SPECIFICATIONS - SPARK PLUGS
| Engine | Spark Plug | Electrode Gap | Thread Size |
|---|---|---|---|
| 2.4L* (with PZEV) | ZFR5AP | 0.8 mm (0.031 in.) | M14 X 1.25 |
| 2.0, 2.4L (without PZEV) | ZFR5F-11 | 1.1 mm (0.043 in.) | M14 X 1.25 |
| 2.7L | RE14PMC5 | 1.27 mm (0.050 in.) | M14 X 1.25 |
| 3.5L | ZFR5LP-13G | 1.27 mm (0.050 in.) | M14 X 1.25 |
| *Partial Zero Emission Vehicle | |||
SPECIFICATIONS - TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| 2.0, 2.4 Camshaft Sensor Screw | 9 | 79.5 | |
| 2.7, 3.5L Camshaft Sensor Screw | 12 | 106 | |
| 2.0, 2.4L Ignition coil bolts | 9 | 79.5 | |
| 2.7L Ignition coil bolts | 7.5 | 65 | |
| 2.0, 2.4L Spark Plugs | 27 | 20 | |
| 2.7L Spark Plugs | 18 | 13 | |
| 3.5L Spark Plugs | 27 | 20 | |
| Knock Sensor 2.0, 2.4, 2.7L | 10 | 7 | |
| Knock Sensor 3.5L | 20 | 15 | |
| Ignition Coil Capacitor Bolt 2.0, 2.4, 2.7L | 10 | 88.5 | |
| Ignition Coil Capacitor Bolt 3.5L | 28 | 20.5 | |
| Transmission mounting bolt | 61 | 45 |
Scheme 30
- Disconnect and isolate negative battery cable at battery.
- Remove electrical connector (1).
- Remove mounting bolt (3) and ignition capacitor (2).
Scheme 31
- Disconnect and isolate the negative battery cable.
- Disconnect the electrical connector.
- Remove nut and capacitor.
Scheme 32
The ignition capacitor is located under the intake manifold on the drivers side of the engine.
- Disconnect and isolate negative battery cable at battery.
- Remove electrical connector (3).
- Remove mounting bolt (1) and ignition capacitor (2).
Scheme 33
The ignition capacitor is located on the drivers side of the engine.
- Disconnect and isolate negative battery cable at battery.
- Remove electrical connector (3).
- Remove mounting bolt (1) and ignition capacitor (2).
