENT TIRE PRESSURE TRIGGER MODULE DTC The conditions necessary to set this DTC are not present at this time. Using the wiring schematic as a guide, inspect the wiring and connectors relative to this circuit. Refer to any Technical Service Bulletins that may apply to this condition. With the scan tool, clear DTCs in the Wireless Control Module (WCM). Test Drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 15 mph (24 km/h). With the scan tool, select View DTCs in the Wireless Control Module (WCM). Does the DTC reset or is the status Active for this DTC? Yes Return to the first step of this test and perform the diagnostic procedure. No Test complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.

Scheme 27

For a complete wiring diagram refer to appropriate SYSTEM WIRING DIAGRAMS article

1. DTC STATUS IS ACTIVE Turn the ignition on. With the scan tool, select View DTCs in the Wireless Control Module (WCM). Is the DTC status Active at this time? Yes Go To 2 . No Go To 4 .
2. TIRE PRESSURE TRIGGER MODULE Turn the ignition off. Replace the appropriate Tire Pressure Trigger Module in accordance with the Service Information. With the scan tool, clear DTCs in the Wireless Control Module (WCM). Test Drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 15 MPH (24 km/h). With the scan tool, select View DTCs in the Wireless Control Module (WCM). Does the DTC reset or is the status Active for this DTC? Yes Go To 3 . No Test Complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
3. WIRELESS CONTROL MODULE (WCM) View repair. Repair Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
4. INTERMITTENT TIRE PRESSURE TRIGGER MODULE DTC The conditions necessary to set this DTC are not present at this time. Using the wiring schematic as a guide, inspect the wiring and connectors relative to this circuit. Refer to any Technical Service Bulletins that may apply to this condition. With the scan tool, clear DTCs in the Wireless Control Module (WCM). Test Drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 15 MPH (24 km/h). With the scan tool, select View DTCs in the Wireless Control Module (WCM). Does the DTC reset or is the status Active for this DTC? Yes Return to the first step of this test and perform the diagnostic procedure. No Test complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.

Scheme 28

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article

1. DTC STATUS IS ACTIVE Ignition on, engine not running. With the scan tool, select View DTCs in the Wireless Control Module (WCM). Is the DTC status Active at this time? Yes Go To 2 . No Go To 4 .
2. TIRE PRESSURE TRIGGER MODULE Turn the ignition off. Replace the appropriate Tire Pressure Trigger Module in accordance with the Service Information. With the scan tool, clear DTCs in the Wireless Control Module (WCM). Test Drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 15 mph (24 km/h). With the scan tool, select View DTCs in the Wireless Control Module (WCM). Does the DTC reset or is the status Active for this DTC? Yes Go To 3 . No Test Complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
3. WIRELESS CONTROL MODULE (WCM) View repair. Repair Replace the Wireless Control Module (WCM) in accordance with the Service Information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
4. INTERMITTENT TIRE PRESSURE TRIGGER MODULE DTC The conditions necessary to set this DTC are not present at this time. Using the wiring schematic as a guide, inspect the wiring and connectors relative to this circuit. Refer to any Technical Service Bulletins that may apply to this condition. With the scan tool, clear DTCs in the Wireless Control Module (WCM). Test Drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 15 mph (24 km/h). With the scan tool, select View DTCs in the Wireless Control Module (WCM). Does the DTC reset or is the status Active for this DTC? Yes Return to the first step of this test and perform the diagnostic procedure. No Test complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.

1. DTC STATUS NOTE: This fault can be set if the wrong TPM sensor was installed on the vehicle, or that the wheel has a rubber valve stem. Check to make sure the vehicle is equipped with the correct sensors. NOTE: If the vehicle is equipped with the remote start feature, check to make sure the antenna connector is properly connected to the WCM. NOTE: If the following conditions are present: Low Tire Pressure DTC. Tire Pressure Monitoring (TPM) Sensor Internal DTC. Spare Tire is not equipped with a Tire Pressure Monitoring (TPM) Sensor and is currently on the vehicle. Repair or replace the original tire and place it back on the vehicle. Test drive the vehicle. If the DTCs reset continue with the diagnostic procedure. Test drive the vehicle. If the DTCs reset continue with the diagnostic procedure. Ignition on, engine not running. With the scan tool, select View DTCs in the Wireless Control Module (WCM). Is the DTC status Active at this time? Yes Go To 2 . No Go To 4 .
2. TIRE PRESSURE MONITORING (TPM) SENSOR NOTE: The following tests are used to locate the Tire Pressure Monitoring (TPM) Sensor/Transmitter that is setting the sensor internal fault. If the tires have been rotated, the Tire Pressure Monitoring (TPM) Sensor/Transmitter are no longer in sequence from the factory. Faults are linked to the sensor/transmitter IDs. You MUST locate the correct Tire Pressure Monitoring (TPM) Sensor/Transmitter that set the fault before continuing. Use one or more of the following methods below. METHOD 1: Use a TPM-RKE Analyzer tool to scan each tire pressure sensor. If a suspected sensor has been located, lower the tire pressure to 20 PSI, wait for 2 minutes, and check the scan tool for changes to any compensated tire pressure values. If there was a pressure change to any compensated tire pressure values, check to make sure that the TPM-RKE Analyzer is set correctly, and repeat the process on each wheel on the vehicle until the faulty Sensor/Transmitter has been identified. On base systems starting with the left front wheel, deflate the tire to 20 PSI, wait 2 minutes, and check the scan tool for changes to any compensated tire pressure values or TPM lamp turning on. Look for NO pressure change to any compensated tire pressure value, or a pressure change corresponding to "Sensor 1 Identification". NOTE: Compensated tire pressure values are only available on the premium TPM system. For a base TPM system lowering the tire pressure to 20 PSI will set DTC C0077 and turn on the TPM lamp. NOTE: When scanning a sensor with a TPM-RKE Analyzer, replace the TPM sensor if the results show a "Damaged Accel", "Damaged Temp", or "Damaged Press". Has the malfunctioning/faulty TPM sensor been located? Yes Replace the Tire Pressure Monitoring (TPM) Sensor Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 3 .
3. WIRELESS CONTROL MODULE (WCM) Replace the Wireless Control Module (WCM) in accordance with the service information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. Drive the vehicle for a minimum of 10 minutes while maintaining a continuous speed above 15 mph (24 km/h). During this time the system will learn the sensor IDs. With the scan tool, read DTCs. Are there any DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-485546-S11319983082012071300000) and perform the appropriate diagnostic procedure. No Repair complete. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
4. INTERMITTENT TIRE PRESSURE MONITORING (TPM) SENSOR DTC NOTE: The DTC can be caused by many different factors and might not be a sensor/transmitter or a WCM (WCM) fault. Interference from other elements will over power the sensor/transmitter RF frequency making erratic operation to the TPM system. Check the vehicle for aftermarket accessories that could compromise the RF frequency signal before diagnosing the TPM system. The conditions necessary to set this DTC are not present at this time. Refer to any Technical Service Bulletins that may apply to this condition. With the scan tool, clear DTCs in the Wireless Control Module (WCM). Test Drive the vehicle for a minimum of 10 minutes with vehicle speed greater than 15 m.p.h. With the scan tool, select View DTCs in the Wireless Control Module (WCM). Does the DTC reset or is the status Active for this DTC? Yes Return to the beginning of this test and perform the diagnostic procedure as necessary. No Test complete.

Scheme 29

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. VERIFY DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-485529-S21413626642012071300000) and perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-485529-S21413626642012071300000) and perform the U0155-Lost Communication with Cluster/CCN diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. VERIFY THE DIAGNOSTIC TROUBLE CODE (DTC) IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read the active DTCs. Is this DTC active? Yes Refer to «DIAGNOSIS AND TESTING»(ref-485529-S21413626642012071300000) and perform the U0184-Lost Communication with Radio diagnostic procedure. No Refer to «DIAGNOSIS AND TESTING»(ref-485491-S29601655582012071300000) and perform the Stored Lost Communication DTCs diagnostic procedure.

1. DTC STATUS Make sure every trigger module connector is connected. Ignition on, engine not running. With the scan tool, run the "Trigger Module Test Routine" under "Miscellaneous Functions" for the "WCM" and follow the procedure. NOTE: Three trigger modules are located in three of the four wheel wells on the vehicle to provide the WCM with the location of the tire pressure sensors on the vehicle. A fourth transponder is not necessary in the remaining wheel well due to the process-of-elimination theory. Once the system knows the location of the first three sensors it assumes the location of the fourth tire pressure sensor. The locations of the trigger modules can vary for each vehicle. Make sure the vehicle has trigger modules, and that are in the right locations. After every repair, the trigger module test routine must be rerun in order to verify the fix. Did the Left Front Trigger Module have NO as a result? Yes Go To 2 . No Perform the appropriate diagnostic procedure.
2. (F202) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT OPEN OR HIGH RESISTANCE Ignition on, engine not running. Using a 12-volt test light connect to ground, check the (F202) Fused Ignition Switch Output (Run) circuit. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go To 3 . No Repair the (F202) Fused Ignition Switch Output (Run) circuit for an open circuit or high resistance. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
3. (Z904) GROUND CIRCUIT(S) OPEN OR HIGH RESISTANCE Using a 12-volt test light connect to 12 volts, check each of the (Z904) Ground circuit(s). NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go To 4 . No Repair the (Z904) Ground circuit(s) for an open circuit or high resistance. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
4. (D508) COM - LIN TIRE PRESSURE MONITOR LAN CIRCUIT SHORTED TO VOLTAGE Turn the ignition off. Disconnect all three tire pressure transponder harness connectors. Disconnect the Sentry Key Remote Entry Module harness connector. Ignition on, engine not running. Measure the voltage of the (D508) COM - LIN Tire Pressure Monitor LAN circuit. Is there any voltage present? Yes Repair the (D508) COM - LIN Tire Pressure Monitor LAN circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 5 .
5. (D508) COM - LIN TIRE PRESSURE MONITOR LAN CIRCUIT SHORTED TO GROUND Turn the ignition off. Measure the resistance between ground and the (D508) COM - LIN Tire Pressure Monitor LAN circuit. Is the resistance below 5.0 Ohms? Yes Repair the (D508) COM - LIN Tire Pressure Monitor LAN circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 6 .
6. (D508) COM - LIN TIRE PRESSURE MONITOR LAN CIRCUIT OPEN OR HIGH RESISTANCE Use a jumper wire with one end connected to ground and the other to the (D508) COM - LIN Tire Pressure Monitor LAN circuit in the Front Left Pressure Tire Transponder harness connector. Using a 12-Volt test light connected to battery voltage, probe the (D508) COM - LIN Tire Pressure Monitor LAN circuit in the WCM harness connector. NOTE: The test light should be illuminated and bright. Compared the brightness to that of a direct connection to the battery. Does the test light illuminate bright? Yes Go To 7 . No Repair the (D508) COM - LIN Tire Pressure Monitor LAN circuit for an open circuit or high resistance. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
7. (D508) COM-LIN TIRE PRESSURE MONITOR LAN CIRCUIT OPEN Turn the ignition off. Disconnect the Tire Pressure Trigger Module. Disconnect the WCM harness connector. With an Ohmmeter measure the resistance of the (D508) COM-LIN Tire Pressure Monitor LAN circuit. Is the resistance below 5 Ohms? Yes Go To 8 . No Repair or replace the open circuit. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
8. POWER AND GROUND CIRCUIT OPEN Ignition on, engine not running. With a voltmeter measure the voltage between the power and ground circuit at the Trigger Module. Is the voltage at least the same as battery voltage? Yes Go To 9 . No Repair the open circuit. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
9. CHECK FOR ADDITIONAL TRIGGER MODULE COMMUNICATION RELATED DTCs With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the WCM? Yes Replace/update the WCM in accordance with the service information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Tire pressure trigger Module in accordance with the service information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.

1. DTC STATUS Make sure every trigger module connector is connected. Ignition on, engine not running. With the scan tool, run the "Trigger Module Test Routine" under "Miscellaneous Functions" for the "WCM" and follow the procedure. NOTE: Three trigger modules are located in three of the four wheel wells on the vehicle to provide the WCM with the location of the tire pressure sensors on the vehicle. A fourth transponder is not necessary in the remaining wheel well due to the process-of-elimination theory. Once the system knows the location of the first three sensors it assumes the location of the fourth tire pressure sensor. The locations of the trigger modules can vary for each vehicle. Make sure the vehicle has trigger modules, and that are in the right locations. After every repair, the trigger module test routine must be rerun in order to verify the fix. Did the Left Front Trigger Module have NO as a result? Yes Go To 2 . No Repair intermittent condition. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
2. (F202) FUSED IGNITION SWITCH OUTPUT (RUN) CIRCUIT OPEN OR HIGH RESISTANCE Ignition on, engine not running. Using a 12-volt test light connect to ground, check the (F202) Fused Ignition Switch Output (Run) circuit. NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go To 3 . No Repair the (F202) Fused Ignition Switch Output (Run) circuit for an open circuit or high resistance. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
3. (Z904) GROUND CIRCUIT(S) OPEN OR HIGH RESISTANCE Using a 12-volt test light connect to 12 volts, check each of the (Z904) Ground circuit(s). NOTE: The test light should be illuminated and bright. Compare the brightness to that of a direct connection to the battery. Is the test light illuminated and bright? Yes Go To 4 . No Repair the (Z904) Ground circuit(s) for an open circuit or high resistance. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
4. (D508) COM - LIN TIRE PRESSURE MONITOR LAN CIRCUIT SHORT TO VOLTAGE Turn the ignition off. Disconnect all three tire pressure transponder harness connectors. Ignition on, engine not running. Measure the voltage of the (D508) COM - LIN Tire Pressure Monitor LAN circuit. Is there any voltage present? Yes Repair the (D508) COM - LIN Tire Pressure Monitor LAN circuit for a short to voltage. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 5 .
5. (D508) COM - LIN TIRE PRESSURE MONITOR LAN CIRCUIT SHORT TO GROUND Turn the ignition off. Measure the resistance between ground and the (D508) COM - LIN Tire Pressure Monitor LAN circuit. Is the resistance below 5.0 Ohms? Yes Repair the (D508) COM - LIN Tire Pressure Monitor LAN circuit for a short to ground. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Go To 6 .
6. (D508) COM - LIN TIRE PRESSURE MONITOR LAN CIRCUIT OPEN OR HIGH RESISTANCE Use a jumper wire with one end connected to ground and the other to the (D508) COM - LIN Tire Pressure Monitor LAN circuit in the Front Left Pressure Tire Transponder harness connector. Using a 12-Volt test light connected to battery voltage, probe the (D508) COM - LIN Tire Pressure Monitor LAN circuit in the WCM harness connector. NOTE: The test light should be illuminated and bright. Compared the brightness to that of a direct connection to the battery. Does the test light illuminate bright? Yes Go To 7 . No Repair the (D508) COM - LIN Tire Pressure Monitor LAN circuit for an open circuit or high resistance. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
7. (D508) COM-LIN TIRE PRESSURE MONITOR LAN CIRCUIT OPEN Turn the ignition off. Disconnect the Tire Pressure Trigger Module. Disconnect the WCM. With an Ohmmeter measure the resistance of the (D508) COM-LIN TIRE PRESSURE MONITOR LAN CIRCUIT. Is the resistance below 5 Ohms? Yes Go To 8 . No Repair or replace the open circuit. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
8. POWER AND GROUND CIRCUIT OPEN Ignition on, engine not running. With a voltmeter measure the voltage between the power and ground circuit at the Trigger Module. Is the voltage at least the same as battery voltage? Yes Go To 9 . No Repair the open circuit. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.
9. CHECK FOR ADDITIONAL TRIGGER MODULE COMMUNICATION RELATED DTCs With the scan tool, select Network View and select Advanced. Is there more than one module with active DTCs "Logged Against" the WCM? Yes Replace/update the WCM in accordance with the service information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST. No Replace the Tire pressure trigger Module in accordance with the service information. Refer to «STANDARD PROCEDURE»(ref-485546-S13917643862012071300000) and perform the TPM VERIFICATION TEST.

1. Are there any WCM DTCs present? Yes Repair not complete, refer to «DIAGNOSTIC CODE INDEX»(ref-485546-S00158710032012071300000) and perform the appropriate diagnostic procedure. No Repair is complete.

1. TIRE PRESSURE MONITORING (TPM) Was the Wireless Control Module (WCM) replaced during the test procedure? Yes Go To 2 . No Go To 3 .
2. WIRELESS CONTROL MODULE (WCM) NOTE: When entering the Personal Identification Number (PIN), care should be taken because the WCM will only allow three consecutive attempts to enter the correct PIN. If three consecutive incorrect PIN's are entered the WCM will Lock Out the scan tool. To exit Lock Mode, the ignition key must remain in the Run position for one hour. All accessories must be off. A battery charger connected to the battery during this time period is recommended. Connect the previously removed and/or disconnected components and harness connectors. Obtain the vehicle's unique Personal Identification Number (PIN) assigned to its original WCM. This number can be obtained from the vehicle invoice or from the Chrysler Customer Center (Phone 1-800-992-1997). With the scan tool, select Miscellaneous Functions, WCM. Then select the desired procedure and follow the display on the scan tool. If the WCM was replaced, all the customer's keys must be programmed to the new module. Use the scan tool and the Program Key procedure With the scan tool, erase all DTCs. Perform five ignition key cycles, leaving the key on for at least 90 seconds per cycle. Drive the vehicle for a minimum of 10 minutes while maintaining a continuous speed above 24 km/h (15 mph). During this time the system will learn the new sensor ID code and will clear any DTCs automatically. With the scan tool, read DTCs. Are there any DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-485546-S11319983082012071300000) and perform the appropriate diagnostic procedure. No Repair is complete.
3. WIRE REPAIR Was there a wire repair? Yes Go To 5 . No Go To 4 .
4. TIRE PRESSURE MONITORING (TPM) SENSOR/TIRE PRESSURE MONITORING (TPM) TRANSPONDER REPLACE Connect the previously removed and/or disconnected components and harness connectors. Use a TPM-RKE Analyzer 9936 along with the Scan Tool to program the WCM with the correct TPM Sensor IDs and locations on the vehicle. Drive the vehicle for a minimum of 10 minutes while maintaining a continuous speed above 24 km/h (15 mph). During this time the system will learn the new sensor IDs. With the scan tool, read TPM DTCs. Are there any DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-485546-S11319983082012071300000) and perform the appropriate diagnostic procedure. No Repair is complete.
5. WIRE REPAIR Make sure the WCM and all of the TPM Transponder harness connectors are connected. Ignition on, engine not running. With the scan tool, run the "Trigger Module Test Routine" under "Miscellaneous Functions" for the "WCM" and follow the procedure. NOTE: The three TPM Transponder are located in three of the four wheel wells on the vehicle to provide the WCM with the location of the TPM Sensors on the vehicle. A fourth TPM Transponder is not necessary in the remaining wheel well due to the process-of-elimination theory. Once the system knows the location of the first three TPM Sensors it assumes the location of the fourth TPM Sensor. The locations of the TPM Transponder can vary for each vehicle. Make sure the vehicle has TPM Transponder, and that are in the right locations. After every repair, the TPM Transponder test routine must be rerun in order to verify the fix. Did any of the three TPM Transponder have a NO result? Yes Refer to «DIAGNOSIS AND TESTING»(ref-485546-S11319983082012071300000) and perform the appropriate diagnostic procedure. No Repair complete.
