ASSEMBLY
- Thoroughly clean all gasket mating surfaces before assembling.
- Inspect water pump and components for any damage. Refer to «PUMP, WATER, INSPECTION»(ref-485484-S03153413872012071300000) .
- Using bolts (3), install the water pump (4) and gasket (8) to the water pump adapter (6). Tighten the bolts (3) to 22 N-m (16 lbs. ft.)
- Using bolts (1), install the water pump pulley (2) to the water pump (4). Tighten the bolts (1) to 9 N-m (80 lbs. in.)
- Using bolts (5), install the water pump assembly and gasket to the engine block. Tighten the bolts to 24 N.m (18 lbs. ft.). Refer to «PUMP, WATER, INSTALLATION»(ref-485484-S41972622452012071300000) .
- Start the engine and check for leaks. Refer to «DIAGNOSIS AND TESTING»(ref-485484-S36514498252012071300000) .
Scheme 18
| 1 - WATER PUMP PULLEY |
|---|
| 2 - BOLT |
| 3 - WATER PUMP |
| 4 - WATER PUMP HOUSING |
| 5 - NUT |
| 6 - WATER PUMP RETURN TUBE |
- Position the water pump assembly (3) into the water pump housing (4).
- Install the mounting bolts (2). Tighten the bolts to 24 N.m (18 ft. lbs.).
- Install the water pump pulley (1). Tighten the bolts to 9 N.m (80 in lbs.).
- Install the drive belt splash shield.
- Lower the vehicle.
- Install the accessory drive belt. Refer to «BELT, SERPENTINE, INSTALLATION»(ref-485484-S29366023502012071300000) .
- Connect the negative battery terminal.
- Evacuate air and refill cooling system. Refer to «PUMP, WATER, STANDARD PROCEDURE»(ref-485484-S08201670512012071300000) .
- Check cooling system for leaks. Refer to «STANDARD PROCEDURE»(ref-485484-S02211614932012071300000) .
